Dish Network 40.0 Bedienungsanleitung

Remote User Guide

Safety Instructions

You must keep safety in mind while using this device. Keep

these and any other instructions for future reference.

Observe Warnings: Carefully follow all warnings on the device

and in the operating instructions.

Heat: Do NOT place the device near heat sources such as

radiators, stoves, heat registers, or other appliances that

produce heat.

Care and Use

Cleaning: Do NOT use liquid, abrasive, solvent, or aerosol

cleaners. Use a damp cloth for cleaning.

When Not in Use: Remove the batteries if this device is to be

left unattended or unused for a long period of time.

Refer servicing to qualied personnel when a

solid object or liquid has fallen onto or into the

device.

Do NOT attempt to service this device. Refer all

servicing to qualied personnel. Opening covers

other than the battery cover will void the warranty.

Publishing Information

The information in this User Guide may change without notice.

Revisions may be issued to tell you about such changes.

Send comments or questions about this User Guide to

techpubs@echostar.com or

Technical Publications, EchoStar Technologies L.L.C,

90 Inverness Drive Circle East, Englewood, Colorado 80112.

Document Number: 188891

Printed in

DISH Network is a registered trademark of

DISH Network L.L.C.

All product names, trade names, or corporate names

mentioned in this User Guide are acknowledged to be the

proprietary property of the registered owners.

Conguring the 40.0 Remote

Conrm your remote has the

green number 1 key installed.

Pull the remote battery cover off.

If your remote has a blank,

black key, continue to Insert the

Batteries on page 2.

Separate the key from the

remote by inserting your

thumbnail or a coin in the crease.

Remove the key by grasping at

the bottom.

Insert the key face up and slide

into place.

Note: If you are using the green TV1 key that comes

installed in your remote, skip these steps. Go to Insert

the Batteries (page 2).

Insert the Batteries

Pull the remote battery cover

off.

Insert 4 AAA batteries,

making sure to match the

plus (+) ends with the plus

markings on the battery case.

Replace the remote battery

cover.

Using System Wizard

Use System Wizard initially to set up the remote

to work with the receiver. System Wizard can also

store/restore the settings for your XiP system in both

your remote control’s memory and on the receiver.

This feature is helpful if you ever need to program a

replacement remote or a new system.

Note: If your batteries are low, replace them before

beginning.

Press and hold 0 until

System Wizard message

appears. Make sure the

remote and receiver are in

line of sight.

Or, Press MENU, select

Remote Control, and then

select System Wizard.

If rst time in System

Wizard, follow instructions

provided.

Follow the on-screen

options to Backup or

Restore setting for your

XiP system and remote

control settings.

Select Continue to return

to your paid programming.

Linking Remote to Receiver

Verify the antenna

is installed on the back

of the receiver.

Turn your receiver and

TV on, and press

SYSTEM INFO on the

front panel of the receiver.

Conrm that you

see the System

Info screen.

Press and release SAT

on your remote. Wait until

you hear a tone and see

the remote listed on the

screen.

Conrm that your remote

operates your receiver by

pressing remote buttons.

If this is not working, go

back to step 4.

Use these instructions

to link the remote

to the receiver if

your receiver does

not support System

Wizard.

REMOTE

ANTENNA

SYSTEM

INFO

SAT Mode

To use the features described in this section, make sure you

are in SAT mode by pressing the SAT Mode button.

Note: Some features may not be available depending on your

receiver model.

SAT

Power & TV Power

Top button turns the receiver on/off

Bottom button turns the TV on/off

Volume and

Mute Buttons

Control TV

volume

Programming

required

Recall

Return to last TV

channel viewed

Picture-In-

Picture (PIP)

Buttons

Watch two

separate

programs at

same time (in

Single Mode)

Number Buttons

Enter a channel

number or navigate

through menus

Access receiver

features and

settings

Pair/Input

Press once for

Input. Press and

hold for Pair

Themes

Search for

programs

using Themes

Info

Retrieve info

on programs

Search for a

program

Shortcut Keys

Access

frequently

used features

Digital Video

Recorder (DVR)

Buttons

Pause live TV and

play or record

programming

Format

Format the

picture to the

desired width

to match the

program you

are viewing

System Wizard

Press and hold to

x remote control

issues and sync

data

Arrow/Select

Buttons

Channel up/down,

navigate through

menus, and select

a desired option

View Satellite

Programming

Exit out of any

menu/guide and

return to viewing

live TV

Cancel

Return to previous

menu or to watch

a program

Browse

See what is on

other channels

while watching TV

Program Guide

Display current

and future satellite

program listings

Page Buttons

Page up/down

in menus

Press this

button for

SAT Mode

Dish OnDemand

Explore interactive

TV features

TV Mode TV

To use the features described in this section, make sure

you are in TV mode by pressing the TV Mode button.

Remote programming is required. Note: Some features

may not be available depending on your receiver model.

Note: Remote operation is different on DISH Network TVs.

See your DISH Network TV User’s Guide for proper operation.

Power & TV Power

Top button turns

the TV on/off

Bottom button

turns the TV on/off

Press this button

for TV Mode

Mute

Turn TV volume

on or off

Recall

Return to last TV

channel viewed

Picture-In-Picture

(PIP) Buttons

Watch two separate

programs at same

time (in Single

Mode)

Number

Buttons

Enter a channel

number or

navigate

through menus

TV Menu

Access menu

features available

on some TVs

Pair/Input

Switch between

TV inputs

(available only for

certain makes and

models of TVs)

Up/Down

Arrow Button

Channel up/

down on the TV

Volume

Control TV

volume

Select Button

Select a program

or menu

DVD Mode DVD

Power & TV Power

Top button turns the

DVD/VCR/BD on/off

Bottom button

turns the TV on/off

Number Buttons

Enter a channel

number or

navigate through

menus

Pair/Input

Press once

for Input

Press and

hold for Pair View Satellite

Programming

Exit out of any

menu/guide

and return to

viewing live TV

Press this button

for DVD Mode

FWD

Forward a

videotape or

DVD

Play

Play a videotape

or DVD

Pause

Pause a

videotape or

DVD

Back

Rewind a

videotape

or reverse a

DVD

Stop

Stop playing

a DVD, stop

playing or

recording a

videotape

Record

Record on a

videotape

To use the features described in this section, make sure you

are in DVD mode by pressing the DVD Mode button. You

can use this mode to operate a Blu-ray disc player or VCR.

Remote programming is required. Note: Some features

may not be available depending on your receiver model.

DVR Functions

• Press twice to go to the list of recorded

programs.

• Plays a live or recorded program.

• Pauses a live or recorded program.

• Stops recording a program.

• Records a program.

• Press BACK once to reverse the program

four times as fast as normal play. Press

BACK twice to reverse at 15 times normal

speed, three times to reverse at 60 times

normal speed, and four times to reverse

at 300 times normal speed. The on-

screen bar shows how far you’ve gone.

For a live program, you can only reverse

back to the last channel change or back

one hour, whichever occurs rst.

• Press SKIP BACK to skip back about 10

seconds in a program.

• Press FWD (Forward) once to fast-

forward through the program four times

normal speed. Press FWD twice to

forward at 15 times normal speed, three

times to forward at 60 times normal

speed, and four times to forward at 300

times normal speed. The on-screen bar

shows how far you’ve gone. Of course,

you cannot forward into the part of a

live program that has not been broadcast.
