DEVA Broadcast DB35 Gebrauchsanweisung

DB35

Compact & Reliable FM Radio Streamer

65 Aleksandar Stamboliyski Str., 8000 Burgas, Bulgaria

Tel.: +359 56 820027, Fax: +359 56 836700

Email: [email protected], Web: www.devabroadcast.com

Quick User Guide

BEFORE YOU USE THIS PRODUCT

In order to be able to enjoy all the benefits of owning your new

DEVA product, please verify first that the latest software and

firmware release were installed.

Visit www.devabroadcast.com/downloads for the most

recent software and firmware downloads, prior the installation.

DEVA Broadcast Limited is an ISO 9001:2015 certified company.

This Quick user guide will make the installation of DB35 – Compact & Reliable FM Radio Streamer quick

and easy. Applying these principles, you can simplify the process and save yourself extra time and effort.

For more information about the Safety precautions and the Operating environment

recommendations please refer to the User Manual.

Ÿ Install the unit on its operation place;

Ÿ Connect the device to 12V DC network using the provided adapter;

Ÿ Connect the antenna cable to the RF antenna input connector located on the rear panel of the device;

Ÿ Connect DB35 to the TCP/IP network using a direct network cable;

DB35 is controlled through a built-in WEB Server and a standard web browser can be used to monitor

its status or to make some adjustments. To operate the device you need to know its IP address and follow

these steps:

1. Open a new WEB Browser;

2. Enter the device IP address in the Address field and press “Enter”;

NOTE: If the port is different than the default one (80), it is need to be specified. For example:

http://192.168.1.2:9000

In case you are not aware of the IP Address, use the Network discovery feature at Local

networks or refer to Step 4.

After connecting the network cable the LED 'LAN' indicator located on the rear panel must be ON or (1)

flashing. These are the Default Network Settings:

3. A window requiring a username and a password will appear. Default values are username: admin

and password: pass (For more information refer to Step 5).

NOTE: DB35 has an DHCP assigned IP address by default. In order to establish a communication, your

PC should be connected to the same Sub network as the device. For further information consult

with your network administrator.

DHCP: Enabled

IP: Assigned by DHCP

Mask: Assigned by DHCP

Gateway: Assigned by DHCP

DNS: Assigned by DHCP

HTTP Port: 80

Connection

STEP 1

Network Settings

STEP 2

WEB Interface

STEP 3

LAN

ANTENNA

MAX 110 dBµV

POWER

12V / 2A

MADE IN

BULGARIA

AUDIO INPUT

LEFT RIGHT

2. Select your current network profile.

Network discovery is a network setting that defines whether your computer can see (find) other

computers and devices on the network and whether other computers on the network can see your

computer. By default, Windows Firewall blocks network discovery but you can enable it.

4. To access the device, open a new Explorer bar and click on . If you have successfully Network (1)

enabled the network discovery option, the device will be displayed. Double click on will open DB35 (2)

a new WEB browser window requiring a username and a password.

(For more information refer to Step 5)

NOTE: If you have already enabled this function on your computer just open a new Explorer bar and click

on . The device will be displayed. If not, follow the instructions from Step 4.Network (1)

1. Open Advanced sharing settings by clicking the Start button, and then click on "Control Panel". In the

search box, type "network", click "Network and Sharing Center", and then, in the left pane click

"Change advanced sharing settings".

3. Click "Turn on network discovery", and then click "Save changes". If you're prompted for an

administrator password or confirmation, type the password or provide confirmation.

Network Discovery for Windows 7

STEP 4

DB35 provides you with a protected access to the device settings.

The device serves only one user at a time, thus username and password will be requested when login.

Default values are admin and pass.

After successful log in the Control Window will look like this:

Please refer to the User manual for detailed information on

how to configure and explore your device.

The Web Interface is visually divided into three parts:

ŸLeft – General Tuner and Channel readings, functional buttons.

ŸMiddle – Specific contextual readings;

ŸRight – Navigational Menu;

NOTE: Nevertheless the current menu of the WEB Interface, the left section is constantly displayed. This

allows immediate tuner interactions.

WEB Interface Login

STEP 5

STEP 6

WEB Interface Operation
