Installation and Operating Manual

Dualit, County Oak Way, Crawley, West Sussex, RH11 7ST

Customer Helpline: +44 (0) 1293 652 500 (9am - 5pm Monday to Friday) • Fax: +44 (0) 1293 652 555

Email: [email protected] •www.dualit.com

Contact Information

Salamander Grill

Please carefully read this manual before using this product.

Make sure you are familiar with all of the safety and

usage instructions.

Keep this manual in a safe place for future reference.

RSG1

SAFETY INFORMATION

WARNING: The installation, maintenance and servicing of this

product must be carried out by a qualied technician.

You should consult local and national standards to comply with

the following:

Health & safety at work legislation

BS EN Codes of practice

Fire precautions

IEE Wiring regulations

Building regulations

WARNING: Incorrect installation, unauthorised modications,

retting, adjustments, dismantling or maintenance could result

in damage to the grill, damage to property or serious injury. All

repairs, maintenance and adjustments must be carried out by

a qualied technician.

WARNING: RISK OF SEVERE BURNS. Take caution when

using this product.

WARNING: ELECTRIC SHOCK RISK. DO NOT use when the

power cord is damaged.

WARNING: For safety reasons, this product MUST be earthed.

The terminal marked is for equipotential bonding.

WARNING: This is a commercial product and must only be used

by a trained operative who has read and fully understands this

manual. It must not be used by children or persons with reduced

physical, sensory or mental capabilities.

IMPORTANT: This product is intended for grilling food only. It

is not intended for any other styles of cooking. Its temperature

operation range is 50 - 250°C.

Before using the product, ensure that the electricity supply

conforms to the rating markings on the product.

Check power cord for damage prior to every use. If damaged

it can only be replaced by the manufacturer or a qualied

technician.

IMPORTANT: The product should be given a visual safety check

over every day to help prevent accidents.

IMPORTANT: The product should not be used if operator feels

there is anything wrong with it. The problem should be referred

to the manufacturer or a qualied technician.

Incorrect use of the grill, other than its intended use, can cause

damage to it and be dangerous.

The grill surfaces and control panel may be damaged by hard or

sharp objects.

DO NOT use a power supply that is not compatible with safety

standards.

DO NOT store any type of ammable liquid, gas or other similar

items near or around this product.

CAUTION: Be aware that surfaces of the product may be hot

before and after it has been used - RISK OF SEVERE BURNS.

DO NOT use the product during a thunderstorm. To avoid it

being damaged by a lightning strike, unplug it from electricity

supply prior to the storm.

Before cleaning, unplug the product from the mains

power supply.

Allow the grill to cool before cleaning.

DO NOT use wet cloths, steel wool pads, abrasive creams or

acid based cleaners.

DO NOT spray or splash water directly onto the product - RISK

OF ELECTRIC SHOCK.

DO NOT submerge product, electric plug or power lead in water

or other liquids. If the product has been soaked, it must be dried

and checked by a trained technician before further use.

When not in use, turn the temperature control to the ‘0’ position

and unplug the product from the mains power supply.

Store product in a safe, clean, dry, well ventilated place if it is

not going to be used for any length of time.

EXTREME CAUTION: Failure to follow instructions could result

in damage to product, damage to property or serious injury

To avoid risk of suffocation to children or animals, dispose of the

plastic bags and packaging correctly.

For use with an earthed wall socket.

For indoor use only. Must NOT be used outdoors.

Not suitable for use with an extension cable.

Keep grill and power cord out of reach of children and keep pets

clear during use.

DO NOT position or use product underneath or near ammable

items such as curtains, shelves, cupboards etc - FIRE HAZARD

DO NOT cover the product with anything - FIRE HAZARD

DO NOT try to dislodge food from the product when it is plugged

in - RISK OF ELECTRIC SHOCK.

DO NOT allow the power cord to hang over the edge of a table

or work surface on which the product stands.

DO NOT allow the power cord to come into contact with a heat

source.

DO NOT use on or near direct heat sources.

DO NOT operate product with wet hands.

DO NOT operate product if damaged, or the power cord, plug or

it is damaged in any way.

DO NOT leave product unattended when in use.

