CLASSICAL TURNTABLE WITH AM/FM RADIO

CD, BT,CASSETTE RECORDER & USB/SD SLOT

MODEL: TR-18CD

Operating Instruction Manual

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN

EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES

CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE

OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR

MOISTURE.

IMPORTANT SAFETY INSTRUCTIONS

1) Please read these instructions and keep them for future reference.

2) Pay attention to all warnings.

3) Follow all instructions.

4) Do not use this apparatus near water.

5) Clean only with a dry cloth.

6) Do not block any ventilation openings.

7) Install in accordance with the manufacturer's instructions.

Do not install near any heat sources such as radiators, heaters, stoves, or other

apparatus (including amplifiers) that produce heat.

8) Protect the power cord from being walked on or kinked, in particular where the

plug is fitted and at the point where it exits from the apparatus.

9) Only use attachments / accessories specified by the manufacturer.

10) Unplug this apparatus during lightning storms or when unused for long periods

oftime.

11) Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture, does not operate normally, or

has been dropped.

12) This appliance should not be exposed to dripping or splashing water and no

object filled with liquids, such as vases, should be placed on the apparatus.

13) Do not overload the wall power outlet. Use only power source as indicated - i.e.

230V AC mains.

Avoid installing this unit in places exposed to direct sunlight or close to heat

radiating appliances such as electric heaters, on top of other stereo equipment

that radiates too much heat, places lacking ventilation or dusty areas, places

subject to constant vibration and/or humid or moist areas.

Do not attempt to clean this unit with chemical solvents as this might damage

the finish. Use a clean dry cloth.Operate controls and switches as described in the

manual.Before turning On the power, make certain the AC power cord is plugged in.

Store your CDs, Cassettes in a cool area to avoid damage from heat.When moving the set,

be sure to first disconnect the power cord.

UNPACKING AND SET UP

●Carefully remove the unit from the display carton and remove all packing material from

the unit.

●Unwind the AC power cord and extend it to its full length.

●Unwind the FM Antenna wire and extend it to its full length.

●Place the unit on a stable, level surface, convenient to an AC outlet, out of Direct

sunlight, and away from sources of excess heat, dust, moisture, humidity or

strong magnetic fields.

●Remove the opaque white plastic stylus cover from the phonograph stylus by sliding it

forward and down.

●Discard the stylus cover

●Remove the twist-tie that was used to secure the tone arm during shipment.

●Release the tone arm lock lever.

● Connect the plug to your AC outlet.

POWER SOURCE

This product is designed to operate on 230V 50/60Hz AC Mains only. Attempting to

operate this system from any other power source may cause damage to the system,

and such damage is not covered by your warranty.

PROTECT YOUR FURNITURE

This model is equipped with non-skid rubber 'feet' to prevent the product from moving

when you operate the controls. These 'feet' are made from non-migrating rubber material

specially formulated to avoid leaving any marks or stains on your furniture. However certain

types of oil based furniture polishes, wood preservatives, or cleaning sprays may cause the

rubber 'feet' to soften, and leave marks or a rubber residue on the furniture. To prevent any

damage to your furniture we strongly recommend that you purchase small self-adhesive felt

pads, available at hardware stores and home improvement centers everywhere, and apply

these pads to the bottom of the rubber 'feet' before you place the product on fine wooden

furniture.

LOCATION OF CONTROLS AND INDICATORS

1) DustCover

2) Cassetter Door

3) Speaker

4) Cassetter Button

5) PowerLedIndicators

6) IR Remote Receiver

7) Lcd Display Screen

8) TuningKnob

9) PowerSwitch&VolumeKnob

10) Function Selector Button

11) CD/USB/SD PlayBack Control Button

12)DiskTrayDoor

13) CD-Rom Open/close button

14) 3.5mm headphone socket

15) Auxiliary input

16)USBsocket

17) SD/MMC card slot

PHONOGRAPH

30)45rpmadaptor

31) Lift lever

32) Autostopcontrol

33) Tone arm lock

34) Speed selector (33/45/78 rpm)

35) Tone arm

BACK PANEL

18) RCALineout jack

19) FM wire antenna

20) AC power cord

REMOTE CONTROL

41) Mute button

42) Program button

43) Repeat button

44) Function Mode button

45) Skip down button

46) Play/Pause button

47) Record button

48) Stop button

49) Skip up button

50) Folder up button

51) Folder down button

NOTE: All the buttons on the remote control just use for CD/USB/SD function.

