Denver MT-774 Bedienungsanleitung

7” PORTABLE DVD PLAYER WITH USB/SD/MMC INPUTS

INSTRUCTION MANUAL

SIZE: 148x105mmGB

MT-774

GB-1

FOR SAFE AND EFFICIENT OPERATION

- Do not damage the mains lead.

When not in use, disconnect the mains lead from the outlet. Grasp the plug, not the mains lead,

when disconnecting the unit.

- If water should enter the unit, electrical shock or a malfunction may result. Use in an area where

there is low humidity and little dust.

- Do not disassemble or alter the unit in any way. 。

- Do not use the unit in areas where extremes in temperature occur (below 5 C o r e xceeding

。

35 C), or where it may be exposed to direct sunlight.

- Because of the CD player's extremely low noise and wide dynamic range, there is a tendency

to turn the volume on the amplifier higher than necessary. Doing so may produce an

WARNING

CAUTION

CAUTION!

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE

THIS APPLIANCE TO RAIN OR MOISTURE.

Use of controls or adjustments or performance of procedures

other thanthose specified herein may result in hazardous

radiation exposure.

This Compact Disc player is classified as CLASS 1 LASER product.

Invisible laser radiation when open and interlocks defeated. Avoid

exposure to beam.

CLASS 1 LASER PRODUCT

KLASSE 1 LASER PRODUKT

LUOKAN 1 LASER LAITE

KLASS 1 LASER APPARAT

GB-2

excessively high output from the amplifier which can cause damage to your speakers. Please

be careful in this regard.

- Sudden changes in the surrounding temperature can cause dew to form on the optical

pickup lens inside the unit. Under this condition the unit may be unable to operate properly.

If this should occur, remove the disc and allow the player to adjust to the surrounding

temperature.

- This unit must be operated in a horizontal position.

- Please use the original DVD or VCD or CD or MP3 software, and any copy discs are not

recommendable for use.

- The ventilation should not be impeded by covering the ventilation openings with items,

such as newspapers, table-cloths, curtains, etc;

- No naked flame sources, such as lighted candles, should be placed on the apparatus;

- It shall not be exposed to dripping or splashing and that no objects filled with liquids,

such as vases, shall be placed on the apparatus;

- Do not place the product in closed bookcases or racks without proper ventilation.

- Where the mains plug or an appliance coupler is used as the disconnect device,

the disconnect device shall remain readily operable.

- Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such

as sunshine, fire or the like.

- Excessive sound pressure from earphones and headphones can cause hearing loss.

There are two ways to supply power: AC power supply and Lithium battery power supply.

AC power operation

Connect one end of the mains lead to the DC ~IN socket and the other end to an AC outlet,

and set the POWER ON/POWER OFF select switch to POWER ON.

Lithium battery power supply

When the lithium battery be full charged, push the POWER ON/POWER OFF select switch to

POWER ON, the unit will start work.

Once you connect the unit to the AC outlet, the lithium battery will be charged. The indicator

light has been flashing during charge period. when charged be full of, the indicator light

hasn't been flashing.

POWER SUPPLY

GB-3

14 15 16

GB-4

GB-5

THE FUNCTION PARTS OF THE UNIT

1. TFT screen

2. Left button

In the menu interface , press the key to move

left the option, then press"OK" key to enter the

current location.

3. Upward/ Previous song button:

In the menu interface , press the key to move

up the option, then press"OK" key to enter the

current location.

In the CD/VCD/DVD play interface, press the

key to enter previous song

4. Right button

In the menu interface, press the key to move

left the option, then press"OK" key to enter the

current location.

5. OK button

6. Downward/ Next button

In the menu interface , press the key to move

down the option, then press"OK" key to enter

the current location.

In the CD/VCD/DVD play interface, press the

key to enter next song.

7. Setup button: Enter DVD setup menu.

8. Menu button:

In CD/VCD play mode ,open or close PBC.

In DVD play mode, enter song play menu.

9. Volume- button

10. USB/SD card button

11. Volume+ button

12. Repeat button

13. Audio button

14. CD/VCD/DVD Compartment Lid

open button

15. indicator light:

In work state, indicator lights up, in standby

state, indicator light display flashes red.

16. Mode button:

Enter display setup menu to set Brightness,

Contrast, Colar, FLIP, MODE, Reset.

