Denver IR-135B Bedienungsanleitung

-1-

Internet Radio

IR-135B/IR-135S

User Manual

Please read this user manual carefully before using the radio.

-2-

Safety information

Please read the safety instructions carefully before using the product for the first time and keep the

instructions for future reference.

1. This product is not a toy. Keep it out of reach of children.

2. Keep product out of the reach of children and pets to avoid chewing and swallowing.

3. Product operating and storage temperature is from 0 degree Celsius to 40 degree Celsius. Under

and over this temperature might affect the function.

4. Never open the product. Touching the inside electrics can cause electric shock. Repairs or

service should only be performed by qualified personnel.

5. Do not expose to heat, water, moisture, direct sunlight!

6. Please protect your ears against loud volume. Loud volume can damage your ears and risk in

hearing loss.

7. Bluetooth wireless technology operates within a range of about 10 m (30 feet). The maximum

communication distance may vary depending on the presence of obstacles (people, metal

objects, walls, etc.) or the electromagnetic environment.

8. Microwaves emitting from a Bluetooth device may affect the operation of electronic medical

devices.

9. The unit is not waterproof. If water or foreign objects enter the unit, it may result in fire or electric

shock. If water or a foreign object enters the unit, stop use immediately.

10. Only charge with supplied Adaptor. The direct plug-in adapter is used as disconnect device, the

disconnect device shall remain readily operable. So, make sure there is space around the power

outlet for easy access.

11. Do not use non original accessories together with the product as this can make the product

functionality abnormal.

-3-

Location of Controls

Press and hold to power the radio on/off.

Press to switch to standby mode / activate the radio (standby mode is enabled only when power is

connected. It will be disabled when battery power is used).

Back to previous menu/navigation left.

Return to Home screen / Return to the playing screen.

Navigation right / Enter edit menu of the Favorite list / Display the big clock & radio info on the now

playing display.

5. Dial / Select / Volume

Rotate to scroll up/down on the menu / Select menu options. Push to confirm / Push to stop /

Resume playback of radio channel. Rotate to adjust the volume level.

Press and hold to preset a particular station.

Press to recall the Favorite list.

7. Preset buttons 1-3

Preset your top three favorite stations.

Press and hold to preset stations.

Press to recall stations.

8. 2.4" TFT color display.

9. Speaker

10. USB port to connect USB-C cable for charging built-in battery.

11. 3.5 mm line out jack.

12. 3.5 mm earphone jack.

13. LED indicator for battery charging status.

-4-

How to Enter the Password for Your Wireless Network

Using control buttons on the radio

Use the [Tune/Select] dial to scroll through the characters, highlight the desired character and press the

[Tune/Select] dial to confirm, then enter the next character.

When it comes to the last character of the password, press and hold the [Tune/Select] dial to confirm

and complete the entry.

Note: The password is case sensitive.

Getting Started

The radio is powered by the built-in lithium battery. A power adapter with USB-C plug is included in the

product package.

Press and hold the [ ] button to power the radio on.

To power off the radio, press and hold the button again.

Standby mode is enabled only when mains power is connected and so to make use of the alarm clock

function.

Connect the power supply to the radio, press and hold the [ ] button to turn it on. Pressing the [ ]

button again will turn the radio to standby mode.

-5-

Internet Radio

On the Home screen, choose Internet Radio to find the options below:

Skytune

Select Skytune to start enjoying thousands of radio stations from all over the world.

You can filter your search by region, genre and talks.

Local Radio lets you quickly access the stations available in your local area through internet connection.

-6-

Music Streaming

⚫Once the UPnP/DLNA compatible server is configured to share media files with your radio, you can

start music streaming.

⚫On the main menu, select Media Centre and choose UPnP.

⚫It may take a few seconds for the radio to complete the scan for available UPnP servers. If no UPnP

servers are found, it will show Empty List.

⚫After a successful scan, select your UPnP server.

⚫The radio will show the media categories available from the UPnP server, e.g. 'Music', 'Playlists', etc.

⚫Choose the media files that you wish to play.

You can set the playback mode under Configuration > Playback setup.

Bluetooth Playback

⚫Push the Home button to display the selection menu for the different operating modes.

⚫Use the left/right/up/down button on the remote control or turn the dial to select the operating mode

Bluetooth, then press the dial to confirm.

