DURKOPP ADLER 911 Produkthandbuch

911

CNC-controlled sewing unit with large

sewing area

Operating Instructions

Installation Instructions

Service Instructions

Postfach 17 03 51, D-33703 Bielefeld Potsdamer Straße 190, D-33719 Bielefeld

Telefon +49 (0) 5 21/ 59 25-00 Telefax +49 (0) 5 21/ 9 25 24 35 www.duerkopp-adler.com

Ausgabe / Edition: Änderungsindex Teile-Nr./Part.-No.:

08/2010 Rev. index: 00.0 Printed in Federal Republic of Germany 0791 911001

Property of Dürkopp Adler AG and copyrighted. Reproduction or publication of the content in any

manner, even in extracts, without prior written permission of Dürkopp Adler AG, is prohibited.

Foreword

This instruction manual is intended to help the user to become familiar

with the machine and take advantage of its application possibilities in

accordance with the recommendations.

The instruction manual contains important information on how to

operate the machine securely, properly and economically. Observation

of the instructions eliminates danger, reduces costs for repair and

down-times, and increases the reliability and life of the machine.

The instruction manual is intended to complement existing national

accident prevention and environment protection regulations.

The instruction manual must always be available at the machine/sewing

unit.

The instruction manual must be read and applied by any person that is

authorized to work on the machine/sewing unit. This means:

–Operation, including equipping, troubleshooting during the work

cycle, removing of fabric waste,

–Service (maintenance, inspection, repair) and/or

–Transport.

The user also has to assure that only authorized personnel work on the

machine.

The user is obliged to check the machine at least once per shift for

apparent damages and to immediatly report any changes (including the

performance in service), which impair the safety.

The user company must ensure that the machine is only operated in

perfect working order.

Never remove or disable any safety devices.

If safety devices need to be removed for equipping, repairing or

maintaining, the safety devices must be remounted directly after

completion of the maintenance and repair work.

Unauthorized modification of the machine rules out liability of the

manufacturer for damage resulting from this.

Observe all safety and danger recommendations on the machine/unit!

The yellow-and-black striped surfaces designate permanend danger

areas, eg danger of squashing, cutting, shearing or collision.

Besides the recommendations in this instruction manual also observe

the general safety and accident prevention regulations!

General safety instructions

The non-observance of the following safety instructions can cause

bodily injuries or damages to the machine.

1. The machine must only be commissioned in full knowledge of the

instruction book and operated by persons with appropriate training.

2. Before putting into service also read the safety rules and

instructions of the motor supplier.

3. The machine must be used only for the purpose intended. Use of

the machine without the safety devices is not permitted. Observe all

the relevant safety regulations.

4. When gauge parts are exchanged (e.g. needle, presser foot, needle

plate, feed dog and bobbin) when threading, when the workplace is

left, and during service work, the machine must be disconnected

from the mains by switching off the master switch or disconnecting

the mains plug.

5. Daily servicing work must be carried out only by appropriately

trained persons.

6. Repairs, conversion and special maintenance work must only be

carried out by technicians or persons with appropriate training.

7. For service or repair work on pneumatic systems, disconnect the

machine from the compressed air supply system (max. 7-10 bar).

Before disconnecting, reduce the pressure of the maintenance unit.

Exceptions to this are only adjustments and functions checks made

by appropriately trained technicians.

8. Work on the electrical equipment must be carried out only by

electricians or appropriately trained persons.

9. Work on parts and systems under electric current is not permitted,

except as specified in regulations DIN VDE 0105.

10. Conversion or changes to the machine must be authorized by us

and made only in adherence to all safety regulations.

11. For repairs, only replacement parts approved by us must be used.

12. Commissioning of the sewing head is prohibited until such time as

the entire sewing unit is found to comply with EC directives.

13. The line cord should be equipped with a country-specific mains

plug. This work must be carried out by appropriately trained

technicians (see paragraph 8).

It is absolutely necessary to respect the safety

instructions marked by these signs.

Danger of bodily injuries !

Please note also the general safety instructions.

Contents Page:

Preface and General Safety Instructions

Part 1: Operating Instructions Cl. 911 - Original Instructions

(Edition 08/2010)

1 Product Description ..............................................3

2 Designated Use .................................................5

3 Subclasses ....................................................5

4 Optional Equipment...............................................6

5 Technical Data ..................................................7

6 Operation

6.1 Switchingon-Switchingoff-Safestop-Quickstop...........................8

6.2 Raisingthemachinehead...........................................11

6.3 Changingtheneedle..............................................12

6.4 Threadingtheneedlethread .........................................13

6.5 Adjustingthethreadregulator ........................................14

6.6 Winding on the hook thread..........................................15

6.7 Changing the hook-thread bobbin ......................................16

6.8 Setting the hook thread tension .......................................17

7 Operating the control unit of the 911

7.1 Thecontrolpanel................................................18

7.2 Operatingthetouchscreenpanel......................................18

7.3 Thestartscreen.................................................22

7.4 Themainscreen.................................................23

7.5 Popupmenustructure.............................................24

7.6 Menuitem“File”.................................................25

7.7 Menuitem“Edit” ................................................29

7.8 Menuitem“Extras”...............................................41

7.9 Menuitem“Correction”............................................49

7.10 Menuitem“?”..................................................50

7.11 Teach-in......................................................51

7.12 Repairmode...................................................55

7.13 Thread breakage ................................................56

8 DA-CAD 5000 ..................................................57

Contents Page:

9 Error messages/Information messages

9.1 Errormessages.................................................59

9.2 Informationmessages.............................................63

10 Maintenance

10.1 Cleaning and Checking ............................................64

10.2 OilLubrication..................................................65

1 Product Description

CNC-controlled sewing unit based on the class 867 with large sewing

area (sewing field size 300 x 200 mm) and a DAC III control unit with

special software.

