INSTALLATION/OWNER'S MANUAL

AM/FM/CD Marine Receiver with Detachable Face

AM400W

TYPICAL FRONT-LOAD DIN MOUNTING METHOD

Removal Keys

Mounting Sleeve

Dashboard or

Mounting Kit

Head Unit

AM400W INSTALLATION

Preparation

Please read entire manual before installation.

Before You Start

•Disconnectnegativebatteryterminal.Consultaqualifiedtechnicianforinstructions.

•Avoidinstallingtheunitwhereitwouldbesubjecttohightemperatures,suchasfrom

directsunlight,orwhereitwouldbesubjecttodust,dirtorexcessivevibration.

Getting Started

•Removetrimringfromunit.

•Remove2transitscrewslocatedontopoftheunit.

•Insertthesuppliedkeysintotheslotsasshown,andslidetheunitoutofthemounting

sleeve.

•Installmountingsleeveintoopening,bendingtabstosecure.

•Connectwiringharnessandantenna.Consultaqualifiedtechnicianifyouareunsure.

•Certainvehiclesmayrequireaninstallationkitand/or

 wiringharnessadapter(soldseparately).

•Testforcorrectoperationandslideinto

mountingsleevetosecure.

•Snaptrimringintoplace.

AM400W INSTALLATION

Wiring Diagram

Rear Preamp Output

Connect to amplifier RCA input

Antenna Connector

RCA Cable

(sold separately)

AMP

BLUE

BLACK

RED

YELLOW

Remote Turn-On

Connect to amplifier or power

antenna. Insulate wire if not used.

Ground

Connect to vehicle

chassis ground.

Accessory

Connect to ignition

circuit or switched 12 volt source.

Memory

Connect to battery

circuit or constant 12 volt source.

Right Front

Gray/Black (-)

Gray (+)

Left Front

White/Black (-)

White (+)

Right Rear

Violet/Black (-)

Violet (+)

Left Rear

Green/Black (-)

Green (+)

10 AMP

AGC Fuse

FUSE

Whenreplacingthe

fuse,makesurenew

fuseisthecorrecttype

andamperage.Using

anincorrectfusecould

damagetheradio.

TheAM400Wuses

one10ampATMfuse

locatedbesidethewiring

connector.

AM400W OPERATION

Control Locations - Receiver

Release

Volume

Mute / Power

Tune / Track Down

Source

Tune / Track Up

Eject

USB Port

Auxiliary Input

Preset 6 / Folder Up

Preset 5 / Folder Down

Preset 4 / Play / Pause

Preset 3 / Intro

Preset 2 / Random

Preset 1 / Repeat

Band / Select

Display / Escape

Audio / Menu

1 2 3 4 6 7

16 9

15 14 13 12 11 101718

1 10

2 11

3 12

4 13

5 14

6 15

7 16

8 17

9 18

AM400W OPERATION

Control Locations - Remote

Display/ESC

Tune/TrackDown

Band/Select

Mute/Power

VolumeUp

Source

Tune/TrackUp

VolumeDown

Audio/Menu

1 6

2 7

3 8

45 6

AM400W OPERATION

Press oranyotherbutton(exceptEJECT)toturntheunit

on. Press toturntheunitoff.

Press SOURCE toselectbetweenAM/FM,CDplayer,

auxiliaryinput,USBandoperationofiPod®/iPhone®.Modes

ofoperationareshowninthedisplay.

NOTE:CD,USBandoperationofiPodmodeswillnotappear

unlessaCDisinsertedorUSB/iPoddevicesareconnected.

TheAM400Woffersa3.5mmportonthefrontpanel.Using

a3.5mmmale-to-malecable,connectaudiodevice,MP3

player,etc.totheauxilaryinput.PressSOURCE toselect

AUX-INmode.

Adjustvolumeusingvolumeknob(00-46).

Press DISPtoselectbetweenclockanddifferenttypesof

information,suchasradiofrequency,CDtrack/elapsedtime

orMP3/WMAsonginformation.

Press RESETuponinitialinstallationorifabnormal

operationoccurs.Resetbuttonislocatedbehindthefront

panel.

Withtheuniton,pressandholdDISPuntiltheclockbegins

toflash,thenrelease.PressTUNE

toadjustthehours

and TUNE

toadjusttheminutes.PressDISP momen-

tarilytosavetheselectedtime.

Theclockwilldisplay12-hourAM/PMtimeinUSAfrequency

spacingmode(10:00PM).InEuropeanfrequencyspacing

mode,theclockwilldisplay24-hourtime(22:00).

PressandholdAUDIO/MENUformorethan3secondsto

accessthesetupmenu.PressAUDIO/MENUmomentarily

toselectbetweenthemenufunctionsandrotatethevolume

knobleft/righttoadjustoractivatethedesiredfunction.

