DFI G586OP Bedienungsanleitung
G586OPA
Rev. 0 +
System Board
User’s Manual
-D26250525-
vCopyright1995byDFI,Inc.
All rights reserved.
No part of this document may be copied, reproduced in
any form or by any means or used to make any trans-
formation/adaptation without the prior written consent
of DFI, Inc.
DFI, Inc. makes no warranties with respect to this
documentation and disclaims any implied warranties of
merchantability, quality, or fitness for any particular
purpose. The information in this document is subject to
change without notice. DFI, Inc. reserves the right to
make revisions to this publication and to make changes
to any and/or all parts of its content, at any time,
without obligation to notify any person or entity of such
changes. Further, DFI, Inc. assumes no responsibility
for any errors that may appear in this document.
DFI is a registered trademark, and G586OPA is a
trademark of Diamond Flower, Inc. All other product
names mentioned are trademarks or registered trade-
marks of their respective companies.
vFCC Statement on Class B
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interfer-
ence when the equipment is operated in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
the receiver.
•Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio TV
technician for help.
Notice:
1. The changes or modifications not expressly
approved by the party responsible for compliance
could void the user's authority to operate the
equipment.
2. Shielded interface cables must be used in order to
comply with the emission limits.
v Table of Contentsv
Introduction ..............................................................................
Features and Specifications .........................................
Package Checklist ........................................................
Installation Overview ...............................................................
Preparing the Area ..............................................................
Handling the System Board ................................................
Tips in Handling the System Board ..............................
Hardware Installation...........................................................
Memory Installation .......................................................
Installing the Modules ............................................
Board Configuration ......................................................
Jumper Settings for Flash EPROM, PS/2 Mouse
and Display Type....................................................
Jumper Settings for Parallel Port ...........................
Cache Configuration .....................................................
Jumper Settings for Cache Memory ......................
CPU Installation ............................................................
Jumper Settings for CPU .......................................
Installing Upgrade CPUs .......................................
Built-in Ports ........................................................................
Serial Ports ...................................................................
Parallel Port ..................................................................
Floppy Disk Drive Connector ........................................
IDE Hard Disk Connector .............................................
PS/2 Mouse Port ...........................................................
Installing Expansion Cards ..................................................
Installing the System Board ................................................
1-1
1-2
1-5
2-1
2-1
2-2
2-2
2-3
2-3
2-6
2-7
2-8
2-11
2-13
2-14
2-17
2-18
2-21
2-26
2-27
2-28
2-30
2-31
2-34
2-35
2-36
3-1
3-2
3-2
3-5
3-7
3-8
3-9
3-16
3-17
3-17
3-18
3-19
3-20
4-1
5-1
A-1
B-1
C-1
D-1
E-1
F-1
G-1
Initial Setup Program ..............................................................
Award BIOS CMOS Setup Utilities .....................................
Standard CMOS Setup .................................................
BIOS Features Setup ....................................................
Chipset Features Setup ................................................
Power Management Setup ...........................................
PCI Configuration Setup ...............................................
Load BIOS Defaults ......................................................
Load Setup Defaults .....................................................
Password Setting ..........................................................
IDE HDD Auto Detection ..............................................
Save & Exit Setup .........................................................
Exit Without Saving .......................................................
IDE Device Drivers ..................................................................
Troubleshooting Checklist .....................................................
Appendix A:Types of Modules ..............................................
Appendix B:System Error Report .........................................
Appendix C:Memory & I/O Maps ..........................................
Appendix D:PCI I/O Pin Assignments ..................................
Appendix E:ISA I/O Pin Assignments ..................................
Appendix F:Connector Pin Assignments ............................
Appendix G:Award BIOS Hard Disk Table ...........................
PCI/ISASystemBoard
1-1 uIntroduction
vIntroduction
The G586OPA system board offers several advanced
features integrated into the system board. Its design is
based on the new Peripheral Component Interconnect
(PCI) local bus and Industry Standard Architecture
(ISA) standards.
The G586OPA supports a 320-pin Zero Insertion Force
(ZIF) CPU socket for PentiumTM processors running at
75MHz, 90MHz, 100MHz, 120MHz or 133MHz fre-
quency. This ZIF socket allows users to easily upgrade
their CPUs. It also supports a Flash EPROM for easy
BIOS upgrades. Flash EPROM is a memory chip for the
storage of BIOS which can be erased in bulk or modi-
fied using a software utility.
The G586OPA is equipped with three PCI slots, three
ISA slots and one shared PCI/ISA slot.
Equipped with two built-in PCI IDE connectors, the
G586OPA system board can control four drives and
supports fast Mode 3 hard drives and hard drives larger
than 528MB under DOS. The system board is also
equipped with two NS16550-compatible serial ports, an
ECP/EPP parallel port, a floppy disk drive controller,
and one mini-DIN-6 connector for the PS/2 mouse.
