Dometic REFRIGERATION 10-Series Bedienungsanleitung

RMD10.5XS

Absorption refrigerator

Installation Manual

REFRIGERATION

10-SERIES

DometicRMD10_INM_4445103186_APAC(en)_2020_xx-xx.book Seite 1 Mittwoch, 28. Oktober 2020 9:57 09

protected by copyright and design law. The underlying technical design and the

products contained herein may be protected by design, patent or be patent

pending. The trademarks mentioned in this manual belong to Dometic Sweden AB.

All rights are reserved.

DometicRMD10_INM_4445103186_APAC(en)_2020_xx-xx.book Seite 2 Mittwoch, 28. Oktober 2020 9:57 09

RMD10.5XS

Please carefully read and follow all instructions, guidelines and warnings included in this product manual in order to ensure that you install,

use and maintain the product properly at all times.

By using the product, you hereby confirm that you have read this disclaimer, all instructions, guidelines and warnings carefully and that you

understand and agree to abide by the terms and conditions as set forth herein.

You agree to use this product only for the intended purpose and application and in accordance with the instructions, guidelines and warnings

as set forth in this product manual as well as in accordance with all applicable laws and regulations.

A failure to read and follow the instructions and warnings set forth herein may result in an injury to yourself andothers, damage to your product

or damage to other property in the vicinity.

Dometic accepts no liability for any loss, damage or injury incurred, directly or indirectly, from the installation, use or maintenance of the

product not in compliance with the instructions and warnings in the product manual.

This product manual, including the instructions, guidelines and warnings, and related documentation may be subject to changes and

updates. For up-to-date product information, please visit: documents.dometic.com, dometic.com.

Table of contents

1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

6 Installing the refrigerator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

7 Connecting the refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

8 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

NOTE

You can find details on the operation in the operating manual.

DometicRMD10_INM_4445103186_APAC(en)_2020_xx-xx.book Seite 3 Mittwoch, 28. Oktober 2020 9:57 09

Explanation of symbols RMD10.5XS

1 Explanation of symbols

2 Safety instructions

The manufacturer accepts no liability for damage in the following cases:

• Faulty assembly or connection

• Damage to the product resulting from mechanical influences and incorrect

connection voltage

• Alterations to the product without express permission from the manufacturer

• Use for purposes other than those described in the operating manual

!WARNING!

• The electrical installation must comply with national and local

regulations including AS/NZS 3001 – Electrical installations.

• The gas installation must comply with national and local regulations

including AS/NZS 5601.2 – Gas installations.

• Never open the absorber unit. It is under high pressure and can cause

injury if it is opened.

• Ensure clean and residue-free handling if silicone sealant or similar is

used. There is a risk of fire if silicone filaments come into contact with

hot parts or naked flames.

• Do not operate the refrigerator if it is visibly damaged.

WARNING!

Safety instruction: Indicates a hazardous situation that, if not avoided,

could result in death or serious injury.

CAUTION!

Safety instruction: Indicates a hazardous situation that, if not avoided,

could result in minor or moderate injury.

NOTICE!

Indicates a situation that, if not avoided, can result in property damage.

NOTE

Supplementary information for operating the product.

DometicRMD10_INM_4445103186_APAC(en)_2020_xx-xx.book Seite 4 Mittwoch, 28. Oktober 2020 9:57 09

RMD10.5XS Safety instructions

• If the AC power cable for this refrigerator is damaged, it must be

replaced by the manufacturer, service agent or a similarly qualified

person in order to prevent safety hazards.

• Never use a naked flame to check the refrigerator for leaks.

• This refrigerator may only be repaired by qualified personnel.

Inadequate repairs may cause serious hazards.

• Only use universal LPG gas.

•Only operate the refrigerator at the pressure shown on the type

plate. Only use pressure controllers with a fixed setting which comply

with national regulations.

• Dismantle all refrigerator doors for the disposal of the old refrigerator

and leave the shelves in the refrigerator to prevent accidental enclo-

sure and suffocation.

!CAUTION!

• Danger of crushing! Do not put your fingers into the hinge.

• Before starting the device, ensure that the power supply line and the

plug are dry.

ANOTICE!

• Only hold the refrigerator at its body during transport. Never hold the

refrigerator at the absorber unit, the cooling fins, the gas pipes, the

door or the control panel.

• Make sure that the refrigerator circuit is not damaged during transpor-

tation. The refrigerant in the refrigerator circuit is highly flammable.

In the event of any damage to the refrigerator circuit (smell of ammo-

nia):

– Switch off the refrigerator if applicable.

– Avoid naked flames and sparks.

– Air the room well.

• Do not install the refrigerator near naked flames or other heat sources

(heaters, direct sunlight, gas ovens etc.).

•Risk of overheating!

Always ensure sufficient ventilation so that the heat generated during

operation can dissipate. Make sure that the refrigerator is sufficiently

far away from walls and other objects so that the air can circulate.

• Check that the voltage specification on the type plate is the same as

that of the power supply.