OPERATING INSTRUCTIONS

Listening to radio

1. Turn the volume knob in a clockwise direction to turn the equipment on.

2. Use the function selector to select TUNER mode.

3. Use the radio band selector to select the desired band (AM, FM or FM-Stereo).

4. Turn and hold the tuning knob for a few seconds to tune into a radio station. The

unit will start searching automatically and stop when a radio station is found.

Release the knob once a station has been found.

5. Repeat the above step until your desired radio station is found.

6. Adjust the volume knob to your desired volume level.

7. AM reception: the receiver has a built-in AM bar antenna. If reception is weak,

slightly rotate or reposition the unit to improve AM reception.

8. FM reception: the receiver has a built-in FM wire antenna hanging at the rear

cabinet. For best reception, completely unravel and extend this wire.

9. When you have finished listening to the radio, turn the volume knob in a

counterclockwise direction to switch the unit off. Unplug it from the power supply if

you are not going to use it for a while.

FM and FM-stereo

FM-Stereo : receiving stereo programs. Once a stereo signal is received, the ST icon

will light up on the display.

Phono Operation

1. Open the dust cover and turn the volume knob clockwise to turn the equipment on.

2. Use the function selector to select PHONO mode.

3. Set the speed selector to the appropriate position: 33, 45 or 78, depending on the

record to be played.

4. Set the auto stop control to ON if you want the turntable to stop turning when it has

reached the end of the record. If the switch is set to OFF, the turntable will continue

turning at the end of the record.

5. Place the record on the turntable (use the 45 rpm adaptor, if required).

6. Move the lift lever towards the back to raise the tone arm from the arm park, then

slowly move the arm to the record, as illustrated on the right. The turntable will start

rotating.

7. Move the lift lever towards the front, the tone arm will gently drop onto the record

and playback will start.

8. To stop playback, move the lift lever towards the back to raise the tone arm. The

turntable will still be rotating but the record will stop playing. To continue playback,

move the lift lever towards the front.

9. To play a different piece on the record, move the lift lever towards the back, move the

raised tone arm to the start of the piece and then move the lift lever towards the front to

lower the tone arm and start playback.

10. To adjust the volume level, turn the volume knob to the right or left.

11. At the end of the record, move the lift lever towards the back to raise the tone arm and

move it back to the tone arm park, and then move the lift lever towards the front to lower

the arm onto its rest.

12. Alternatively, lift the tone arm off the record and return it to the arm rest manually.

13.When you have finished playing records, engage the tone arm lock to protect it from

accidental movement. Turn the volume knob in a counterclockwise direction to switch

the unit off. Unplug it from the power supply if you are not going to use it for a while.

NOTE: Should your record stop before the last track finishes, set the auto stop control to

OFF. Your record will now play to the end, but you will have to stop the turntable

rotation manually. (Return the tone arm to its rest manually and if the turntable is

still rotating, switch off the unit by the volume control knob. Then set the auto stop

control back to ON.)

Phono encoding

1. Set the function button to PHONO mode and then insert a memory device (USB drive,

SD or MMC card).

2. Put your record onto the turntable and get it ready for playback.

3. Press the record REC button. It will take about 3 - 4 seconds to read the

memory device, then the USB or SD icon will be flashing on the LC display.

4. Press the skip up or skip down button to select the desired mode (USB

or SD) for encoding, then press the record REC button again to confirm.

(You can skip this step if only a USB drive or an SD/MMC card is inserted.)

5. The system will start the encoding mode after a few seconds.

6. Lower the tone arm to start playback of the record. During encoding, the USB or SD

icon will be flashing on the display.

7. To finish encoding, press the stop button. The display will show “END” and return to

PHONO mode.

NOTE:

The recording speed is 1:1. Recording will take as long as playing the record.

The recording format is preset at MP3 bit rate 128 kbps.

Cassette Operation

1. Cassetter Button Indicators

2. Cassetter Button Control

a) RECORDER-------Copy RADIO / PHONO /AUX IN / CD / USB / SD to TAPE

b) PLAYER--------------Play tape tracks

c) REVERSE

d) FORWARD

e) STOP/EJECT--------1st push – Cassette function stop, 2nd push open cassette door

f) PAUSE-----------------Pause when cassette in PlayBack mode.