The G586OPA can support 2MB to 128MB of memory
using 256Kx36, 512Kx36, 1Mx36, 2Mx36, 4Mx36 and
8Mx36 72-pin SIM modules.
G586OPA
Features and Specifications
Introduction u1-2
Processor
•Intel PentiumTM 75/90/100/120/133MHz
Chipset
•OPTI: Viper chipset
82C556 -data buffer
82C557 -system controller
82C558 -Integrated Peripheral Controller
Energy Efficient Design
•Supports 3.3V CPUs
•Supports system power management
•Supports CPU stopped clock
Power Management
•Three power-saving stages: Doze, Standby and
Suspend
•Microsoft APM 1.1 supported
•EPA Energy Star compliant design
PCI IDE Interface
•Fast PCI local-bus interface
•Supports Mode 3 (enhanced IDE) hard drives
•Two IDE connectors to control four drives (e.g. two
HDDs, one tape drive and one CD-ROM)
•Uses NS PC87410 PCI IDE chip
Super I/O Interface
•Two NS16C550A-compatible serial ports
•PS/2 mouse port
•One parallel port with EPP and ECP support
•Supports 360KB, 720KB, 1.2MB, 1.44MB and
2.88MB floppy drives
•Uses NS PC87332VF super-I/O controller
PCI/ISASystemBoard
1-3 uIntroduction
BIOS
•Award Plug & Play BIOS
•Flash EPROM for easy BIOS upgrades
•Supports IDE HDDs larger than 528MB under DOS
(LBA mode only)
Architecture
•PCI/ISA
Cache Memory
•256K, 512K or 1MB direct map write-back or
write-through cache
•Uses 32Kx8, 64Kx8 or 128Kx8 SRAM
•Supports 3.3V or 3V/5V mixed mode SRAM
Memory Onboard
•Up to 128MB
•Four 72-pin SIMM sockets
•Supports single and/or double density SIMMs
•256Kx36, 512Kx36, 1Mx36, 2Mx36, 4Mx36 or
8Mx36 SIMMs
•Supports 60ns or 70ns fast page mode DRAM
Expansion Slots
•Three dedicated PCI slots
•One shared PCI/ISA slot
•Three dedicated 16-bit ISA slots
Due to the height of the heat sink, once the 3.3V
Pentium Upgrade Processor is in place, you cannot
install full-length add-in cards in slot connectors 1, 2
& 4 (ISA), and 1 & 2 (PCI). These slots are limited
to 2/3 length of add-in cards.
G586OPA
ZIF Socket
•320-pin ZIF socket (Intel Socket 5)
Board Dimensions
•33cm (12.87") x 22cm (8.58")
Baby AT form factor
Introduction u1-4
PCI/ISASystemBoard
1-5 uIntroduction
Package Checklist
The G586OPA package contains the following items:
•The G586OPA system board
•The G586OPA user’s manual
•Two IDE driver diskettes
•One 34-pin floppy disk drive cable
•Two 40-pin IDE hard disk cables
•One 25-pin printer port cable for chassis mounting
•One card-edge bracket with serial and mouse port
cables
If any of these items are missing or damaged, please
contact your dealer or sales representative for assistance.
Inhaltsverzeichnis
Andere DFI Hauptplatine Handbücher
DFI
DFI DL631-C226 Bedienungsanleitung
DFI
DFI K6XV3+ Bedienungsanleitung
DFI
DFI CM33-TC Bedienungsanleitung
DFI
DFI K6BV3+/66 Bedienungsanleitung
DFI
DFI Lanparty JR P45-T2RS Bedienungsanleitung
DFI
DFI NB71-BC Bedienungsanleitung
DFI
DFI KD631-C236 Bedienungsanleitung
DFI
DFI NFII ULTRA-A Bedienungsanleitung
DFI
DFI SB601-C Bedienungsanleitung
DFI
DFI NT70-SC Bedienungsanleitung
DFI
DFI PIC-Q170 Bedienungsanleitung
DFI
DFI PT630-NRM Bedienungsanleitung
DFI
DFI CMS100 Bedienungsanleitung
DFI
DFI LanParty LT X38 series Bedienungsanleitung
DFI
DFI 852GME-MGF Pro Bedienungsanleitung
DFI
DFI LanParty LT X38 series Bedienungsanleitung
DFI
DFI LanParty nF4 Bedienungsanleitung
DFI
DFI 915P-TAG Bedienungsanleitung
DFI
DFI KM400A-MLV Bedienungsanleitung
DFI
DFI WL051 Bedienungsanleitung
Beliebte Hauptplatine Handbücher anderer Marken
Gigabyte
Gigabyte GA-9IVDT Bedienungsanleitung
Texas Instruments
Texas Instruments ADS8372EVM Bedienungsanleitung
Commell
Commell MS-C73 Bedienungsanleitung
IBT Technologies
IBT Technologies MB860 Bedienungsanleitung
Nvidia
Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung
Biostar
Biostar M7VIT Bravo Bedienungs- und Montageanleitung