DO NOT attempt to service the product yourself. Contact a

qualied technician.

DO NOT use attachments other than those recommended by

the manufacturer.

CAUTION: Do not pull or drag the product by the power cord.

The product must be placed and operated on a safe, at and

stable surface.

Children should be supervised to ensure that they do not play

with the appliance.

THE SALAMANDER GRILL

Salamander Grill Parts:

1. Power on

2. Power light

3. Wall spacer

4. Temperature control

5. Grill rack

6. Drip tray

7. Rubber feet

Thank you for purchasing this Dualit Salamander Grill. The Salamander Grill is the ideal for providing the

nishing golden touch to the tops of lasagne, pies or desserts. With three grill positions, the Salamander is a

versatile and convenient way to create grilled dishes in a bustling kitchen.

INSTALLATION

Remove all protective lm from the grill before use.

This grill is a plug-in product but commercial safety regulations

require additional earthing to be carried out.

Only a suitably qualied technician should install the product.

There is an earth bolt at the back of the grill .

Complying fully with safety regulations, connect the earth wire

with suitable cable.

The grill should be positioned where it can be easily connected

to the power supply and where there is enough room to use and

maintain the product.

The wall spacers on the back/side will ensure there is a air gap

around the machine.

A suitable switch, fuse breaker and plug socket should be

installed near the grill.

You may see smoke coming from the elements,when the

machine is rst switched on, this is normal.

6 5 4

WARNING: RISK OF SEVERE BURNS. When used,

parts of the grill will be hot to the touch.

WARNING: Use heat protective gloves when moving

food in or out of the grill.

1. Before using the product, ensure that the electricity supply

conforms to the rating markings on the grill and check there

is no damage to the power cord.

2. Adjust the position of the rack/tray in the oven according to

the size of dish to be grilled.

3. Plug the grill into the wall socket and make sure the power is

switched on.

4. Turn temperature control dial (4) to WARM or HOT settings

whereby the elements will cycle on and off to maintain a

regular temperature or set to MAX setting whereby the

element will stay on constantly at maximum temperature.

IMPORTANT: The product must be regularly inspected and

maintained by a qualied technician.

IMPORTANT: Always unplug grill from the mains power socket

and allow to cool completely before cleaning.

DO NOT use a water jet, spray or splash water directly onto

the product.

DO NOT submerge product, electric plug or power cord in water

or other liquids.

Clean the grill chamber at least once a week, more often if grill

is used frequently.

Remove the drip tray and rack and wash them in warm water

and dry.

The inside of the oven should be cleaned using a non abbrasive

cleaning pad and a cleaner suitable for ovens/grills.

Care, Maintenance, Storage and Transportation

Only return the drip tray and rack to the oven when they are fully

dry.

When not in use, turn the temperature control to the ‘0’ position

and unplug the grill from the mains power supply.

Store product in a safe, clean, dry, well ventilated place if it is

not going to be used for any length of time.

Handle the grill with care when transporting.

DO NOT turn the grill upside down. This will help prevent the

possibility of damaging it.

USING THE SALAMANDER GRILL

5. To turn the grill on, press the

power switch (1) grill will start to

heat.

6. When cooking is nished, the

temperature control (4) must be

turned to the ‘0’ position and the

timer turned to the off position.

8. Unplug the grill from the mains

power socket when not in use.

Problem Cause(s) Solution(s)

Power light stays on when power off. Fuse may be blown. Replace fuse.

The mains power is on but the heating

elements are not working.

1. The element may have failed.1. Contact a qualied technician for

repair advice.

Temperature control is working but the

indicator light is off.

1. Indicator light is not properly

connected.

2. Indicator light is broken.

1. Wiring needs to be looked at.

Contact a qualied technician for repair

advice.

2. Replace indicator light. Contact a

qualied technician for repair advice.

If a problem occurs that does not appear on this table, stop using the grill and seek help from the manufacturer, a qualied

technician or an authorised dealer.

TROUBLE SHOOTING

Model number RSG1

Description Grill

Voltage 230V~

Power 2KW

Overall dimensions 690 x 350 x 280 (ht) mm

Temperature range 50 - 250°C

Weight 13kg

Casing material Stainless steel

Oven interior material Stainless steel

Feet Rubber

Technical Specifications

This appliance is of excellent quality and construction. However, if any defects in materials or workmanship do appear during the

relevant guarantee period, we will, at our discretion, either repair or replace the defective parts, free of charge, subject to the terms

and conditions of our Guarantee shown below.

