5 www.dension.com
Before using your Bluetooth hands free functions, you need to pair your phone to
the BTA 1500. This only needs to be done once after installation.
6. Pairing
‘System error: Phone not available.’ Press ‘Confirm’. You can now proceed.
he Bluetooth handsfree communication will be turned off.
the radio and select ‘Phone On’ from the menu
In the place of the network operator name, ‘Pairing’ will be displayed. The Gateway
will be in pairing mode for one minute
Enable Bluetooth on your phone and search for audio devices (refer to your phone’s
user manual for details)
Select ‘DENSION-BTA’ and connect using the default PIN ‘0000’
After successful connection, the phone’s name will appear on the car audio system
display. It is now ready to use via the car radio controls
Please note that the following phone menu items are displayed by the Porsche car
audio device and cannot be updated by the Gateway:
•Important no.
•Dialled calls
•Received calls
•Missed calls
To call a number from the phonebook or to navigate inside the phonebook structure,
(ABC-Search function) use the green button on the top-left corner of the PCM
‘Phone Off’ will disable Bluetooth
If ‘Phone On’ is selected the Gateway will go into pairing mode. In the phonebook
menu you can reach the list of the connected phones:
•New phone can be added with a new pairing/connection procedure
•Any device can be deleted by choosing the ‘Delete’ item on the PCM. Any
phone on the list can be connected if the green button is pressed on the name of
the device.
Please note that the Phonebook (or the list of paired devices) is not valid until the
‘Synchronising Phone Book…’ text is shown on the bottom of the PCM display
6.2. BMW
When fitted in a BMW, the BTA1500 provides all of the same functions as the factory-
fitted version. Please refer to your car’s owner’s manual for a full list.
When you turn on the system at the first time, the Bluetooth handsfree communication
Enable Bluetooth on your phone and search for audio devices (refer to your phone’s
user manual for details)
Select ‘DENSION-BTA’ and connect using the default PIN ‘0000’
At first startup t
Press the TEL button on
is switched off. In order to enable it and carry out the pairing process follow the
owners manual of your car. The Gateway500 will be in pairing mode for one minute
‘
’
’
Every time you turn on the system, the following warning message will be displayed:
1. If it is needed, enable the factory Bluetooth module with a diagnostic computer.
2.
3.
4.
5.
6.
7.
8.
9.
10.
6.1. Porsche
1. If it is needed, enable the factory Bluetooth module with a diagnostic computer.
2.
3.
4.
