Digi Connect IT 16 Bedienungsanleitung

Digi Connect IT® 16/48

User Guide

Revision history—90002332

Revision Date Description

A July 2019 Initial release.

B September 2019 Added information for Remote Power

Management.

Additional edits.

Trademarks and copyright

Digi, Digi International, and the Digi logo are trademarks or registered trademarks in the United

States and other countries worldwide. All other trademarks mentioned in this document are the

property of their respective owners.

Disclaimers

Information in this document is subject to change without notice and does not represent a

commitment on the part of Digi International. Digi provides this document “as is,” without warranty of

any kind, expressed or implied, including, but not limited to, the implied warranties of fitness or

merchantability for a particular purpose. Digi may make improvements and/or changes in this manual

or in the product(s) and/or the program(s) described in this manual at any time.

Warranty

To view product warranty information, go to the following website:

www.digi.com/howtobuy/terms

Send comments

Documentation feedback: To provide feedback on this document, send your comments to

techcomm@digi.com.

Customer support

Digi Technical Support: Digi offers multiple technical support plans and service packages to help our

customers get the most out of their Digi product. For information on Technical Support plans and

pricing, contact us at +1 952.912.3444 or visit us at www.digi.com/support.

Digi Connect IT® 16/48 User Guide 2

Contents

Digi Connect IT® 16/48 User Guide

Connect IT 16 and 48 key features 6

Get started with Connect IT 16/48

Verify product components 8

Included equipment 8

Required additional equipment 9

Optional additional equipment 9

Optional equipment 10

Cellular ONLY: Insert the CORE module 10

Prerequisites 10

Connect the power supplies and fans 11

Optional: Connect SFP+ modules 12

Connect the hardware 12

Connect hardware and connect to site network using an Ethernet LAN 12

Connect hardware and connect to a cellular network 13

Connect equipment to the Connect IT serial ports

Serial connector pinout 14

Configure the Connect IT 16/48

Change a Connect IT password 16

Manage users and groups 16

Create a group 16

Configure an access control group 16

Create a user profile and assign an access control group 17

Configure two-factor authentication for a user 18

Update the firmware on the Connect IT 18

Update Connect IT firmware from the local web user interface 18

Update the firmware on Connect IT from Remote Manager 19

Download the Connect IT firmware to your PC 19

Configure authentication methods 19

Configure idle timeout 20

Update modem firmware from the local web user interface 20

Configure Remote Power Management 21

Configure the Connect IT to connect to a power controller 21

Digi Connect IT® 16/48 User Guide 3

Digi Connect IT® 16/48 User Guide 4

Create an access control group for power management and assign to users 23

View power controller status and manage power (Administrators) 24

Control the outlet power from a terminal (all users) 24

Configure a serial port 25

Configure the connection settings for a serial port 25

Monitor serial port changes 27

Enable a Telnet connection on the serial port 28

Enable a TCP connection on the serial port 29

Enable an SSH connection on the serial port 30

Configure a modem 31

Configure the modem 31

Define a custom APN list 34

Configure a custom gateway for the modem 35

Configure an IPv4 network interface for the modem 35

Configure an IPv6 network interface for the modem 36

Configure the network 37

Configure the Connect IT name from the local web user interface 38

Configure a VPN 39

Configure an IPsec tunnel for a VPN 39

Configure an OpenVPN server 39

Configure an IP tunnel for a VPN 40

Back up, restore, and delete the configuration 40

Back up the Connect IT configuration 41

Restore the Connect IT configuration 41

Delete the Connect IT configuration 41

Configure the firewall 41

Configure services 42

Monitor the data from the Connect IT 43

Reboot the Connect IT 43

Immediately reboot the Connect IT from the local web user interface 44

Immediately reboot the Connect IT from Remote Manager 44

Schedule a reboot from the local web user interface 44

Schedule system maintenance 45

Synchronize system time 46

View Connect IT status information 47

Download an archive of the supported MIBs 47

Download a support report file 47

Configure and view events and logs 48

View events information 48

Configure log messages 48

View system log information 49

Work with the web UI (web user interface)

Access a screen in the local web user interface or Remote Manager 50

Add an item 50

Access the Terminal screen 51

Access help 51

Save your changes 51

Manually configure PCto connect to the Connect IT 52

Digi Connect IT® 16/48 User Guide 5

Troubleshooting

Reset your device to the factory defaults 56

Tips for improving cellular signal strength 56

Download a support report 56

Hardware

Front panel and LEDs 57

Back panel and LEDs 59

Hardware specifications 61

Power supply 61

Electrical rating 61

Mounting options 62

Regulatory and safety information

Safety warnings 63

Power supply and supplemental fan module considerations 64

Information access 64

Digi Connect IT® 16/48 User Guide

This guide provides reference and usage information for the Connect IT 16/48.

The 16/48 provides out-of-band management for remote network or infrastructure devices. Cellular

connectivity, available as standard in some models and as an option in other models, provides fast

reliable cellular connections without additional equipment. All connections are encrypted for security.

Connect IT 16 and 48 key features

The Digi Connect IT 16/48 port products provide these key features:

nDual Gigabit Ethernet and Dual SFP+ option for robust flexible network connectivity.

nDevices with either 16 or 48 serial connections to manage IT assets via console port.

nOption to install Certified Digi Cellular CORE Module to support different cellular speeds with

modules certified for specific regions.

nSuperior network performance management through Digi Remote Manager® (DRM).

nGlobal Deployment support.

Digi Connect IT® 16/48 User Guide 6

Get started with Connect IT 16/48

This section explains what comes with each Connect IT model, how to install the necessary software,

and how to connect the hardware.

