DIAMOND VIEW DV156
Colour TFT LCD Monitor
15” (38.4 cm) LCD Panel Size
i
Table of Contents
1
1 Important Safety Instructions...........................................3
2
2 Features .............................................................................4
3
3 Unpacking the Monitor......................................................5
4
4 Hardware Installation ........................................................6
Audio Cable Installation ..................................................................7
5
5 Windows Software Installation.........................................8
Windows 95......................................................................................8
Windows 98......................................................................................8
Windows Millennium Edition (Windows Me) ..................................9
Windows 2000..................................................................................9
6
6 Setting the Display Resolution.......................................10
Choosing The Best Resolution .....................................................10
Supported Graphics Modes and Refresh Rate Selection ............11
7
7 Adjusting the Monitor .....................................................13
Picture Optimisation......................................................................13
Manual Picture Adjustment...........................................................13
8
8 Security Lock Installation ...............................................16
9
9 Frequently Asked Questions..........................................17
1
10
0 Specifications ..................................................................19
1
11
1 Service Contacts .............................................................21
Australia.........................................................................................21
New Zealand ..................................................................................22
ii
Copyright Notice
Copyright 2001, Mitsubishi Electric Australia Pty. Ltd. All rights reserved. No
part of this publication may be reproduced, transmitted, transcribed, stored in
a retrieval system or translated into any language or computer language, in
any form or by any means, electronic, mechanical, magnetic, optical,
chemical, manual or otherwise, without the prior written permission.
Disclaimer
Mitsubishi Electric Australia Pty. Ltd. makes no representations or
warranties, either expressed or implied, with respect to the contents hereof
and specifically disclaims any warranties, merchantability or fitness for any
particular purpose. Further, Mitsubishi Electric Australia reserves the right to
revise this publication and to make changes from time to time in the contents
hereof without obligation to notify any person of such revision or changes.
Diamond View is a registered trademark of Mitsubishi Electric Australia Pty. Ltd.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
All other trademarks remain the property of their respective owners.
Reference Information
For future reference, write the following information about your
monitor in the space below. The serial number is on the back of
the product or on the bottom of its stand.
Monitor Information
Product Name: Diamond View DV156
Serial Number:
Date of Purchase:
Dealer Information
Dealer:
Telephone
Number:
Address:
3
1
1
Important Safety
Instructions
Please read the following safety instructions before installing or cleaning
your Diamond View monitor:
1. Unplug the monitor’s power cable from the wall outlet before cleaning.
Do not use liquid or aerosol cleaners. Use a soft cloth to clean the
monitor housing and a tape to stick dust and fingerprints on the screen
panel.
2. Slots and openings on the back or top of the cabinet are provided for
ventilation. They must not be blocked or covered. This product should
never be placed near or over a radiator or other heat source, or in a
built-in installation unless proper ventilation is provided.
3. Never push objects of any kind, or spill liquid of any kind into this
product.
4. Do not attempt to service this product yourself as opening or removing
covers may expose you to dangerous voltages or other risks.
5. If any abnormal operation or accident (such as dropping the unit)
occurs, disconnect the monitor from the wall power outlet and contact
qualified service personnel.
6. Turn the audio volume control of the built-in speakers to minimum (0)
and turn the monitor off before connecting or disconnecting any audio
cable.
4
2
2
Features
Your Diamond View DV156 Monitor features:
♦XGA (1024 x 768 pixel) Resolution LCD Panel
♦High Brightness – 250 cd/m2
♦Very High Contrast Ratio –400:1
♦True Colour Display
With dithering support, Diamond View DV156 monitor enhances the
visual effect and offers you better image quality.
♦High Quality Ratiometric Expansion
With any resolution within the monitor’s specified range, your Diamond
View DV156 monitor can expand the image to full screen.
♦Auto Adjustment Function
The auto adjustment key automatically optimises the displayed image.
♦Plug and Play Compatibility wth MicrosoftWindows
♦Space Saving - only 186 mm deep
♦Light Weight - only 5.8 kg
♦Lower Power Consumption
36 W maximum during operation with audio.
♦Power Saving
Power management complies with VESA DPMS standard. When the
system is idle (in monitor off mode), the monitor automatically cuts its
power consumption to less than 5 W.
♦On Screen Display
Allows you to adjust all settings simply using on-screen menus.
♦Removable Stand with VESA Standard Mounting
♦Built-in Stereo Amplifier and Speakers
5
3
3
Unpacking the
Monitor
Please check that the following items are included with your monitor. If they
are missing or damaged, please contact your place of purchase immediately.
♦LCD monitor with attached signal cable
♦Power cord
♦User’s manual
♦Audio Cable
♦Utilities and Driver Floppy Diskette
Locate the model name and the serial number label on the back of your
monitor and write the details of the monitor and your place of purchase in the
space on page (ii) of this manual for future reference.
6
4
4
Hardware Installation
Your monitor is equipped with an automatic power supply with a voltage
range from 90 to 264 Volts AC at a frequency of 50 to 60 Hz. Make sure that
your local power supply is within the supported range. If you are unsure,
please contact your electricity supplier.
