DFI E586-ICP Bedienungsanleitung

E586-ICP

E586-IPE

System Board

User’s Manual

-D23540520-

No part of this document may be copied or reproduced

in any form or by any means without the prior written

consent of DFI, Inc.

DFI, Inc. makes no warranties with respect to this

documentation and disclaims any implied warranties of

merchantability, quality, or fitness for any particular

purpose. The information in this document is subject to

change without notice. DFI, Inc. reserves the right to

make revisions to this publication and to make changes

to any and/or all parts of its content, at any time,

without obligation to notify any person or entity of such

changes. Further, DFI, Inc. assumes no responsibility

for any errors that may appear in this document.

DFI is a registered trademark, and E586-ICP/E586-IPE

is a trademark of Diamond Flower, Inc. All other

product names mentioned are trademarks or registered

trademarks of their respective companies.

vFCC Statement on Class B

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to

Part 15 of the FCC rules. These limits are designed to

provide reasonable protection against harmful interfer-

ence when the equipment is operated in a residential

installation. This equipment generates, uses, and can

radiate radio frequency energy and if not installed and

used in accordance with the instruction manual may

cause harmful interference to radio communications.

However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does

cause harmful interference to radio or television recep-

tion, which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and

the receiver.

•Connect the equipment into an outlet on a circuit

different from that to which the receiver is

connected.

•Consult the dealer or an experienced radio TV

technician for help.

Notice:

1. The changes or modification not expressly approved

by the party responsible for compliance could void

the user's authority to operate the equipment.

2. Shielded interface cables must be used in order to

comply with the emission limits.

v Table of Contentsv

Introduction .................................................................................

Features and Specifications .................................................

Package Checklist .................................................................

Installation Overview .................................................................

Preparing the Area ................................................................

Handling the System Board ..................................................

Tips in Handling the System Board ...............................

Hardware Installation.............................................................

Memory Installation .........................................................

Installing the Modules ..............................................

Board Configuration ........................................................

Jumper Settings .......................................................

Cache Configuration ................................................

Jumper Settings for Cache Memory .................

CPU Installation ..............................................................

Jumper Settings for CPU ........................................

Installing Upgrade CPUs ........................................

Installing the System Board ..................................................

Installing the PS/2 Mouse Port .............................................

Initial Setup Program .................................................................

Award BIOS CMOS Setup Utilities ......................................

Standard CMOS Setup ..................................................

BIOS Features Setup .....................................................

Chipset Features Setup .................................................

PCI Slot Configuration ...................................................

Load BIOS Defaults .......................................................

Load Setup Defaults ......................................................

Password Setting ...........................................................

IDE HDD Auto Detection ...............................................

Save & Exit Setup ..........................................................

Exit Without Saving ........................................................

1-1

1-2

2-1

2-2

2-6

2-7

2-9

2-13

2-15

2-16

2-17

2-18

2-22

2-24

3-1

3-2

3-5

3-7

3-8

3-9

3-10

3-11

3-12

EISA Configuration Utility .......................................................

Troubleshooting Checklist ......................................................

Appendix A:Types of Modules ..............................................

Appendix B:System Error Report .........................................

Appendix C:Memory & I/O Maps ...........................................

Appendix D:EISA I/O Pin Assignments ................................

Appendix E:PCI I/O Pin Assignments ..................................

Appendix F:Connector Pin Assignments ............................

Appendix G:Award BIOS Hard Disk Table ...........................

4-1

5-1

A-1

B-1

C-1

D-1

E-1

F-1

G-1

This page left intentionally blank.

Read Me First

The E586-ICP/E586-IPE system board requires the installation

of the ECU (EISA Configuration Utility), found on the

provided EISA Configuration Utility diskette, for proper

operation of this system board.

The ECU configures the EISA devices and maintains system

parameters by storing them in the Extended CMOS Memory, so

the BIOS can initialize the system and expansion boards

inserted in the EISA slots once you power up your system.

The Extended CMOS Memory is equipped with an internal

battery that needs to be constantly charged. In a small number

of cases, the internal battery may have drained and the

information stored in the Extended CMOS Memory lost during

shipment. If this happens, you will get the message "EISA

CMOS Inoperational" when you power up your system.

Simply run the ECU software, bundled with the system board,

to reconfigure the system. Save the configuration and reboot

your system. Refer to the EISA Configuration Utility section on

page 4-1 for more detailed information.

EISA/PCISystemBoard

vIntroduction

The E586-ICP/E586-IPE system board offers several

advanced features integrated into the system board. It is

designed based on the new PCI (Peripheral Component

Interconnect) local bus and EISA (Extended Industry

Standard Architecture) standards.

The E586-ICP/E586-IPE supports 273-pin Zero Inser-

tion Force socket for PentiumTM processors running at

60MHz or 66MHz bus speed. It also supports an op-

tional Flash EPROM. Flash EPROM is a memory chip

for the storage of BIOS which can be erased in bulk or

modified using a software utility.

The E586-ICP/E586-IPE comes with an EISA Configu-

ration Utility (ECU) that must be installed and run to

configure the board and the EISA expansion boards that

will be inserted in the EISA expansion slots.

The E586-ICP/E586-IPE system board is equipped with

four EISA and four PCI local bus slots. One EISA slot

and one PCI slot are shared, meaning you may use only

one or the other of these three slots. Therefore, in

accord with the PCI standard, seven slots are useable.

The E586-ICP/E586-IPE is also equipped with one

mini-DIN-6 connector for the PS/2 mouse and an op-

tional IDE disk interface, only if installed with the

Symphony SL82C101P chip.

The E586-ICP/E586-IPE can be configured to twenty-

two different sizes from 2MB to 128MB using 256Kx36,

512Kx36, 1Mx36, 2Mx36, 4Mx36 and 8Mx36 HSIM

modules.

1-1 uIntroduction

E586-ICP/E586-IPE

•Microprocessor

PentiumTM Processor

•Chipset

Intel 82430 PCI: system

Symphony SL82C101P: PCI IDE (optional)

•BIOS

Award system BIOS

•Cache Memory

256K or 512K Burst (sync) SRAM for 3-1-1-1

Level 2 cache access (E586-ICP)

256K or 512K Async SRAM for 3-2-2-2 Level 2

cache access (E586-IPE)

Supports direct map write-back or write-through

cache subsystem

Integrated cache tag RAM

•Memory Onboard

2MB to 128MB

•DRAM Type

256Kx36, 512Kx36, 1Mx36, 2Mx36, 4Mx36 and

8Mx36 SIMM

Supports single and/or double density SIMMs

Supports DRAM access time of 60ns or 70ns

Supports page mode

•ZIF Socket

273-pin ZIF socket (Intel Socket 4)

Features and Specifications

Introduction u1-2

EISA/PCISystemBoard

•Slots

Three 32-bit PCI slots

One shared - PCI/EISA slot

Three 32-bit EISA slots

•Connectors

A mini-DIN-6 connector for the PS/2 mouse

One IDE disk interface (optional; only if installed

with the Symphony SL82C101P chip)

•Tooling Holes

Baby AT form factor

•PCB

4 layers

Package Checklist

The E586-ICP/E586-IPE package contains the following

items:

•The E586-ICP/E586-IPE system board

•The E586-ICP/E586-IPE user’s manual

•One EISA Configuration Utility diskette

•One DB-25S hole cover holding the PS/2 mouse port

•One 40-pin IDE hard disk cable (optional)

If any of these items is missing or damaged, please

contact your dealer or sales representative for assistance.

1-3 uIntroduction
