Doro AFTI 22 Bedienungsanleitung

doro afti 22

Manual

   

www.doro.com 3

English (see page 4-8)

Memory button

Handset Volume Control

Redial/Pause button

Recall button

Store/Mute button and LED

Visual Ring/Message Waiting

indicator

One Touch Memories

English

www.doro.com

Operation

Connection

Connect the curly cord to the handset and to the socket marked

on the

q on the

underside of the telephone.

Connect the telephone line cord to the socket marked

on the underside of

T on the underside of

the telephone, and then to a telephone network wall socket.

You will hear a click when the modular plug is correctly in place.

Lift the handset and listen for the dial tone. Your telephone is now

operational.

Ringer

On the underside of the telephone there are switches to adjust the ringer, tone

and volume:

Ringer volume

Ringer type

Ringer tone

Volume control

The handset earpiece volume may be adjusted during a call using

. Press the

right side of the button to increase and the left side to decrease the volume.

Mute button

The handset microphone can be disabled during a call by pressing

. Press

once

more to reactivate the microphone. The LED next to the button  ashes when the

microphone is muted.

Redial button

If the number dialled is engaged or if you wish to redial the last number dialled, lift

the handset and press the redial button

English

www.doro.com 5

Settings

Memory

The telephone will store 4 one-touch and 10 two-touch memories for frequently

dialled telephone numbers.

When a number is stored in memory, you need only press one or two buttons

dependant on location to make a call. One-touch memories are numbered

M1-M4, two-touch memories are stored using the telephone keypad digits

Storing One-touch Memories

Lift the handset and press

(ignore anything you hear in the earpiece).

P (ignore anything you hear in the earpiece).

Select a memory location (M1-M4) by pressing the corresponding button.

Enter the phone number to be stored (up to 21 digits).

Press

again.

P again.

Replace the handset. The number is now stored.

Dialing using One-touch Memories

Lift the handset and wait for a dialling tone.

Dial the desired number by pressing the corresponding memory location(M1-M4).

Storing Two-touch Memories

Lift the handset and press

(ignore anything you hear in the earpiece).

P (ignore anything you hear in the earpiece).

Press

Select a memory location by pressing one of the keypad numbers

Enter the phone number to be stored (up to 21 digits).

Press

and replace the handset The number is now stored.

P and replace the handset The number is now stored.

Dialing using Two-touch Memories

Lift the handset and wait for a dialling tone.

Press

Select the memory location where the number is stored by pressing the relevant

keypad number

Press

if you need a pause in the telephone number. If a

stored number changes, enter the new number in the location of

the old one following the procedures above. As a memory aid names or

numbers can be written on the memory index card. To remove the

memory card (after detaching the desk top bracket) press and hold down

the button located on the underside or the telephone (see diagram).

English

www.doro.com

6 www.doro.com6

Other

Recall

Access to additional network services can be gained by using the recall button

and

keys. Contact your network operator for more information.

Press the recall button

followed by the extension number to transfer a call

when connected to a PBX (TBR only).

Wall mounting

The telephone can be wall mounted using two screws positioned vertically at

a distance of 100mm. Remove the desktop bracket. The screws should then  t

into the two ‘keyholes’ on the back of the telephone. The telephone can also be

directly mounted to the standard Australian wall plate.

Hearing Aid compatible

This telephone is hearing aid compatible. Select the T mode on your hearing

aid to enable this feature.

Recall Button Timing

There are different Recall Button Timings available: 100, 300 and/or

600 ms,

using the

switch located beneath the protective cover and label. Please

refer

to page 5 for instructions to remove this protective cover. The standard setting

is 100 ms for UK/AU and 600 ms for NZ, in normal domestic use this setting

should not require changing.

Message Waiting Indicator

Some PBX systems have a function called Message Waiting.

On the under side of the telephone is a switch marked (MW), this is used to

select one of the following options: LED+, LED-, Visual Ring Indicator (

)

and high voltage (HV).

By selecting the appropriate option for your system the telephone will indicate if

there are any voice mail messages available.