17. Stop button

18. Pause/play button

19. SD/MMC card socket

20. AV OUT socket

21. COAXIAL socket

22. POWER ON/POWER OFF select switch

23. Phone socket

24. USB socket

25. DC~IN socket

GB-6

1. STANDBY button

2. USB/CARD button

3. DISPLAY button

4. MUTE button

5. Number button

6. REPEAT button

7. A-B button

8. GOTO button

9. STOP button

10. TITLE button

11.SETUP button

12. VOL+ button

13. Upward button

14. ZOOM button

15. LEFT button

17 16

19 20

27 28

29 30

CAUTION

1.When using the remote controller ,make sure the

remote controller directly to the remote sink of the

unit ,and avoid operating in the 45°c and 5m range

having no any bar.

2.When the remote controller doesn't use ,change

the battery as right picture.

3.If the battery isn't used for a long time ,take out it .

REMOTE CONTROL

16. VOL- button

17. OK button

18. RIGHT button

19. AUDIO button

20. PLAY/PAUSE button

21. Downward button

22. SUBTITLE button

23. Fast Recede button

24. Next song button

25. Fast forward button

26. Previous song Button

27. LCD-MODE button

28. MENU/PBC button

29. N/P button

30. PROG button

GB-7

1. Standby button: switch on/off the unit.

2. USB/CARD button: when insetr USB or

CARD, press this button to play song in the

USB or CARD.

3. Display button: display the information of

current song.

4. Mute: mute control

5. Repeat button:

Each press the REPEAT button will

change the repeat mode. During MP4/VCD/

CD playback, there are three modes: Repeat

single ,Repeat all and off. During DVD

playback, there are four modes: Repeat

chapter, Repeat Title, Repeat all and off.

Note: During VCD playback, the PCB mode

must be set to off.

6. A-B button:

Repeat play between A-B point for all discs.

1) Press "A-B" button once at the point where

repeat play is started. (“Rep A-” appears on

the TFT screen.)

2) Press "A-B" button again at the point where

repeat play is stopped. ("Rep A-B" appears on

the TFT screen)

3) To cancel, press "A-B" button again.

INSTRUCTION TO KEYSTROKES OF REMOTE CONTROLLER

7. GOTO button:

Press this button enter into search interface,

such as:

Title 16

Chapter 1

Time 00:00:03

Press upward/downward button to move

high light bar to select item you desired, then

press left or right button to set the value, or

press number buttons to set the value.

8. Title button: press this button to display

disc's played title.

9. Stop button: stop play.

10. Setup button: enter into the DVD setup

interface.

11. Upward/Downward button: press the key

to move up/down the option, then press" OK "

button to enter the current location.

12. Left/Right button: press the key to move

left/right the option, then press "OK" button

to enter the current location.

GB-8

13. OK button: press to enter an item in the

menu or to confirm and execute a selection.

14. Zoom button: repeat this button in turn to

Q1,Q2,Q3, Q4, off.

15. Vol-/+: turn down/up the volume.

16. Audio button: enter into Audio setup

menu, repeat press this button to select left,

right and stereo audio.

17. Subtitle button: The button's function is

switch subject title in DVD disc play mode.

( One DVD disc has over 32 kind of language ).

18. Play/Pause button: Switch between Play

and Pause.

19. Fast backward search button

20. Fast forward search button

21. Pre-view SKIP button

22. Next-view SKIP button

23. LCD-MODE button: Enter display setup

menu to set Brightness,Cintrast,Color,Flip,

Mode,Reset.

24. N/P button: switch between PAL mode

and NTSC mode.

25. PROG button: press PROG button, enter

desired track in sequence by setting the

program play.

Press this button enter into program play

interface, such as:

When playing DVD:

1 ......

......

...... ......

Program

Play

Clear program

When playing VCD:

Press upward/downward/left/right button to

move high light to design point, then press

number button to set title and chapter which

you desired. Move the high light to “play”

after finishing the setup of the program play,

then press OK button, the unit will play the

DVD DISC in sequence according to the

program sequence you just do. If you want to

cancel the program play, move the high light

to “Clear program”, then press OK button.

Tip: When play DVD disc, you must input

title and chapter, and when play VCD, you

just only input chaper.

26. Menu:

In CD/VCD play mode ,open or close PBC.

In DVD play mode, enter song play menu.

