Diamond Elite Series DE300.2 Bedienungsanleitung
10Hz-35KHz
DE600.1D/DE1200.1D
SPEAKER/POWER ENDPLATE
DE600.1D/DE1200.1D
SIGNAL ENDPLATE
DE300.2
SIGNAL/ENDPLATE
DE300.2
SPEAKER POWER ENDPLATE
7Remote Level Control - DE600.1D/1200.1D amplifer has this port is for the remote level control (included). The control is
intended to allow the user to control the level of gain up to the maximum adjustment level set on the amplifier. The control does not add
additional boost, it only attenuates the setting that is fixed at the amplifier’s control panel.
Power/OverLoad Protection System LED’s - These lights indicate when the amplifier is powered up normally
and when there is a protection fault. The “OPS” LED is illuminated when there is a problem with your amplifier. Please contact your authorized
Diamond Audio dealer or call our technical support.
1
9Variable Phase - This control gives the installer a unique feature that allows the variable adjusment of phase 0-180 degrees to
compensate for subwoofer placement. Allowing the subwoofer to sound like it’s placed in the front of the vehicle instead of the trunk.