This Guarantee covers both parts and labour. Carriage is not included.

Your Guarantee period is as follows:

• 1 year

This Guarantee provides benets which are additional to, and do not affect, your statutory rights. This Guarantee does not cover the

cost of returning the product to the dealer from whom it was purchased or to ourselves. This Guarantee applies only to products sold

and located in mainland Great Britain. It does not cover liability in respect of or replacement of plugs, cables or fuses and also does

not cover defects due to:

• Failure to use or maintain product in accordance with Dualit's instructions

• The product being connected to an unsuitable electricity supply

• Accidental damage to or abuse or misuse of the product

• The product has not been modied except by Dualit or approved agent

• Dismantling of or interference with the product

• Accidental breakage or damage

• Operational misuse, wear and tear from normal usage, incorrect adjustment and neglect

• Incorrect installation, maintenance, modication or unauthorised service work

• Theft or attempted theft of the product

Before returning any product under this Guarantee, please check that:

• You have followed the product instructions correctly

• Your mains electricity supply is functional

• The defect is not due to a blown fuse

If you wish to claim under this Guarantee you should:

• Send the product, postage or carriage paid, to the dealer from whom it was purchased or to Dualit direct

• Ensure that the product is clean and packed carefully (preferably in its original carton)

• Enclose details of your name, address and telephone number and when and where the product was purchased, together with

proof of purchase (e.g. a till receipt)

• Give exact details of the nature of the defect

This Guarantee does not cover any other claims whatsoever, including, without limitation, any liability for incidental, indirect or

consequential damage, nor does it cover any claims for conversion or modication or for the costs of repair carried out by any third

party without the prior consent of Dualit. If replacement parts are tted to the product this will not extend the period of the guarantee.

For further advise contact the Dualit Customer Helpline on: +44 (0)1293 652 500 (09:00 to 17:00 Monday to Friday).

Alternatively, email Dualit at [email protected] or visit www.dualit.com.

This product is covered by the waste electrical and electronic equipment (WEEE) regulations. It should not be discarded

with normal household waste, but taken to a local collection centre for recycling. For further information, please contact

the local authority or approved disposal agency.

Dispose of all packaging responsibly.

GUARANTEE

Disposal and the Environment

Issue 7 - 0911

Dualit, County Oak Way, Crawley, West Sussex, RH11 7ST

Telephone: +44 (0) 1293 652 500 Fax: +44 (0) 1293 652 555

Email: [email protected] www.dualit.com

Inhaltsverzeichnis

Andere Dualit Grill Handbücher

Dualit

Dualit RCG1 Bedienungsanleitung

Beliebte Grill Handbücher anderer Marken

Orbegozo

Orbegozo GR 2300 Bedienungsanleitung

bora

bora PT11 Bedienungsanleitung

Klarstein

Klarstein 10031664 Bedienungsanleitung

Garland

Garland MWE3W Bedienungsanleitung

Char-Broil

Char-Broil 463722714 Bedienungsanleitung

Nexgrill

Nexgrill 720-0830HK Bedienungsanleitung

Kenmore

Kenmore 415.16123800 Bedienungsanleitung

Camp Chef

Camp Chef PG24CLAU Bedienungsanleitung

Tucker Barbecues

Tucker Barbecues GTR Series Montageanleitung

Monogram

Monogram ZGG540NCP1SS Bedienungsanleitung

Equipex

Equipex Sodir Savoy Bedienungsanleitung

Gaggenau

Gaggenau VR 414 610 Bedienungsanleitung

Miele

Miele KM 408-1 Bedienungsanleitung

George Foreman

George Foreman GGR50B Bedienungsanleitung

AOG

AOG T series Bedienungsanleitung

Gorenje

Gorenje TG2000CB Bedienungsanleitung

Weber

Weber Genesis Silver-B Permamount NG 051701 Bedienungsanleitung

Glen

Glen SA 3037 Bedienungsanleitung