1 ......

......

Program

Play

Clear program

GB-9

GENERAL OPERATION

1. Connect one end of the mains lead to the

DC ~IN socket and the other end to an AC

outlet, the indicator light will display red.

2. Press the CD/VCD/DVD Compartment Lid

open button to open the Compartment Lid,

put the DISC in.

3. Set the POWER ON/POWER OFF select

switch to POWER ON, the indicator light will

display green, and the unit will automatically

play the DISC.

4. Press the Play/Pause button to pause the

play, press twice to resume play.

5. Press Stop button to stop the play.

6. Press power button to switch off the unit,

the indicator light will display red.

DVD PLAYING OPERATION

1. Open the unit, after inserting the disc ,

close the cover , then the unit will play

automatically.

(Press some invalid button, the screen will

show "not allowed at the moment". )

2. Title/Chapter Search

(1) Some discs will have many title, each title

will have many chapters. Press Title button

on the remote controller in playing, the screen

will show title.

(2) Press upward/downward/left/right button

to select expected title, then press “OK”

button to play.

(3) Select playing tracks chapter with number

key "0-9" and "10+" (the entering number must

less than the total chapter number), then

press "ENTER" to play.

3. Previous and next

During playing, press " " " " button of the

remote controller, each time press the button,

jump a chapter to playing.

Press " ", playing from the next chapter;

press " ", playing from the previous chapter.

4. Fast forward and fast backward

(1)Press the " " button or " " button to

activate fast forward or fast backward function.

Andere Denver Tragbarer DVD-Player Handbücher

Denver

Denver MT-910 Bedienungsanleitung

Denver

Denver MT-1002DVBT Bedienungsanleitung

Denver

Denver MTW-1085TWIN Bedienungsanleitung

Denver

Denver MT-1097 Bedienungsanleitung

Denver

Denver MT-1083NB Bedienungsanleitung

Denver

Denver MT-1084NB Bedienungsanleitung

Denver

Denver MT-1087T2H Bedienungsanleitung

Denver

Denver MT-779DVBT Bedienungsanleitung

Denver

Denver 12809S Bedienungsanleitung

Denver

Denver MT-739 Bedienungsanleitung

Denver

Denver MTW-981 TWIN Bedienungsanleitung

Denver

Denver DFT-714M Bedienungsanleitung

Denver

Denver MTW-751 TWIN Bedienungsanleitung

Denver

Denver MT-1002 BLACK Bedienungsanleitung

Denver

Denver MT-748DVBT Bedienungsanleitung

Denver

Denver MT-983NB Bedienungsanleitung

Denver

Denver MT-1063 Bedienungsanleitung

Denver

Denver MTW-735 TWIN Bedienungsanleitung

Denver

Denver MT-766 Bedienungsanleitung

Denver

Denver MT-980DVBT Bedienungsanleitung

Denver

Denver MT-908 Bedienungsanleitung

Denver

Denver MTW-793 Bedienungsanleitung

Denver

Denver MT-781 Bedienungsanleitung

Denver

Denver MTW-745 TWIN Bedienungsanleitung

Beliebte Tragbarer DVD-Player Handbücher anderer Marken

Philips

Philips PET718/77 Bedienungsanleitung

Impecca

Impecca DVP775 Bedienungsanleitung

NextBase

NextBase MULTI-VISION SET PRO Bedienungsanleitung

Impecca

Impecca DVP-1017 Bedienungsanleitung

Akura

Akura APDVD6008 Bedienungsanleitung

TV Star

TV Star TD3 LCD COMBO Bedienungsanleitung

LENCO

LENCO MES-202 Bedienungsanleitung

Philips

Philips PET940/98 Bedienungsanleitung

Philips

Philips PET702P Bedienungsanleitung

Philips

Philips PD7016 Bedienungsanleitung

Logik

Logik L7SPDVD11 Bedienungsanleitung

LG DP650 Bedienungsanleitung

Mustek

Mustek MVP850B Bedienungsanleitung

Insignia

Insignia NS-MDDVD10 Bedienungsanleitung

Philips

Philips PD9000/12 Bedienungsanleitung

LENCO

LENCO DVP-1027 Bedienungsanleitung

Philips

Philips PD7010/05 Bedienungsanleitung

Technika

Technika PDVDTWINSS10 Benutzerhandbuch