1. Verify product components.

2. Cellular ONLY: Insert the CORE module.

3. Connect the power supplies and fans.

4. Optional: Connect SFP+ modules.

5. Connect the hardware to a network.

6. Access the device from the web UI.

7. Update the firmware on the Connect IT from the web UI.

8. Change the password.

9. Administrators only: Additional configuration to the Connect IT can be done in Remote Manager

or in the Connect IT's local web user interface. See Configure the Connect IT 16/48.

10. Mount the Connect IT to a rack.

11. Connect equipment to the Connect IT serial ports.

Digi Connect IT® 16/48 User Guide 7

Get started with Connect IT 16/48 Verify product components

Digi Connect IT® 16/48 User Guide 8

Verify product components

Verify that you have the following included equipment.

Included equipment

Equipment Description

Digi

Connect IT

Digi

Connect IT

Note This image is of Connect IT 48. The Connect IT 16 has a blank panel instead of

ports 17 - 48.

For detailed information about the front and back panels, see Connect IT 16/48

hardware and LEDs.

Serial

adapter

DB9 female to RJ45 adapter.

Connects a DB9 serial port on a PC to the Connect IT 16/48 console port.

Ethernet

cable

8-wire straight-through shielded Cat5 Ethernet cable.

You can also choose to connect to the network with an Ethernet connection rather

than connecting to a cellular network. See Connect hardware and connect to site

network using an Ethernet LAN.

Label The label includes the MAC addresses of the device.

Get started with Connect IT 16/48 Verify product components

Digi Connect IT® 16/48 User Guide 9

Required additional equipment

Equipment Description

Power supply kit Each kit includes three items: two power supply items and one fan

item. These items are connected to the Connect IT 16/48. See

Connect the power supplies and fans.

You can choose between the following two kits:

nITPS-PSEK: Connect IT 16/48 power supply kit, port-side

exhaust. Use this when the serial ports will be in the hot

aisle. The thumb screws used to connect the items to the

Connect IT are blue.

nITPS-PSIK: Connect IT 16/48 power supply kit, port-side

intake. Use this when the serial ports will be in the cold

aisle. The thumb screws used to connect the items to the

Connect IT are red.

Power cord IEC 60320 power cord

Optional additional equipment

Equipment Description

COREmodule

Note This is required only if you want to connect to a cellular

network. A SIM card is also required.

SIMcard An activated SIM card provided by your cellular network operator.

You can insert up to two SIMcards in the CORE module. See

Connect hardware and connect to a cellular network.

The COREmodule supports the standard mini-SIM cards (2FF).

Note This is required only if you are using a COREmodule to

connect to a cellular network.

Get started with Connect IT 16/48 Cellular ONLY: Insert the CORE module

Digi Connect IT® 16/48 User Guide 10

Equipment Description

Antennas (2)

Optional equipment

Equipment Description

Power cord IEC 60320 power cord.

An additional power cord used for redundancy.

Cellular ONLY: Insert the CORE module

Note If you are connecting to a network using an Ethernet connection, you can skip this section. See

Connect hardware and connect to site network using an Ethernet LAN.

This section explains how to connect the COREmodule and cellular antennas to the Connect IT

hardware.

Prerequisites

nActivated SIM card from your cellular network provider.

nCORE module. This may be included with your device. If it is not, you must purchase one

separately.

To connect the hardware and connect to the cellular network:

1. Insert your activated SIM card into the COREmodule. The notched end of SIM card should be

inserted first, with the gold metal contacts facing down. You will hear a click once the SIM is

completely inserted.

Note If one SIM card is being used, insert the SIMcard into the SIM 1 slot.

2. Insert the COREmodule into the device.

a. Orient the device so the rear of the device is facing you.

b. Remove the COREmodule slot cover from the back of the device.

c. Insert the COREmodule into the slot. Make sure the pin holes on the back of the

module match the location of the pins in the slot.

d. Push the module into the slot.

e. Push the white handle down until you hear it click.

Andere Handbücher für Connect IT 16

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Digi Server Handbücher

Digi

Digi One IAP Haz Bedienungsanleitung

Digi

Digi PortServer II Bedienungsanleitung

Digi

Digi Connect EZ Mini Bedienungsanleitung

Digi

Digi Connect IT Mini Bedienungsanleitung

Digi

Digi PortServer TS 1 M MEI Bedienungsanleitung

Digi

Digi Passport 48 Bedienungsanleitung

Digi

Digi ConnectPort LTS Series Bedienungsanleitung

Digi

Digi DC-ES-4SB Bedienungsanleitung

Digi

Digi DIGI CONNECT ES Betriebshandbuch

Digi

Digi Connect Wi-SP Bedienungsanleitung

Digi

Digi Connect IT 4 Bedienungsanleitung

Digi

Digi PortServer TS 8 Bedienungsanleitung

Digi

Digi 1002 Handbuch

Digi

Digi PortServer TS Series Bedienungsanleitung

Digi

Digi opengear CONSOLE MANAGER 8100 Bedienungsanleitung

Digi

Digi One SP Bedienungsanleitung

Digi

Digi EL 2 Bedienungsanleitung

Digi

Digi Modem Digi One IA Bedienungsanleitung

Digi

Digi ConnectPort LTS 8 Installationshandbuch

Digi

Digi PortServer/8 Bedienungsanleitung

Digi

Digi Connect IT 16 Bedienungsanleitung

Digi

Digi LTS 32 Bedienungsanleitung

Digi

Digi ConnectPort LTS 8 Bedienungsanleitung

Digi

Digi ConnectPort TS 8 MEI Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung
