Diamond VS Bedienungsanleitung

Mod: NT22G-ALZ/VV

Production code: IR22 VS

02/2010



Reseller Stamp for

Warranty







DECLARATION OF CONFORMITY

In agreement with the LowVoltage Directive 2006/95 EEC, with the directive 2004/108 EEC (EMC9),with

thedirective 2006/42 EEC (machines), integratedbytheCEmark.

In agreement with Regulation (EC) No.1935/2004 of the European Parliament andof the Councilof27

October 2004 on materials andarticlesintended to come into contact with food.

Type of appliance / Machine KNEADING MACHINE

Trademark DIAMOND

Model

IF17-IF22-IF33-IF42–IF53

IFM7-IFM10-IFM17-IFM22-IFM33-IFM42-IFM53

IR17-IR22-IR33-IR42-IR53

IRM17-IRM22-IRM33-IRM42-IRM53

IF17VS-IF22VS-IF33VS-IF42VS-IF53VS

IR17VS-IR22VS-IR33VS-IR42VS-IR53VS

Manufacturer PIZZA GROUP S.r.l.

Address

Telephone

Telefax

The harmonised standards or technical specifications (designations) that have been applied in

agreement with the highest professional standards on safety in force in the EEC are:

Standards or other normative documents Test report - Technical data sheets

EN 60335-1 EN 60335-2-64 IMQ PRIMA CONTROL 58 CEEL 99

EN292 EN294 EN418 FLAM GAS

EN 55014 EN 61000-3-2 EN 61000-3-3

Otherinformation:

In my capacity as manufacturer and/or authorised representative of the company inside the EEC, I

hereby declare, under my own responsibility that the appliances conform to the essential

requirements of the aforementioned Directives.

San Vito al Tagliamento (PN) Bellotto Carlo

07.01.2010 President







The equipment is constructed and tested in accordance with

the safety regulations indicated in the reference European

directives.

This manual is for people who are going to install, use or

service the mixers in order to make the best use of the

product characteristics.

In the case of questions about the contents or for any other

clarification, contact the manufacturer or authorized

technical assistance centre, providing the number of the

section and topic needing clarification.

It is important to keep this manual with the machine, even if

it is moved elsewhere or is transferred to a new owner, so it

may be consulted whenever needed, using the information it

contains which is necessary to ensure working under safe

conditions.

In addition, the ownership of this document is reserved by

law, and it is prohibited to tamper with or translate its

contents by third parties without authorization.

The technical information, graphic representations and

specifications contained in this manual are not to be

distributed.

The manufacturer is not obliged to advise of any

subsequent changes to the product.







INDEX

1 INTRODUCTION

1.1 SYMBOLS

1.2 INTENDED USE

1.3 PURPOSE AND CONTENT OF THE MANUAL

1.4 CONSERVATION OF THIS MANUAL

1.5 MANUAL UPDATING

1.6 GENERAL INFORMATION

1.7 RELEVANT SAFETY AND ACCIDENT

PREVENTION REGULATIONS TO BE

ADHERED TO

1.8 LEGAL WARRANTY

1.9 MANUFACTURER LIABILITY

1.10 USER CHARACTERISTICS

1.11 TECHNICAL ASSISTANCE

1.12 SPARE PARTS

1.13 IDENTIFICATION PLATE

1.14 MIXER DELIVERY

2 SAFETY RECOMMENDATIONS

2.1 WARNINGS FOR THE INSTALLER

2.2 WARNINGS FOR THE USER

2.3 WARNINGS FOR THE MAINTENANCE

OPERATOR







3 HANDLING AND TRANSPORT

4 PREPARATION OF THE INSTALLATION

AREA

4.1 SAFETY PRECAUTIONS

4.2 MACHINE INSTALLATION LOCATION

5 INSTALLATION

5.1 MIXER LEVELLING

5.2 EQUIPMENT HOOK-UP

5.2.1 Electrical connection

5.2.1.1 Earth connection

6 MIXER START-UP AND USE

6.1 COMMAND PANEL DESCRIPTION

6.2 START-UP PHASE

6.3 WORKING PHASE

6.4 SAFETY DEVICES

6.5 SHUT-DOWN PHASE

7 MAINTENANCE AND CLEANING

7.1 SAFETY PRECAUTIONS

7.2 ORDINARY MAINTENANCE FOR THE USER

7.2.1 General cleaning

7.2.2 Upper chain tensioning

7.2.3 Greasing the chains







8 POSSIBLE FAULTS

9 INFORMATION FOR DEMOLITION AND

DISPOSAL

10 WIRING DIAGRAM

11 EXPLODED VIEW AND SPARE PARTS

LIST

12 TECHNICAL DATA







Dear customer,

Above all, thank you for choosing our product and we

would like to congratulate you on your selection.

In order to better use your new mixer, please carefully

read the information contained in this manual.

1 INTRODUCTION

The manufacturer reserves the right to change

technical specifications and features and/or functions

of the machine at any time without notice.

1.1 SYMBOLS

In this manual, important information is pointed out

using the following symbols:





INSTRUCTION: Instructions pertaining to correct use

of the mixer and those responsible for using the

machine.





WARNING: Signifies a particularly important point.

DANGER: Signifies important information about

practices for preventing accidents or material damage.

1.2 INTENDED USE

The mixer versions with a fixed head and bowl or with

removable head and tank were designed and







constructed exclusively for use in food sectors for

preparing dough made with grain flours, mainly for use

in pizzerias, bakeries and pastry shops.

The intended use described above and the machine

configurations are the only uses authorized by the

Manufacturer: do not use the machine in any way

that does not adhere to the provided instructions.

The intended use is valid only for equipment which is

in good structural, mechanical and engineering

condition.

1.3 PURPOSE AND CONTENTS OF THE MANUAL

Purpose:

The purpose of this manual is to allow the user to

operate the machine in compliance with all regulations

and to make use of the necessary materials for correct,

safe and long-term use.

Content:

This manual contains all the necessary information for

mixer installation, use and maintenance.

Scrupulous adherence to the information contained in

this manual guarantees high safety and productivity

levels of the mixer.

1.4 CONSERVATION OF THIS MANUAL

Conservation and consultation:

The manual must be conserved with care and must

always be available for consultation, both by the user







and by those responsible for assembly and

maintenance.

The User and Maintenance Manual is an integral

part of the machine.

Deterioration or loss:

If necessary, request another copy of the manual from

the manufacturer or dealer.

Transfer of the mixer:

If the mixer is to be transferred, the user is required to

deliver this manual to the purchaser.

1.5 MANUAL UPDATING

This manual reflects the state of the art of the machine

at the moment the machine is released on the market.

The machines that are already available on the

market, with their related technical documentation, will

not be considered to be lacking or inadequate following

possible modifications, adjustments or applications of

new technologies on newly marketed machines.

1.6 GENERAL INFORMATION

Information:

If exchanging information with the Manufacturer or the

Dealer regarding the mixer, please refer to the serial