Power On/Off

Changing Modes

Auxiliary Input

Volume

Display

Reset

Set the Clock

12/24-hour Clock

Setup Menu

General Operation

AM400W OPERATION

General Operation - Setup Menu

Menu Function Options Action

Auto Station

Store AUTOSTORE Press SELECTtoseekandsave6strongstationsinthe

currentband.(Tuner mode only)

Local/Distance

Tuning

LOCALOFF Activatesdistancetuning(Tuner mode only).

LOCALON Activateslocaltuningforstrongstationreceptiononly(Tuner

mode only).

Tuner

Frequency

Spacing

FREQUSA ProgramstheunittoUSAtunerspacing.

(200kHzforFMand10kHzforAM).(Tuner mode only)

FREQEURO ProgramstheunittoEuropeantunerspacing.

(50kHzforFMand9kHzforAM).(Tuner mode only)

Selectable iPod

Control

IPODFULL ProgramstheheadunittoadvancedcontroloftheiPod/

iPhonedevice.(Operation of iPod mode only)

IPODBASIC

ProgramstheheadunittomanualcontroloftheiPod/iPhone

deviceandallowsmusictobecontrolledfromtheiPod/

iPhonedevice.(Operation of iPod mode only)

Clock

Display

CLOCKOFF Programsunittonotdisplaytheclockwhenthepowerisoff.

CLOCKON Programsunittodisplaytheclockwhenthepowerisoff.

Auxiliary Input AUXON Enablesthefrontpanel3.5mmauxiliaryinput.

AUXOFF Disablesthefrontpanel3.5mmauxiliaryinput.

Beep

Confirmation

BEEPOFF Disablestheconfirmationbeep.

BEEPON Enablestheconfirmationbeep.

Programmable

Turn On Volume PRO-VOL# Programsunittoalwaysturnonataspecificvolume

(defaultisOFF).Anyvolumelevel1-46canbeselected.

Power on

Message

MSGOFF Disablespoweronmessage.(example:GOODMORNING)

MSGON Enablespoweronmessagetobedisplayed.

Scrolling

Option

SCROLL15S Programsunittoscrollinformationonceevery15seconds

(default).

SCROLLONCE Programsunittoscrollonce,thenshowthefirst10

charactersondisplay.

SCROLLON Programsunittoscrollcontinuously.

SCROLLOFF Programsunittoshowthefirst10charactersonthedisplay.

Illumination

Dimmer

DIMMERHI Programsunittothebrightestilluminationlevel.

DIMMERMED Programsunittothemiddleilluminationlevel.

DIMMERLOW Programsunittothedimmestilluminationlevel.

Demonstration

Mode

DEMOOFF Disablesthedemonstrationmode.

DEMOON Enablesthedemonstrationmessage.

AM400W OPERATION

Press AUDIOmomentarilytoselectbetweenBass,Treble,

Balance,Fader,EqualizerandSourceVolumeLevel.

Press AUDIO until BASSappearsthenrotatevolumeknob

left/righttoadjust(-6minimum/+6maximum).

Press AUDIO until TREBLEappearsthenrotatevolumeknob

left/righttoadjust(-6minimum/+6maximum).

Press AUDIO until BALappearsthenrotatevolumeknob

left/righttoadjust(BALL12-BALR12).

BALEVENrepresentsequalbalance

Press AUDIO until FADERappearsthenrotatevolumeknob

left/righttoadjust(FADERF12-FADERR12).

FADEVENrepresentsequalfader

Press AUDIO until EQappearsthenturnthevolume knob

tocyclethroughthefollowingequalizationcurves:FLAT

(default),POP,JAZZ,CLASSIC,BEAT,ROCKandUSER.

AnymanualadjustmenttotheBassorTreblesettingsare

automaticallysavedasUSER.

Thesourcevolumelevelcontrolallowsagainadjustment

foreachaudiosource:AM,FM,CD,AUX,operationofiPod

andUSB.Setthesourcevolumelevelforeachmode,

dependingontherelativevolumeofeachaudiosource.

Tosetthesourcevolumelevel,pressAUDIOuntilSRC

LEVELappears.Afteronesecond,thecurrentmodewill

appearonthedisplay.Turnthevolumeknobtoadjust

theaudiolevelofthecurrentsource(-6minimum/+6

maximum).

Note: Onlythecurrentmodewillbeavailablefor

adjustment.Toadjustanothermodeofoperation,press

SOURCE untilthedesiredmodeisselected,thensetthe

sourcevolumelevelforthatmode.

Audio

Bass

Treble

Balance

Fader

Equalizer

Source Volume Level

General Operation

BASS TREBLE BALANCE FADER EQUALIZER SOURCE LEVEL

AM400W OPERATION

Seek Tuning

Manual Tuning

Band

Storing and Recalling

Station Presets

Press TUNE

or TUNE

formorethanonesecond

toseektothenextstrongstation.