• Do not open the refrigerant circuit under any circumstances.

DometicRMD10_INM_4445103186_APAC(en)_2020_xx-xx.book Seite 5 Mittwoch, 28. Oktober 2020 9:57 09

Scope of delivery RMD10.5XS

• Only use the AC connection cable supplied to connect the

refrigerator to the AC mains.

• Only use cables with a suitable size (see chapter “DC power” on

page 28).

• Never pull the plug out of the socket by the connection cable.

• The refrigerator must not be exposed to rain.

3Scopeofdelivery

4Accessories

Available as accessories (not included in the scope of delivery):

All the accessories are available from specialist dealers. If you have any questions,

please contact the dealer or your service partner directly.

Quantity Description

1 Refrigerator

1 Drain hose

1 Sealing strip (fitted during installation)

1 Installation, Operating Manual and Quick Start Guide

Description

Dometic gas flue kit 3776

Dometic Roof Vent Kit

LS 300 ventilation grille

DometicRMD10_INM_4445103186_APAC(en)_2020_xx-xx.book Seite 6 Mittwoch, 28. Oktober 2020 9:57 09

RMD10.5XS Intended use

5 Intended use

The device is suitable for:

• Installation in caravans and motor homes

• Providing refrigeration, freezer and storage space for food

The device is not suitable for:

• Storing medications

• Storing corrosive substances or substances that contain solvents

• Freezing previously unfrozen food

This product is only suitable for the intended purpose and application in accordance

with this instruction. Any other use, deviating from the intended use, is not allowed!

Dometic accepts no liability for any loss, damage or injury incurred, directly or

indirectly due to other as the intended use.

6 Installing the refrigerator

You find the instructions manual for changing the door lock

and the decorative plate online at:

documents.dometic.com/?object_id=63258

The device is suitable for installation in:

• caravans

• motor homes

CAUTION! – Health hazard!

Please check if the cooling capacity of the refrigerator is suitable for

storing the food you wish to cool.

DometicRMD10_INM_4445103186_APAC(en)_2020_xx-xx.book Seite 7 Mittwoch, 28. Oktober 2020 9:57 09

Installing the refrigerator RMD10.5XS

6.1 Preparing the installation

When installing the refrigerator, note the following:

• To enable the refrigerant to circulate properly, the refrigerator may not exceed an

angle of 3 °.

Park the vehicle horizontally for this purpose.

• The refrigerator must be installed in a way that the following requirements are

met:

– The refirigerator must be easily accessible for service work.

– It must be easy to install and uninstall the refrigerator.

– It must be easy to remove the refrigerator from the vehicle.

NOTICE!

• The refrigerator may not be installed in the rear of motor homes with

the door pointing in the direction of travel.

• Use exclusively original Dometic ventilation grills to ensure safe

operation.

DometicRMD10_INM_4445103186_APAC(en)_2020_xx-xx.book Seite 8 Mittwoch, 28. Oktober 2020 9:57 09

RMD10.5XS Installing the refrigerator

• The refrigerator must be installed in a recess so that it stands secure when the

vehicle is in motion. Note the dimensions in fig. 1for this purpose.

Refrigerator Overall dimension with flange in mm

Height (A) 1260

Width (B) 550

Depth (C)615

Recess Dimension in mm

Height (H) 1246 – 1251

Width (W) 526 – 531

Depth (D) 571 – 586

DometicRMD10_INM_4445103186_APAC(en)_2020_xx-xx.book Seite 9 Mittwoch, 28. Oktober 2020 9:57 09

Installing the refrigerator RMD10.5XS

• The outer wall must be fitted with one air inlet ventilation grille (fig. 23a,

page 9) and one outlet ventilation grille (fig. 23b. page 9) so that the heat

generated can be easily released to the outside:

– Upper air outlet vent LS300 must be installed with the bottom of the vent no

lower than the top of the refrigerator cabinet.

– Lower air inlet vent LS300 must be installed with the lowest opening of the

grill flush with the floor of the refrigerator.

• If the lower ventilation grille of the air inlet vent cannot be installed flush to the

floor, a gas escape hole (fig. 27, page 9) must be provided in the floor for

releasing any possible gas leakage (see chapter “Making air inlet and outlet

vents” on page 15).

• Fit an air deflection plate (fig. 26, page 9) above the condenser so that the heat

does not accumulate in the vehicle.

• Put insulation wool (fig. 21,page 9) on top and sides of the cabinet.

Pos. in fig. 2Description

1 Insulation wool on top and sides of cabinet

2 Clearance minimum 10 mm to maximum 25 mm

3a/3b LS300 ventilation grille

4 Recommended height is at least equal to the height of the refrigerator

5 Dometic gas flue kit 3776

6 Air deflection plate

7 Gas escape hole, min. 40 mm – required if lower air vent would not

permit all leaked gas to escape

DometicRMD10_INM_4445103186_APAC(en)_2020_xx-xx.book Seite 10 Mittwoch, 28. Oktober 2020 9:57 09
