Digisol DG-WM2001WI Bedienungsanleitung

DG-WM2001WI User Manual

DG-WM2001WI

802.11N INDOOR CONTROLLER 2.4GHZ MANAGED INWALL

User Manual

V1.0

2015-07-27

As our products undergo continuous development the specifications are subject to change without prior notice

DG-WM2001WI User Manual

publication may be reproduced, transmitted, transcribed, stored in a retrieval system,

or translated into any language or computer language, in any form or by any means,

electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the

prior written permission of this company.

This company makes no representations or warranties, either expressed or implied,

with respect to the contents hereof and specifically disclaims any warranties,

merchantability or fitness for any particular purpose. Any software described in this

manual is sold or licensed "as is". Should the programs prove defective following their

purchase, the buyer (and not this company, its distributor, or its dealer) assumes the

entire cost of all necessary servicing, repair, and any incidental or consequential

damages resulting from any defect in the software. Further, this company reserves

the right to revise this publication and to make changes from time to time in the

contents thereof without obligation to notify any person of such revision or changes.

Trademarks:

DIGISOL™ is a trademark of Smartlink Network Systems Ltd. All other trademarks

are the property of the respective manufacturers.

Safety

This equipment is designed with the utmost care for the safety of those who install

and use it. However, special attention must be paid to the dangers of electric shock

and static electricity when working with electrical equipment. All guidelines of this and

of the computer manufacturer must therefore be allowed at all times to ensure the

safe use of the equipment.

DG-WM2001WI User Manual

Content

Chapter 1 Introduction.......................................................................... 6

1.1 Overview........................................................................................................ 6

1.2 Get Familiar with your new indoor Access Point................................6

1.3 Installation Precautions............................................................................. 7

1.4 Installation Environment Requirements................................................7

1.5 Equipment Accessories............................................................................. 7

1.6 Login Web Network Management........................................................... 8

1.7 Quit Web Network Management.............................................................. 9

1.8 Introduction to Page Layout of Web Network Management............ 9

1.9 Introduction to Web Network Management Function......................10

1.10 Introduction to Common Controls of Web Page............................ 12

1.11 Usage Restriction of Web Network Management........................... 12

Chapter 2 Basic Configuration......................................................... 13

2.1 Detailed Explanation of settings........................................................... 14

2.1.1 Description of this Access Point...................................................................14

2.1.2 Device Information............................................................................................ 14

2.1.3 Administrator Password.................................................................................. 15

2.1.4 Serial Settings.................................................................................................... 15

2.1.5 System Settings................................................................................................. 15

Chapter 3 Current Status................................................................... 16

3.1 Network Information................................................................................. 16

3.1.1 Wired Settings.................................................................................................... 16

3.1.2 Wireless Settings............................................................................................... 18

3.2 Statistic for Transmitting and Receiving IP Traffic...........................19

3.2.1 Device Information Status...............................................................................19

3.2.2 Transmit/Receive Packets............................................................................... 20

DG-WM2001WI User Manual

3.3 Client Associations................................................................................... 21

Chapter 4 Advance Configuration................................................... 23

4.1 Ethernet Settings.......................................................................................23

4.2 Wireless Settings.......................................................................................25

4.3 RF Parameters............................................................................................26

4.4 Virtual AP..................................................................................................... 28

4.4.1 None Security Configuration..........................................................................29

4.4.2 Static WEP Security Configuration...............................................................30

4.4.3 WPA Personal Security Configuration.........................................................31

4.4.4 WPA Enterprise Security Configuration......................................................32

4.4.5 WDS....................................................................................................................... 33

4.5 AP Modes.....................................................................................................34

Chapter 5 System Maintenance....................................................... 36

5.1 Configuration Management.................................................................... 36

5.2 Firmware Upgradation............................................................................. 38

Chapter 6 Configuration Examples.................................................40