To install your Diamond View DV156 monitor:
1. Make sure that the power to the computer and the power to the monitor
are both turned off.
2. Connect the blue connector of the monitor’s VGA cable to the VGA
output of the computer‘s graphics card.
3. Connect the monitor‘s power cord to an AC power socket. Please make
sure, that you have easy access to the power socket so you can
disconnect the unit from the power socket should you need to.
VGA Signal Cable
Power Cable
7
Audio Cable Installation
1. Remove the rear cover and then take the base cover off.
2. Connect the stereo audio cable from the Audio output of you
r
sound card to the Audio Input of the monitor.
3. Replace the base cover and the rear cover.
8
5
5
Windows Software
Installation
To get best performance with Windows 95, 98, Millennium Edition or 2000
you should use the Windows driver supplied with your DV156 monitor.
Windows 95
The first time you start Windows after connecting your new monitor, the
system will detect it and automatically install the driver for Plug and Play
displays. To install the Diamond View DV156 driver and colour profile:
1. Insert the Diamond View LCD Monitor Utilities floppy disk into your
floppy disk drive.
2. Right-click on the Windows desktop and select Properties or open the
Control Panel and double-click Display.
3. From the Display Properties window, select the Settings tab and then
click the Advanced Properties button at the bottom, right corner.
4. Select the Monitor tab and then click the Change button.
5. Click the Have Disk button at the bottom right corner. The Install From
Disk window will appear with the floppy drive A:\ selected. Click OK.
6. Select DV156 from the list and click OK again to install the driver.
7. You will be returned to the Advanced Graphics Properties dialogue.
Close this window by clicking OK and confirm the subsequent messages
by clicking Yes. Click OK and then Yes once more.
8. The installation is now complete, click OK to close Display Properties.
Windows 98
The first time you start Windows with a new monitor, the system will detect it
and automatically start the Add New Hardware wizard.
1. Click the Next button. Select Search for the best driver for your device
(recommended) and click Next.
2. Insert the Diamond View LCD Monitor Utilities floppy disk into your
floppy disk drive. Select the Floppy disk drive check box and click
Next.
9
3. Click Next again and then click Continue. The driver and monitor colour
profile will be installed. Click Finish to complete the installation.
Windows Millennium Edition (Windows Me)
The first time you start Windows with a new monitor, the system will detect it
and automatically start the Add New Hardware wizard.
1. Insert the Diamond View LCD Monitor Utilities floppy disk into your
floppy disk drive. Select the Floppy disk drive check box and click
Next.
2. Select Search for the best driver for your device (recommended), tick the
Removable Media (Floppy, CD-ROM,…) and click Next.
3. Click Next again and then Finish to complete the installation.
Windows 2000
If the system will detects your DV156 monitor automatically and starts the
Add new hardware wizard, carry out these instructions beginning at step 7.
Otherwise, to install the monitor driver and ICC colour profile:
1. Click Start and then Settings and open the Control Panel.
2. Double click the Display icon.
3. From the Display Properties dialogue box, select the Settings tab.
Click the Advanced….button at the bottom, right corner.
4. Select Monitor then click Properties.
5. Select the Driver tab and click Update Driver.
6. The Upgrade Device Driver Wizard will pop start. Click Next.
7. Insert the Diamond View LCD Monitor Utilities disk into your floppy disk
drive.
8. Select Display a list of the known drivers for this device so that I
can choose a specific driver and click Next.
9. In the next window, click Have Disk. The Install From Disk dialogue
will open. The default drive is the floppy disk drive, A:\. Click OK.
10. Select the DV156 LCD monitor from the list and then click Next twice.
11. The Digital Signature Not Found window will appear. Click Yes and
then click Finish to complete the driver installation.
Inhaltsverzeichnis
Andere Diamond View Monitor Handbücher
Diamond View
Diamond View DV17NF Bedienungsanleitung
Diamond View
Diamond View DV65UM Bedienungsanleitung
Diamond View
Diamond View DV154 Bedienungsanleitung
Diamond View
Diamond View DV55RM5 Bedienungsanleitung
Diamond View
Diamond View DIAMOND VIEW DV181 Bedienungsanleitung
Diamond View
Diamond View DV150 Bedienungsanleitung
Diamond View
Diamond View DV172 Bedienungsanleitung
Diamond View
Diamond View DV150 Bedienungsanleitung
Diamond View
Diamond View DV158 Bedienungsanleitung
Diamond View
Diamond View DV100UM Bedienungsanleitung
Diamond View
Diamond View DV171 Bedienungsanleitung
Diamond View
Diamond View 2115E Bedienungsanleitung
Diamond View
Diamond View DV190 Bedienungsanleitung
Diamond View
Diamond View DV195 Bedienungsanleitung
Diamond View
Diamond View DV172 Bedienungsanleitung
Diamond View
Diamond View DIAMOND VIEW DV159 Bedienungsanleitung
Diamond View
Diamond View 1995SL Bedienungsanleitung
Diamond View
Diamond View DV75UM Bedienungsanleitung
Diamond View
Diamond View 1786FD Bedienungsanleitung
Diamond View
Diamond View 1998E Bedienungsanleitung
