Draytek VigorSwitch G2260 Bedienungsanleitung

Quick Start Guide

European Community Declarations

Manufacturer: DrayTek Corp.

Address: No. 26, Fu Shing Road, HuKou Township, HsinChu Industrial

Park, Hsin-Chu, Taiwan 303

Product: VigorSwitch G2260

DrayTek Corp. declares that VigorSwitch G2260 is in compliance with the

following essential requirements and other relevant provisions of 2004/108/EC.

The product conforms to the requirements of Electro-Magnetic Compatibility

(EMC) Directive 2004/108/EC by complying with the requirements set forth in

EN55022/Class A and EN55024/Class A.

The product conforms to the requirements of Low Voltage (LVD) Directive

2006/95/EC by complying with the requirements set forth in EN60950-1.

Federal Communications Commission (FCC) Statement

This equipment has been tested and found to comply with the limits for a class

A computing device pursuant to Subpart J of part 15 of FCC Rules, which are

designed to provide reasonable protection against such interference when

operated in a commercial environment.

Version: 1.0

Date: 19/07/2012

nPackage Content

The 24+2 Giga Port L2 Managed Switch is a standard switch that meets all

IEEE 802.3/u/x/z Gigabit, Fast Ethernet specifications. The switch has 24

10/100/1000Mbps TP ports and 6 Gigabit TP/SFP transceiver slots.

The network administrator can logon the switch to monitor, configure and

control each port’s activity. In addition, the switch implements the QoS

(Quality of Service), VLAN, and Trunking. It is suitable for office

application.

VigorSwitch Rack Mount Kit

CD Ethernet Cable

The type of the power cord depends on the country that the router will be

installed:

UK-type power cord EU-type power cord USA-type power cord

Note: If any of these items is found missing or damaged, please contact

your local supplier for replacement.

oDescriptions of Panel

LED Explanation

LED Color Explanation

POWER Green Lit when +3.3V power is coming up.

TP Port 1– 24

(RJ45 LEFT)

LINK/ACT Green Lit when connection with remote device is good.

Blinks when any traffic is present.

TP Port 1– 24

(RJ45 RIGHT)

SPEED Green

Lit Green when TP connection with remote device is

1000M.

Blinks when TP connection with remote device is 100M.

Off when TP connection with remote device is 10M.

SFP Port 21-24

LINK/ACT

Green/

Amber

Lit Green when TP connection with remote device is

1000M..

Lit Amber when TP connection with remote device is

100M.

Blinks when any traffic is present.

SFP Port 25-26

LINK/ACT

Green/

Amber

Lit Green when the connection with remote device is

1000M.

Lit Amber when the connection with remote device is

100M.

Blinks when any traffic is present.

Connector Explanation

Interface Description

RESET Used to restart the device to default settings.

CONSOLE Used to perform telnet command control.

LAN P1 – P24 Giga Ethernet Port.

SFP (21 – 26) SFP Fiber Port.

Installing Your Switch

A hierarchical network with minimum levels of switch may reduce the timing

delay between server and client station. Basically, with this approach, it will

minimize the number of switches in any one path; will lower the possibility of

network loop and will improve network efficiency. If more than two switches

are connected in the same network, select one switch as Level 1 switch and

connect all other switches to it at Level 2. Server/Host is recommended to

connect to the Level 1 switch. This is general if no VLAN or other special

requirements are applied.

All switch ports are in the same local area network.

For other examples of hardware installation, please refer to User’s Guide for

detailed information.
