Draytek VigorAP 1060C Bedienungsanleitung

VigorAP 1060C

11ax Ceiling AP

Quick Start Guide

Version: 1. 3

Firmware Version: V1. 4.4

(For future update, please visit DrayTek web site)

Date: December 17, 2021

1. Package Content ............................................................................1

2. Panel Explanation...........................................................................2

3. Installation....................................................................................3

3.1 Ceiling-mount Installation (Wooden Ceiling) .............................................. 3

3.2 Ceiling-mount Installation (Plasterboard Ceiling) ........................................ 4

3.3 Suspended Ceiling (Lightweight Steel Frame) Installation . .. . ... . .. . . .. . ... . .. . . .. . .. . 5

3.4 Wall-Mounted Installation ..................................................................... 6

4. Connection and Configuration............................................................7

4.1 Connect to a Vigor Router using AP Management .. . . .. . ... . .. . . .. . ... . .. . . .. . ... . .. . . .. . 7

4.2 Web Configurations............................................................................. 8

4. 2.1 Connect ed As a Mesh Node (in Mesh Network).................................................... 8

4. 2.2 Connect ed As an Access Point ....................................................................... 8

5. Customer Service ......................................................................... 11

Be a Registered Owner.............................................................................11

Firmware & Tools Updates........................................................................11

Take a look at t he package cont ent . If t here is anyt hing missed or damaged,

please cont act DrayTek or dealer immediat ely.

VigorAP 1060C Main Unit Screw Set

(for wall mount ing)

Mount Base

(for wall mount ing)

Fixings and Screws

(for ceiling mount ing)

Ceiling Mount Base f or 9/ 16" T-Rail

Ceiling Mount Base f or 15/ 16" T-Rail

Cable Tie & Quick St art Guide RJ-45 Cabl e (Et hernet )

Note

Power Input : 12V 2. 5A

PoE Input : 54V 0. 6A

Tot al Rat ed Power Consumpt ion: 21 Wat t s

LED Status Explanation

On (Blue) The syst em is in boot -loader mode.

Of f The syst em is not ready or f ails.

Blinking(Blue) The syst em is in TFTP mode.

Of f The syst em is not ready or f ails.2

Blinking(Blue) The syst em is ready and can work normally.

Interface Explanation

Et hernet Port Connect s t o LAN or rout er.

Support s PoE power & Gigabit (2.5Gbps).

Power Jack(12V 2. 5A) Connect er f or a power adapt er.

Hole Explanation

Fact ory Reset Rest ores t he unit back t o f act ory default set t ings.

To use, insert a small it em such as an unbent

paperclip int o t he hole. You will feel t he but t on

inside depress gent ly. Hold it f or 5 seconds.

The VigorAP will rest art wit h t he f act ory def ault

conf igurat ion and t he LED will blink blue.

Securit y Hole A securit y hole f or inst alling t he ant i-t heft lock.

Note

For t he sake of securit y, make t he accessory kit away f rom

children.

Factory

Reset

Ethernet Port Power Jack

(

DC IN

)

LED

Security

Hole

VigorAP can be inst alled under cert ain locat ions: wooden ceiling, plast erboard

ceilings, light -weight ed st eel f rame and wall.

-m

(

)

Det ermine where t he Access Point t o be placed and mark locat ion on t he surf ace

for t he t wo mount ing holes. Use t he appropriat e drill bit t o drill t wo holes in t he

markings and hammer t he bolt s int o t he openings.

1. Place t he mount base under t he wooden ceiling and f ast en it on t he ceiling

wit h t wo screws f irmly.

2. When t he mount base is in place, slide t he AP int o t he slot of t he mount

base.

-m

(

)

1. Insert t wo t urnbuckles f irmly int o t he plast erboard.

2. Set t he Mount Base in t he t urnbuckles. Let t he screws pass t hrough t he

Mount Base and insert t hem int o t he t urnbuckles. Fast en t hem t o of fer a

more powerf ul support ing force.

3. When t he Mount Base is in pl ace, slide t he mount base int o t he slot of t he

AP.

(

)

You cannot screw int o ceiling t iles as t hey are weak and not suit able f or bearing

loads. Your VigorAP is supplied wit h mount s (Mount Base) which will be used t o

at t ach direct ly t o t he ceiling frame of your suspended ceiling.

1. Slide t he mount base int o t he slot of t he AP.

2. Hold t he Access Point wit h one hand t o reach t he ot her hand over t he T-Rail

sides of t he bracket .

3. Rot at e and hook t he st at ionary end of t he ceiling mount base ont o t he T-Rail

ceiling frame.

Note

Warning: The screw set shown bel ow is f or wal l mount ing only.

Do not use such set for ceiling mount ing due t o t he danger of

falling.

-M

For wall-mount ing, t he VigorAP has keyhole t ype mount ing slot s on t he

underside.

1. Use t he appropriat e drill bit t o drill t wo holes in t he markings and hammer

t he bolt s int o t he openings.

2. Screw t he anchors unt o t he holes unt il t hey are f lush wit h t he wall; screw

t he included screws int o t he anchors.

3. Place t he Access Point against wall wit h t he mount ing screw heads.

Note

The recommended drill diamet er is 6. 5mm (1/ 4").

Your VigorAP can be used wit h Vigor rout ers which support AP management (such

as t he Vigor2865 or Vigor2927 series). AP Management enables you t o monit or

and manage mult iple DrayTek APs from a single int erf ace.

1. Connect VigorAP t o PoE swit ch (via LAN port ) wit h Et hernet cable. VigorAP

will get t he power f rom t he swit ch direct ly. Then, connect t he VigorSwit ch

t o a Vigor rout er.

2. Access int o t he web user int erf ace of Vigor rout er. Here we t ake Vigor2865

as an example. Open Central Management>>AP>>Status.

3. Locat e VigorAP 1060C. Click t he IP address assigned by Vigor rout er t o

access int o web user int erf ace of VigorAP 1060C.

4. Af t er ent ering t he username and password (admin/ admin), t he main screen

will be displayed.