3. Cassette PlayBack Control Operating

1) TAPE Play:

a) Function Choose to “TAPE” mode---Push “EJECT” key under tape----Open cassette

tape door-----put your tape into cassette dock----Manual close the tape door –Press

“PLAYER” Key ------ To adjust the volume level for your preference, turn the volume knob

to the right or left

b) Press “PAUSE” button once to stop playing, press it again to continue

C) When TAPE tracks play ending, “PLAYER” Key up automatically.

2) REVERSE ----------When Cassette Stop -------Press “REVERSE”.

3) FORWARD----------When Cassette Stop -------Press FORWARD.

4) STOP/EJECT-----1st push – Cassette function stop, 2nd push open cassette

5) RECORDER--------Recording from RADIO / PHONO /AUX IN / CD / USB / SD

to TAPE

a) RADIO / PHONO /AUX IN / CD / USB / SD-------During playing -------Press

Tape”EJECT”----Open tape door-----Put a blank tape into Cassette Dock----close the

door-----Press RECORDER&PLAYER together same time-----Now start the recording

songs to the tape------- Press “PAUSE” button if need to pause recording , press it again

to continue recording.

b) Press “STOP” to stop recording.

c) When recording finished (Tape is full-end ), “RECORDER&PLAYER “ Auto Key-up.

IMPORTANT!

When using the cassette deck :

Make sure to insert the cassette in the correct direction.

To avoid damaging the cassette, we strongly recommend

taking it out of the equipment after playing the cassette.

In case erase tape tracks by improper operation, you can choose take

off anti-erase tap (write protection) to finalize the recorded-tape.

For the same principle, if take off anti-erase tap,this tape would not be

able to write new contents/songs.

(Anti-erase taps position)

Cassette encoding

1. Set the function button to TAPE/AUX mode and then insert a memory device (USB

drive, SD or MMC card).

2. Press the record REC button, it will take 3 - 4 second to read the memory device,

then the USB or SD icon will be flashing on the LC display.

3. Press the skip up or skip down button to select the desired mode (USB

or SD) for encoding, then press the record REC button again to confirm.

(You can skip this step if only a USB drive or an SD/MMC card is inserted.)

4. The system will start the encoding mode after a few seconds. Insert your cassette into

the playback slot. During encoding, the USB or SD icon will be flashing on the display.

5. To finish encoding, press the stop button. The display will show “END” and return

to TAPE/AUX mode.

NOTE:

The recording format is preset at MP3 bit rate 128 kbps.

The recording speed is 1:1. Recording will take as long as playing the record.

CD Operation

1. Turn the volume knob clockwise to turn the equipment on.

2. Press the CD-Rom switch ,then the disk tray door opens .

3. Place the CD face up inside ,making sure it is fully placed .Then press the CD-Rom

switch again ,the disk tray door closes .

4. To play a different piece on the record, Press the skip up or skip down

button to select the desired piece.

5 To adjust the volume level, turn the volume knob to the right or left.

CD encoding

1. Set the function button to CD/USB/SD mode and then insert a memory device

(USB drive, SD or MMC card).

2. Press the record REC button, it will take 3 - 4 second to read the memory

device, then the USB or SD icon will be flashing on the LC display.

Inhaltsverzeichnis

Andere Dosound Eletronics Drehscheibe Handbücher

Dosound Eletronics

Dosound Eletronics TR-18CD-SP Bedienungsanleitung

Beliebte Drehscheibe Handbücher anderer Marken

Gemini

Gemini CDT-05 MKII Bedienungsanleitung

Rotel

Rotel RP-820 Bedienungsanleitung

Shuman

Shuman MC-250BT Bedienungsanleitung

Stanton

Stanton STR8-150 Bedienungsanleitung

Audio Technica

Audio Technica AT-LPW40WN Bedienungsanleitung

Crosley

Crosley McQueen CR7011-GY Bedienungsanleitung

Reloop

Reloop SMP-1 Bedienungsanleitung

auna

auna TT-Classic Plus Bedienungsanleitung

COMO AUDIO

COMO AUDIO Turntable Analog Bedienungsanleitung

Dual

Dual 1009 F Bedienungsanleitung

REED

REED Muse3C Bedienungsanleitung

AXIOMTEK

AXIOMTEK OPS883-H Series Bedienungsanleitung

Pioneer

Pioneer PL-71 Bedienungsanleitung

Vestax

Vestax PDX-a1 Bedienungsanleitung

Denon

Denon DP-400 Bedienungsanleitung

Dual

Dual 504 Bedienungsanleitung

Audio-Techica

Audio-Techica AT-LP60XBT Bedienungsanleitung

Goldring

Goldring G99 Bedienungsanleitung
