G586VPM

Rev.A

System Board

User’s Manual

- D25141203 -

No part of this document may be copied or reproduced

in any form or by any means without the prior written

consent of DFI, Inc.

DFI, Inc. makes no warranties with respect to this

documentation and disclaims any implied warranties of

merchantability, quality, or fitness for any particular

purpose. The information in this document is subject to

change without notice. DFI, Inc. reserves the right to

make revisions to this publication and to make changes

to any and/or all parts of its content, at any time,

without obligation to notify any person or entity of such

changes. Further, DFI, Inc. assumes no responsibility

for any errors that may appear in this document.

DFI is a registered trademark, and G586VPM is a

trademark of Diamond Flower, Inc. All other product

names mentioned are trademarks or registered trade-

marks of their respective companies.

vFCC Statement on Class B

This equipment has been tested and complies with the

limits for a Class B digital device, pursuant to Part 15

of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference

when the equipment is operated in a residential installa-

tion. This equipment generates, uses, and can radiate

radio frequency energy and if not installed and used in

accordance with the instruction manual may cause

harmful interference to radio communications. How-

ever, there is no guarantee that interference will not

occur in a particular installation. If this equipment does

cause harmful interference to radio or television recep-

tion, which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the

interference by one or more of the following measures.

•Reorient or relocate the receiving antenna

•Increase the separation between the equipment and

the receiver

•Connect the equipment into an outlet on a circuit

different from that to which the receiver is

connected

•Consult the dealer or an experienced radio TV

technician for help

Notice:

1. The changes or modification not expressly approved

by the party responsible for compliance could void

the user’s authority to operate the equipment.

2. Shielded interface cables must be used in order to

comply with the emission limits.

v Table of Contentsv

Introduction ..............................................................................

Features and Specifications ................................................

Package Checklist ...............................................................

Installation Overview ...............................................................

Preparing the Area ..............................................................

Precautions in Handling the System Board .........................

Tips in Handling the System Board ..............................

Hardware Installation..........................................................

Memory Installation ......................................................

Installing the Modules ............................................

Board Configuration ......................................................

Jumper Settings for Display Type and PS/2

Mouse.....................................................................

PCI IDE Controller..................................................

Cache Memory .............................................................

CPU Installation............................................................

Jumper Settings for CPU .......................................

Installing Upgrade CPU..........................................

Built-in Ports ........................................................................

Serial Ports ...................................................................

Parallel Port ..................................................................

Floppy Disk Drive Connector ........................................

IDE Hard Disk Connector .............................................

PS/2 Mouse Port ..........................................................

Installing Expansion Cards .................................................

Installing the System Board ................................................

1-1

1-2

1-4

2-1

2-2

2-6

2-7

2-8

2-9

2-11

2-13

2-16

2-17

2-20

2-25

2-26

2-27

2-29

2-30

2-33

2-34

2-35

3-1

3-2

3-5

3-7

3-8

3-9

3-10

3-11

3-12

3-13

3-14

4-1

5-1

A-1

B-1

C-1

D-1

E-1

F-1

G-1

Initial Setup Program .............................................................

Award BIOS CMOS Setup Utilities ....................................

Standard CMOS Setup ................................................

BIOS Features Setup ..................................................

Chipset Features Setup ...............................................

Power Management Setup .........................................

PCI Configuration Setup ..............................................

Load BIOS Defaults .....................................................

Load Setup Defaults ....................................................

Password Setting .........................................................

IDE HDD Auto Detection .............................................

Save & Exit Setup .......................................................

Exit Without Saving ......................................................

IDE Device Drivers .................................................................

Troubleshooting Checklist ....................................................

Appendix A:Types of Modules .............................................

Appendix B:System Error Report ........................................

Appendix C:Memory & I/O Maps ..........................................

Appendix D:PCI I/O Pin Assignments .................................

Appendix E:ISA I/O Pin Assignments .................................

Appendix F:Connector Pin Assignments ...........................

Appendix G:Award BIOS Hard Disk Table ..........................

PCI/ISASystemBoard

vIntroduction

The G586VPM system board offers several advanced

features integrated into the system board. Its design is

based on the new Peripheral Component Interconnect

(PCI) local bus and Industry Standard Architecture

(ISA) standards.

The G586VPM supports a 320-pin Zero Insertion Force

(ZIF) CPU socket for PentiumTM processors running at

75MHz, 90MHz or 100MHz frequency. This ZIF socket

allows users to easily upgrade their CPUs. It also sup-

ports Flash EPROM for easy BIOS upgrades. Flash

EPROM is a memory chip for the storage of BIOS

which can be erased in bulk or modified using a soft-

ware utility.

The G586VPM is equipped with four PCI and four ISA

slots, of which one pair is shared.

Equipped with two built-in PCI IDE connectors, the

G586VPM system board can control four drives and

supports fast Mode 3 hard drives and hard drives larger

than 528MB under DOS. The system board is also

equipped with two NS16C550 serial ports, an ECP/EPP

parallel port, a floppy disk drive controller, and one

mini-DIN-6 connector for the PS/2 mouse.

The G586VPM can be configured to 22 different

memory sizes ranging from 4MB to 256MB using

256Kx36, 512Kx36, 1Mx36, 2Mx36, 4Mx36 and

8Mx36 SIM modules.

