Dimplex DCPF40C Bedienungsanleitung

DCPF40C

40cm High Velocity

Pedestal Fan

www.dimplex.com.au

INSTRUCTION MANUAL

PLEASE READ THE INSTRUCTION MANUAL CAREFULLY BEFORE USING THE UNIT.

www.dimplex.com.au

CONTENTS

WARNINGS AND PRECAUTIONS 1

STRUCTURE 3

OPERATION 4

CLEANING AND MAINTENANCE 6

TECHNICAL REFERENCE DATA 8

WARRANTY 8

Warnings

• Never place the unit near gas appliances, ames or

• Flammable liquids.

• Never hit or shake the unit. Doing so may cause damage.

• Never cover or obstruct the air inlet or outlet.

• Doing so may cause overheating.

• Never spray water on or place the unit near water.

• Doing so may cause electric shock.

• Never connect other appliances to the same power outlet.

• Never connect or disconnect the power plug with wet hands.

• Doing so may cause electric shock.

• Never insert ngers or objects through the guards when the unit is

operating.

• Never use an extension cord.

• Always have a professional technician, manufacturer or service agent

replace a damaged power cord.

Precautions

• This appliance is for indoor use only.

• Do not use the unit near windows or where water collects. Rain and

water collection may lead to a risk of re or electric shock.

• Do not place the unit in a damp place or where humidity is high (such

as a bathroom).

• Do not leave the unit operating while unattended.

• Do not place the unit in direct sunlight to avoid surface discolouration.

WARNINGS & PRECAUTIONS

• This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for

their safety.

• Children should be supervised to ensure they do not play with the

appliance.

• Avoid electromagnetic interference. Keep the unit at least 1 metre away

from electric appliances such as televisions and radios.

• Avoid scratching and damaging the surface. Do not use chemical

solvents (i.e. Benzene, alcohol) to clean the surface.

• Place the unit on a stable surface when operating.

• Unplug the unit before cleaning, servicing or maintenance.

• Electrical connections must be in accordance with National or

• Local Codes.

• The rear of the unit must be at least 50cm away from the wall.

• If the supply cord is damaged, it must be replaced by the manufacturer,

its service agent or similarly qualied persons in order to avoid a hazard.

WARNINGS & PRECAUTIONS

1. Front grille

2. Blade locking cap

3. Blade

4. Guard knob

5. Rear grille

6. Motor shaft

7. Rotary switch

8. Oscillation knob

9. Motor housing

10. Power cord & plug

11. Fixing screw A

12. Upper pillar

13. Fixing screw B

14. Main pillar

15. Base

16. Pole xing nut

17. Safety screw

STRUCTURE

OPERATION

BEFORE FIRST USE

•

Please read these instructions carefully before use and keep them for

future reference.

•

Check your local main voltage whether it is the same as stated on the

appliance.

•

Before using for the rst time, remove any protective lms or stickers

from the appliance and ensure the power switch is in the “0” position.

ASSEMBLY

Remove the pole xing nut (16) from the main pillar (14) and insert the

main pillar (14) into the base (15) then tighten the xing nut (16).

Release xing screw B (13) and adjust height to a suitable length. Re-

tighten the xing screw B once ready.

Release the xing screw A (11), connect the motor housing with the

upper pillar (12), fasten it with the xing screw A (11).

Remove the blade locking cap (2) and the guard knob (4) from the

motor shaft (6), secure the rear guard (5) on the motor housing (9) to

line up with the three xing pins, fasten the guard with the guard knob

(4).

Put the blade (3) on the motor shaft (6) and tighten with the blade

locking cap (2).

Attach the front guard (1) to the rear guard (5), and close the guard

xing clips, nally fastening with the safety screw (17).

OPERATION

Connect the plug to a power supply and switch on the power.

On/Off

• Switch the fan on by rotating the speed control knob (7) at the rear in

clockwise direction. The switch is also used to adjust the fan speed

from LOW ”1” – MEDIUM ”2” - HIGH ”3” in sequence.

• The airow direction can be adjusted upward/downward by lifting up

or pressing down the motor housing. NOTE: Only adjust the fan head

when the unit is OFF. Be careful not to insert your ngers through the

guard.

• Push the oscillating knob (8) down to start oscillation. Pull the

oscillation knob up to stop oscillation.

• Turn the switch anti-clockwise to the “0” position to turn the fan OFF.

Speed

• Turn speed control knob (7) to adjust the fan speed from LOW ”1” –

MEDIUM ”2” - HIGH ”3” in sequence. Turn the switch anti-clockwise

to the “0” position to turn OFF.

CLEANING & MAINTENANCE

CLEANING

Over time, dust can accumulate on the rear grille cover and fan blades,

which can affect the fans performance. It is recommended to clean the fan

at least once a month.

1. Turn the unit OFF and disconnect the appliance from the main power

supply.

2. Remove any dust build up with a soft brush.

3. Wipe the surface of the unit with a soft damp cloth. Mild detergent can

be used for any stubborn marks.

4. Do not allow the motor or other electrical parts to come in contact with

water.

5. Do not use abrasive sponges, scouring pads, or a stiff brush to clean

the appliance.

6. When the fan is not being used for long periods, it’s recommended to

store the fan in its original box in a low humidity environment.

IMPORTANT

The control panel and other parts must not come into contact with water or

any other liquids.

• Do not dispose of electrical appliances as unsorted municipal waste.

• Use separate collection facilities.

• Contact your local government for information regarding the collection

systems available.

TECHNICAL & REFERENCE DATA

WARRANTY

The warranty period is 12 months from the date of purchase. For service

advice, please contact the Customer Care Centre on 1300 556 816 (AU) /

0800 666 2824 (NZ).

Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd

1340 Ferntree Gully Road, 38 Harris Road, East Tamaki,

Scoresby 3179, Victoria Auckland 2013

Australia New Zealand

Ph: 1300 556 816 Ph: 0800 666 2824

MODEL NO. DCPF40C

Rated Power 60W

Voltage/Frequency 220-240V/50Hz

Net Weight 5.6kg

Dimensions Body (HxWxDmm) 1250 x 450 x 410

Dimensions Packaging (HxWxDmm) 587 x 470 x 130

RCM

5336

• If electrical appliances are disposed of in landlls or dumps, hazardous

substances can leak into the ground water, polluting the food chain and

damaging health and well-being.

MAINTENANCE

If the unit fails to operate efciently, is broken or other problems arise,

unplug and do not operate. Ask for advice by calling your local after sales

service agent or the Customer Care Centre on 1300 556 816 (AU) / 0800

666 2824 (NZ).