Press TUNE

or TUNE

momentarilytochange

radiofrequencyupordownonestepatatime.Pressand

holdtoadvancequickly.

Press BANDtoselectbetweenFM1,FM2,FM3,AM1,AM2

andWBbands.

Upto18FMstationsand12AMstationscanbestored.To

storeastation,selectthedesiredbandandstation.Press

andholdthedesiredpresetbutton(1-6)formorethan

2seconds.

Whenstored,thepresetnumberwillappearinthedisplay.

Thestationcanberecalledanytimebypressingthe

correspondingpresetbutton.

AM/FM Tuner Operation

Weatherband Tuner Operation

Band

Manual Tuning

Storing and Recalling

Presets

Press BANDtoselectweatherband(WB).

Press TUNE

or TUNE

momentarilytoseekthe

nextweatherbandstation.

Upto6weatherbandstationscanbestored.Tostorea

station,selecttheweatherbandandthedesiredstation.

Pressandholdthedesiredpresetbutton(1-6)formore

than2seconds.

Whenstored,thepresetnumberwillappearinthedisplay.

Thestationcanberecalledanytimebypressingthe

correspondingpresetbutton.

AM400W OPERATION

Insert CD

Eject CD

Track Select

Fast Forward and Reverse

Pause

Intro

Repeat

Random

CD-R/CD-RW Compatibility

Withthelabelfacingup,insertastandardsizeCDintothe

CDslot.TheCDwillautomaticallybeginplayback.

Press EJECTtoejecttheCD.Theunitwillchangeto

previousmodeofoperation.Ifthediscisnotremoved

within10seconds,theunitwillreloadthedisc.Theunit

doesnothavetobeturnedontoejectCD.

Press TRACK

toskiptothebeginningofthenext

track.PressTRACK

toreturntothebeginningofthe

currenttrack.PressingTRACK

againskipstothe

beginningoftheprevioustrack.

PressandholdTRACK

or TRACK

tofastforward

orreverseatrack.

Press

totemporarilystopCDplayback.

Press

againtoresumeplayback.

Press INT toentertheIntromenu,thenturnthevolume

knobtoselectoneofthefollowingoptions:

•OFF-CancelstheINT function.

•ALL-Playsthefirst10secondsofeachtrack.

Press RPT toentertheRepeatmenu,thenturnthevolume

knobtoselectoneofthefollowingoptions:

•ALL-PlaysalltracksonCD.

•TRACK-Continuouslyrepeatsselectedtrack.

Press RDM toentertheRandommenu,thenturnthe

volumeknobtoselectoneofthefollowingoptions:

•OFF-CancelstheRDM function.

•ALL-Playsalltracksinrandomorder.

SomeCD-RsandCD-RWsmaybeincompatiblewiththis

unit,dependingonmediatypeandrecordingmethod.In

addition,thefollowingCDsmaybeincompatiblewiththis

unit:

CDsexposedtoextremetemperaturesordirectsunlight

forextendedperiodsoftime,CDsrecordedinwhicha

recordingsessionfailedorare-recordingwasattempted

and,orencryptedorcopy-protectedCDswhichdonot

conformtotheaudioCD-DAredbookrecordingstandard.

CD Player Operation

Inhaltsverzeichnis

Andere Dual Schiffsausrüstung Handbücher

Beliebte Schiffsausrüstung Handbücher anderer Marken

Clarion

Clarion CMS2 Reparaturanleitung

EBS

EBS M7000 Bedienungsanleitung

Kongsberg

Kongsberg M3 Bathy Bedienungsanleitung

NPK

NPK SCS-1002 Bedienungsanleitung

Furuno

Furuno FE-800 Bedienungsanleitung

Harken

Harken 1561 Bedienungsanleitung

Simrad

Simrad DD15 Bedienungsanleitung

Notifier

Notifier FS-BSO Bedienungsanleitung

Raymarine

Raymarine ST40 Bedienungsanleitung

E2S

E2S E2XS112UL Bedienungsanleitung

R2Sonic

R2Sonic 2026 Bedienungsanleitung

COBHAM

COBHAM SAILOR 6000 Bedienungsanleitung

Clarion

Clarion GR10BT Reparaturanleitung

Raymarine

Raymarine Maxiview ST80 Benutzerhandbuch

GUIDANCE MARINE

GUIDANCE MARINE 20- Series Montageanleitung

Raymarine

Raymarine ST60 Tridata Benutzerhandbuch

olympia electronics

olympia electronics ΒS-531/1/MAR Bedienungsanleitung

Sonic

Sonic 2024 Bedienungsanleitung