1-1 uIntroduction

G586VPM

Features and Specifications

Processor

•Intel’s PentiumTM 75/90/100MHz

OverDrive Pentium Processor

Chipset

•VLSI chipset

VL82C591 - system and cache controller

VL82C592 (2) - data buffer

VL82C593 - PCI bridge

Architecture

•PCI/ISA

Energy Efficient Design

•Supports 3.3V CPUs

•Supports system power management

•Supports CPU stopped clock

•Provides highly efficient 3.3V/5A Switching Power

Supply to CPU and chipsets

Power Management

•Three powersaving stages: Doze, Standby and

Suspend

•Microsoft APM supported

BIOS

•Award Plug & Play BIOS (Flash EPROM)

•Supports IDE HDDs larger than 528MB under DOS

(LBA mode only)

Cache Memory

•160-pin socket for cache module

•Supports 3.3V or 5V/3.3V asynchronous (burst)

SRAM

Introduction u1-2

PCI/ISASystemBoard

•Supports 3.3V or 5V/3.3V synchronous (burst) SRAM

•256K, 512K or 1MB direct map buffered write-through

cache

•Uses 256K, 512K or 1MB cache modules

•Supports 32 byte or 64 byte line size to allow the use

of optional cache-tag RAM size

Memory Onboard

•Up to 256MB

•Eight 72-pin SIMM sockets

•Supports single and/or double density SIMMs

•256Kx36, 512Kx36, 1Mx36, 2Mx36, 4Mx36 or

8Mx36 SIMMs

•Supports 60ns or 70ns fast page mode DRAM

PCI IDE Interface

•Supports two PCI IDE connectors controlling four

drives (e.g., 2 HDDs, 1 tape drive and 1 CD-ROM)

•Supports fast Mode 3 (Enhanced IDE) hard drives

•Uses NS PC87410 PCI IDE chipset

Super I/O Interface

•Uses NS PC87334 super I/O controller

•Two serial ports (NS16C550 compatible)

•One parallel port (with EPP and ECP support)

•Supports 360K, 720K, 1.2MB, 1.44MB and 2.88MB

floppy drives

Expansion Slots

•Three dedicated PCI slots

•One shared PCI/ISA slot

•Three dedicated 16-bit ISA slots

ZIF Socket

•One 320-pin ZIF socket (Intel Socket 5)

1-3 uIntroduction

G586VPM

Board Dimensions

•33cm (12.87") x 22cm (8.58")

Baby AT form factor

Package Parts List

The G586VPM package contains the following items:

•G586VPM system board

•G586VPM user’s manual

•Two IDE driver diskettes

•One 34-pin floppy disk drive cable

•Two 40-pin IDE hard disk cables

•One 25-pin printer port cable for chassis mounting

•One card-edge bracket with serial and mouse port

cables

If any of these items are missing or damaged, please

contact your dealer or sales representative for assistance.

Introduction u1-4

PCI/ISASystemBoard

vInstallation Overview

This chapter summarizes the steps in installing the

G586VPM system board into your system unit. It also

includes a description of the area in which you must

work and directions for memory installation. Before

installing the system board, obtain the memory you plan

to install. Please refer to the memory chart on pages 2-4

and 2-5 for the number and type of SIM modules

needed for the amount of memory you require.

Preparing the Area

Before unpacking the system board, make sure the

location you have selected is relatively free of dust and

static electricity. Excessive exposure to dust, static

electricity, direct sunlight, excessive humidity, extreme

cold and water can damage the system board. Avoid soft

surfaces such as beds and carpeted floors which can

hinder air circulation. These areas also attract static

electricity which can damage some circuits on your

system board.

Be sure that the power source has a properly grounded,

three-pronged socket. It is essential that the power

connection be properly grounded for correct functioning

of your system board. For further protection, we recom-

mend that you use a surge suppressor. This will protect

the system board from damage that may result from a

power surge on the line.

Move items that generate magnetic fields away from

your system board, since magnetic fields can also

damage your system board. Once you have selected the

ideal location, unpack the G586VPM system board

carefully.

2-1 uInstallation Overview

Andere Handbücher für G586VPM

Inhaltsverzeichnis

Andere DFI Hauptplatine Handbücher

DFI

DFI HR900-B Bedienungsanleitung

DFI

DFI NB30-EC Bedienungsanleitung

DFI

DFI KD300-H110 Bedienungsanleitung

DFI

DFI 586ITOX Bedienungsanleitung

DFI

DFI CS332-C246/Q370 Bedienungsanleitung

DFI

DFI Lanparty JR P45-T2RS Bedienungsanleitung

DFI

DFI Infinity NF650I Ultra Bedienungsanleitung

DFI

DFI CS632-Q370 Bedienungsanleitung

DFI

DFI G486VPB Bedienungsanleitung

DFI

DFI G5C100-B Bedienungsanleitung

DFI

DFI CS551 Bedienungsanleitung

DFI

DFI P5BV3+/e Bedienungsanleitung

DFI

DFI LanParty LT P35 Bedienungsanleitung

DFI

DFI CT132-BR Bedienungsanleitung

DFI

DFI WL171 Bedienungsanleitung

DFI

DFI CS630-H310 Bedienungsanleitung

DFI

DFI GH9A3 Bedienungsanleitung

DFI

DFI G5G100-P Bedienungsanleitung

DFI

DFI P5BTX/L Bedienungsanleitung

DFI

DFI CR101-D Bedienungsanleitung

DFI

DFI G586OPC Bedienungsanleitung

DFI

DFI MB630-CRM Bedienungsanleitung

DFI

DFI GIC88-B Bedienungsanleitung

DFI

DFI G586IPV Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