6.1 Laws Wireless Access............................................................................. 40

6.1.1 Networking Requirements.............................................................................. 40

6.1.2 Configuration Steps.......................................................................................... 40

6.1.3 Test the Configuration Results...................................................................... 41

6.2 Cipher Wireless Access of Static-WEP(Open-System)................... 41

6.2.1 Networking Requirements.............................................................................. 41

6.2.2 Configuration Steps.......................................................................................... 42

6.2.3 Test the Configuration Results...................................................................... 43

6.3 WPA2-PSK Wireless Access...................................................................44

6.3.1 Networking Requirements.............................................................................. 44

6.3.2 Configuration Steps.......................................................................................... 44

DG-WM2001WI User Manual

6.3.3 Test the Configuration Results...................................................................... 45

6.4 WPA2-Enterprise Wireless Access....................................................... 46

6.4.1 Networking Requirements.............................................................................. 46

6.4.2 Configuration Steps.......................................................................................... 46

6.4.3 Test the Configuration Results...................................................................... 48

DG-WM2001WI User Manual

Chapter 1 Introduction

1.1 Overview

For the network administrator to configure and maintain to devices, this device provides

WEB network management function. The administrator can use WEB interface to manage

and maintain the network devices visually.

The running environment of Web network management is shown in fig 1-1.

Fig 1-1 Web The running environment of Web network management

1.2 Get Familiar with your new indoor Access Point

DG-WM2001WI User Manual

1.3 Installation Precautions

Only allow the professionals installing and disassembling the device and its annex. Before

the installation and configuration, please read the related security introduction carefully.

Adopt the appropriate security measures to avoid the personal injury and

equipment damage.

Please put the device on the dry and flat place and ensure the anti-skid

measures.

Keep the device clean without dirt.

Do not place the device on a wet place and avoid the device touching any liquids.

Do not put the device and the installation tools in the walking area.

1.4 Installation Environment Requirements

Before the installation, please check the installation conditions of the device to make sure

that the device is in good operating environment for a long time. Check this with the

following aspects:

The temperature and humidity environment requirements of the device are as below:

Table 1- 1 The temperature and humidity index

Items

Range

Standard working environment temperature (indoor)

-10℃～55℃

Storage temperature

-40℃～70℃

Working humidity (non-condensing)

5%～95%

1.5 Equipment Accessories

Please refer to the packing list.

DG-WM2001WI User Manual

Package Contents

Before you start using this AC, please check if there’s anything missing in the package,

and contact your dealer of purchase to claim for missing items:

DG-WM2001WI (1 No.)

screws ( 2 Nos.)

1.6 Login Web Network Management

User can use the default information directly to login the web interface of the device.

The default Web login information includes:

User name: admin

Password: admin

IP address of the device: 192.168.1.10

The steps of web login:

(1) Connect the device to PC.

Use the cable to connect PC to the Ethernet interface of the device.

(2) Configure the IP address for PC and ensure that it can communicate with the device.

For example: Modify the IP address to 192.168.1.0/24.

(3) Launch the browser and input the login information.

Launch the browser on PC, and input “http://192.168.1.10” in the address bar and then

enter it. Enter into the web login page as shown in fig 1-7. Input the user name as admin

and password as admin, click “login” to login.

DG-WM2001WI User Manual

Fig 1-7 Web network management login page

1.7 Quit Web Network Management

Click the “log off” button on the upper right corner on the Web network management page

to quit.

1.8 Introduction to Page Layout of Web Network

Management

Web network management page includes: navigation bar, configuration area and help

area as shown in fig 1-8.

DG-WM2001WI User Manual

Fig 1-8 Initial page of Web network management

Navigation bar: Organize the Web network management menu by using the navigation

tree. User can choose the function menu in the navigation bar and the result will be shown

in the configuration area.

Configuration area: User can configure and check.

Help area: It provides the basic help information. The “more” button can check more help

information. And it provides the “log off” button to quit.

1.9 Introduction to Web Network Management

Function

The Web network management function explanation is given below in table 1-10:

Table 1-10 Web network management function explanation