⚫Switch your Bluetooth device to which you want to connect the radio on and activate pairing mode.

The device scans for Bluetooth devices in the reception range.

⚫When the radio is found, your Bluetooth device shows its name Denver IR-135-XXXX (the XXXX is

an identification code for your radio).

⚫Select the radio as your Bluetooth device.

⚫Start playback on your Bluetooth device.

⚫Playback now takes place using the radio.

-7-

Alarm Setup

Important!

In order to use the alarm clock function, connect the radio with to mains power supply to enable

standby mode.

When the radio is turned on, press the [ ] button to turn the radio to standby mode. Standby

mode is disabled when the radio is using internal battery.

⚫Choose Alarm from the main menu or press the [Alarm] button on the remote control.

⚫Select either Alarm 1 or Alarm 2, choose Turn on to activate the alarm.

⚫Follow the alarm wizard instructions to set the alarm.

⚫The wizard will guide you through the settings below:

Time

- Set the time for the alarm.

Sound

- You can choose Wake to Tone, My Favorite as the alarm source.

Repeat

- You can schedule the alarm as everyday, once or multiple days.

Alarm Volume

- Adjust the volume of the alarm as you like by rotating the [Dial/Select]

knob.

Alarm duration

- Set the duration of the alarm from 15 to 180 minutes. The radio will be

turned to standby mode when the selected duration of time is due.

⚫After the above settings are completed, press the [◄] button to exit and make sure the alarm is

turned on. You will see the alarm icon on the display if it is activated.

Stopping the alarm / Activating the snooze function

When the alarm goes off, press the [ ] button to stop the alarm or press the [Select] dial to activate the

snooze feature.

When snooze is activated, the alarm is muted for 9 minutes and sounds again when the time is due.

You can repeat the process multiple times.

To stop the "Snooze" function, press the [ ] button.

-8-

Technical Specification

Model

IR-135B/IR-135S

Power input

5V 1A

Voltage

100-240V~50/60Hz

Wireless network

IEEE802.11 b/g/n

Wireless network frequency

2412-2484 MHZ

Wireless transmission power

Typical transmission power 14 dBm (72.2 Mbps);

20 dBm (11 b mode)

Security protocol

WEP/WPA/WPA2

Bluetooth version

V4.2 BR/EDR compliant

Bluetooth frequency

2.4 GHz

Bluetooth range

10 meters (line of sight)

Built-in lithium-ion battery

3.7V, 2000 mAh

Audio output

3.5 mm stereo earphone jack

Stereo line out

Dimensions

180 x 110 x 105 mm (L x D x H)

Notes: Specifications may vary without notice

In the box

* Internet Radio

* Power adapter with USB-C plug

* User manual

WEEE and Recycling

The European laws do not allow the disposal of old or defective electric or electronic

devices with the household waste. Return your product to a municipal collection

point for recycling to dispose of it. This system is financed by the industry and

ensures environmentally responsible disposal and the recycling of valuable raw

materials.

-9-

Please notice - All products are subject to change without any notice. We take reservations for errors

and omissions in the manual.

Electric and electronic equipment and included batteries contains materials, components and

substances that can be hazardous to your health and the environment, if the waste material (discarded

electric and electronic equipment and batteries) is not handled correctly.

Electric and electronic equipment and batteries is marked with the crossed out trash can symbol, seen

above. This symbol signifies that electric and electronic equipment and batteries should not be disposed

of with other household waste, but should be disposed of separately.

As the end user it is important that you submit your used batteries to the appropriate and designated

facility. In this manner you make sure that the batteries are recycled in accordance with legislature and

will not harm the environment.

All cities have established collection points, where electric and electronic equipment and batteries can

either be submitted free of charge at recycling stations and other collection sites, or be collected from the

households. Additional information is available at the technical department of your city.

Hereby, Denver A/S declares that the radio equipment type IR-135 is in compliance with Directive

2014/53/EU. The full text of the EU declaration of conformity is available at the following internet

address: denver.eu and then click the search ICON on topline of website. Write model number: IR-135.

Now enter product page, and RED directive is found under downloads/other downloads.

Operating Frequency Range: .412-2.484 GHz Bluetooth 2400-2485GHz

Max Output Power: 30W/ 3W RMS

-10-

DENVER A/S

Omega 5A, Soeften

DK-8382 Hinnerup

Denmark
