SKYROS SERIES
3 Megapixel Pan Tilt
POE IP Camera
DG-SC3800P
V2.0
2013-07-06
2
3
The following items should be present in your package
Network Pan/Tilt IP Camera
AC power adapter (12V DC, 2A)
Wall mounting Kit
Installation Guide CD(includes User Manual, QIG & Utility)
Patch Cord (1 No.)
Make sure that the package contains above items. If any of the listed
items is damaged or missing, please contact your retailer immediately.
Thank You for purchasing this high-resolution 3 Megapixel Pan/Tilt IP Camera!
DG-SC3800P IP Camera provides 3 Megapixel high-resolution video quality.
With the advanced megapixel lens, you can view images remotely in more
detail than conventional close-circuit cameras.
4
Ultra-high resolution 3 Mega pixel CMOS image sensor.
Full Pan / Tilt Control.
Digital input / output interface lets you connect peripherals such as external
alarm, sensor, etc.
Audio output interface/ inbuilt mike, lets you listen to voices from remote
places as well as speak to people in remote places.
Built-in SD-card slot for local storage, which can act like a stand-alone
DVR.
Two Way audio.
3GPP Mobile Surveillance Supported.
ONVIF Compliant.
The following system requirements are recommended
Windows XP, Vista and 7 operating systems (both 32 and 64 bits
version)
2GB of system memory (up to 16 IP cameras, VGA)
1GB of Display card memory
20GB of available hard disk space on system drive
5
After installing the IP camera, you can verify its status from the LED
indicators on the front panel as shown below.
Item No. Item Description
1 Light sensor Detects light level of the place
where this IP camera is installed.
2 IR LEDs Lights up when it’s too dark.
3 Focus ring If the image looks fuzzy, try to turn
this focus ring clockwise or
counter-clockwise to adjust focus
until the image looks clear.
4 Microphone Receives voice.
1
2
3
4
5
6
5 LED indicators There are 2 LED’s inside to
indicate the operation of this IP
camera:
Left: Network activity LED
On: Ethernet cable connected
Off: Ethernet cable
disconnected
Flash: Network Connectivity
Right: Power LED
On: IP camera is switched on
Off: IP camera is switched off
7
Item No. Item Description
1 Audio out Connects to external audio amplifier to output
voice. Use 3.5mm audio cable.
2 DC 12V Connects to DC power adapter output.
3 RESET When the IP camera is not functioning properly,
you can use a pen or similar object to press this
reset button to reset the IP camera. You can also
press and hold this button till the power LED
goes off, to clear all settings of IP camera,
including administrator password.
4 DI/DO
connectors Digital input / output dry contacts. Connects to
external peripherals by wire. See next page for
pin definitions.
WARNING: DO NOT CONNECT POWERED
CABLE.
1 2 3 4 5
6
8
5 ETHERNET
(PoE support) Connects to your local area network by Ethernet
cable.
Getting power from this Ethernet port if this
device connects to PoE switch.
6 SD card slot Insert SD card for video recording. Maximum
32GB of SDHC card supported.
DI/DO PIN ASSIGNMENT
Item Description
GND Signal ground
DO Digital Output #1
DI1 Digital Input #1
DI2 Digital Input #2
To insert or release a wire, press the button of the PIN you wish to insert or
release.
9
Camera Installation – Hardware
1. Fix the wall mounting metal plate ‘A’ on the wall, secure it by 4 screws at the
screw holes indicated by black arrows. You can fix it upside-down when
required.
10
2. Insert wall mounting metal plate ‘B’ into the slot at the bottom of this IP
camera by the direction indicated by black arrow.
3. Fix wall mounting metal plate ‘B’ by 2 screws.