This function operates differently depending on the PBX system in question

therefore please contact your system administrator for more information.

If the unit is not connected through a PBX please select ring indication (

English

www.doro.com 7

Other

Tone/Pulse Dialling (UK only)

You can select either Tone (♫) or Pulse (...) dialling using the switch located on

the right hand side of the unit. A small  at blade screwdriver or similar object

will be required. Normal=♫.

Troubleshooting

Test the equipment on a known working line (e. g. at a neighbour’s). If the

product works then the fault is with the line. If the telephone still does not

work, contact the place of purchase for service. Do not forget the receipt or a

copy of the invoice.

If you cannot resolve the fault using the fault nder section, technical support is

available on the

Premium Rate Number: 0906 302 0114.

Calls cost

50 pence per minute

(prices correct at the time of going to press),

and is operational between 9AM - 5PM Monday-Friday excluding Bank

Holidays. Alternatively,

E-mail on: tech@doro-uk.com

You can contact us in writing: Consumer Support Group, Doro UK Ltd.,

22 Walkers Road, North Moons Moat, Redditch, Worcestershire, B98 9HE,

(regarding any Spares or Technical query), or

Telephoning (Spares only): 01527 584377

Web site: www.doro-uk.com

Guarantee

This product is guaranteed for a period of 12 months from the date of

purchase. Proof of purchase is required for any service or support required

during the guarantee period.

This guarantee shall not apply to a fault caused by an accident or a similar

incident or damage, liquid ingress, negligence, abnormal usage or any other

circumstances on the purchaser’s part. Furthermore, this guarantee shall not

apply to a fault caused by a thunderstorm or any other voltage  uctuations.

This guarantee does not in any way affect your statutory rights. (As a

matter of precaution, we recommend disconnecting the telephone during a

thunderstorm.)

English

www.doro.com

8 www.doro.com8

Other

Australia and New Zealand

Products permitted for connection to the telephone network are marked with

in Australia and

in New Zealand. These marks indicate the

products comply with the regulations and can be used without concern in the

country of purchase.

If you believe this product is malfunctioning, please refer to the relevant section

and/or consult the troubleshooting guide in this manual to ensure that you have

followed the instructions carefully. As an alternative you can visit our web site

for FAQ’s or send an e-mail for a prompt reply.

Guarantee

This product is guaranteed for a period of 12 months from the date of purchase.

Should you experience dif culties with the product, please contact us for

assistance. If the product is then found to be faulty you will be asked to return it

directly to us with a copy of the purchase receipt.

This guarantee shall not apply to a fault caused by an accident or a similar

incident or damage, liquid ingress, negligence, abnormal usage or any other

circumstances on the purchaser’s part. Furthermore, this guarantee shall not

apply to a fault caused by a thunderstorm or lightning, excessive or any other

voltage  uctuations or faults on the telephone line. (As a matter of precaution,

we recommend disconnecting the telephone during a thunderstorm). This

guarantee does not affect your statutory rights.

AUSTRALIA

NEW ZEALAND

DORO Australia Pty Ltd

Atlas Gentech (NZ) Limited

PO Box 6760

Private Bag 14927

Baulkham Hills BC NSW 2153

Panmure

Australia

Auckland

New Zealand

Consumer Support

Ph: 1300 885 023

Ph: 0900-500-25 (Toll Call)

Fax: (02) 8853-8489

Fax: (09) 574-2722

Email: support@doro.com.au

Email: support@atlasgentech.co.nz

Web site:

www.doro.com.au

English

www.doro.com 9

Other

REN (RN for New Zealand)

The REN (Ringer Equivalence Number) or (RN) is of signi cance only if

you wish to connect more than 1 telephone to your telephone line. A standard

telephone line has a maximum REN capacity of 3 (RN of 5). It is possible

to connect 3 devices with a REN of 1 (RN of 1) with no degradation to the

product’s performance. Exceeding this limit may cause the volume of the ringer

in any phone to decrease or not ring at all.