For technical textiles manufacturers, motor vehicle equipment

manufacturers, seat manufacturers (automotive), bag, case and

backpack manufacturers (leather/textile), shoe manufacturers.

For the following applications:

Bartacks on load-bearing straps, lowering harnesses, safety

harnesses, lashing straps; Attaching of labels and facing pieces;

Decorative seams on shoes and legs of boots, decorative seams in

special applications.

Material:

Straps, ropes, leather, webbing, airbag materials, leather cut, foam

laminate, leather- laminate- and textile plastics

Double-lockstitch machine equipped with:

Automatic sewing foot and clamp lifting, sewing stroke adjustment,

thread trimmer, needle thread monitoring, thread pulling device and

multiple thread tension.

Technical specifications

The sewing unit is driven by a positioning drive.

With the control unit DACIII are operated apart from the sewing drive

also two step motors needed for the X and Y motions of the seam

geometry and a Z axis for the adjustment of the sewing foot.

The arm shaft of the sewing unit is directly driven by a brushless DC

motor.

·Max. speed 3,000 U/min.

·Stitch length up to 12.7 mm.

·99 program memory locations are available.

·The programs can be sewn individually or in sequences.

·Motor driven sewing foot lifting.

·Pneumatic driven clamp opening/closing.

·The maximum size of the sewing field is 300 mm in X direction and

200 mm in Y direction.

·Central oil wick lubricating for the machine head and the hook.

·Equipped with a vertical hook

·The BFT graphical control panel OP 7000 serves as control

element.

With electronic needle thread monitor.

In order to generate a clean seam pattern, the sewing unit is equipped

with a multiple thread tension device, permitting to assign to various

thread pulling directions the according tension value previously saved

in the sewing program.

The thread pulling device allows pulling the needle thread under the

sewing material during the first stitch.

The sewing unit is equipped with a programmable stitch counter for

the hook thread monitoring and a piece counter.

Integrated test and check program for service and maintenance

works. In addition to the monitoring of the sewing process, it is also

possible to check the motor functions, the inputs and outputs for the

reference switches, the valves and the feeding motors. The program

also serves for the adjustment of machine functions and the preparing

of sewing programs by the teach-in method.

Individual stitch parameter per stitch in order to control external units

like:

·The stroke position of the presser foot, thread trimmer, thread

clamp,

·Speed, thread tension etc.

The height of the stand can be adjusted with the telescoping feet from

a minimum work height of 760 mm to a maximum work height of 910

mm for stand-up working.

The foot pedal needed to operate the sewing unit can be shifted to

allow an ergonomic adaption to the operator.

2 Designated Use

The class 911 is a sewing unit that is designated for the sewing of

light to medium-heavy material. Such material is generally made of

textile fibers, composite materials but it may also consist of leather.

Suchlike material is used in the clothing industry and for domestic and

motor-vehicle upholstery.

This sewing unit can also be used to produce so-called technical

seams. In this case however, the operator must assess the possible

dangers which may arise (DÜRKOPP ADLER AG will be happy to offer

its assistance), since such applications are relatively rare and at the

same time can be so varied that no single set of criteria can cover

them all. The outcome of this assessment may require appropriate

safety measures to be taken.

Generally only dry material may be sewn with this sewing unit. The

material may be no thicker than 4 mm when compressed by the

lowered workclamp. The material may not contain any hard objects.

The seam is generally produced with textile-fibre sewing thread

(cotton threads, synthetic yarns of covering yarns) with the following

dimensions:

Class 911 thread thickness 15/3 - 120/3

Before using any other thread the possible dangers arising have to be

assessed and appropriate safety measures if necessary taken.

This sewing unit may be set up and operated only in dry,

well-maintained premises. If the sewing unit is used in

premises which are not dry and well-maintained it may be

necessary to take further precautions which should be agreed in

advance (see EN 60204-31:1999).

As manufacturers of industrial sewing machines we proceed on the

assumption that personnel who work on our products will have

received training at least sufficient to acquaint them with all normal

operations and with any hazards which these may involve.

3 Subclasses

Cl. 911-210 CNC-controlled sewing unit based on the class 867 with large sewing

area (sewing field size 300 x 200 mm) and a DAC III control unit with

special software.

4 Optional Equipment

For the sewing unit 911 the following optional equipment is available:

Optional equipment Order-No. Remark

Reception P.-Clamp 0911 457554 Kit for the reception of the parallel

clamp actuation

Bow f. P.- Clamp 0911 457604 Bow holding fixture for the clamping plate

P.-set of clamps HF 0911 417604 parallel set of clamps HF (bow bracket)

P.-set of clamps prg.1 0911 417634 Finished set of clamps f. parallel

clamp act. prg.1

P.-set of clamps prg.2 0911 417644 Finished set of clamps f. parallel

clamp act. prg.2

P.-set of clamps prg.3 0911 417654 Finished set of clamps f. parallel

clamp act. prg.3

L-bracket f. P.-Clamp 0911 457614 Kit L-bracket for reception of the divided

clamp (parallel)

P.-set of clamps HF div. 0911 417614 P.-set of clamps HF, divided, fastening with L-bracket

P.-set of clamps div. prg.1 0911 417664 Finished P.-set of clamps for divided clamp pgr.1

P.-set of clamps div. prg.2 0911 417674 Finished P.-set of clamps for divided clamp pgr.2

P.-set of clamps div. prg.3 0911 417684 Finished P.-set of clamps for divided clamp pgr.3

P.-set of clamps HF div. 0911 417624 P.-set of clamps HF, divided, fastening w. L-bracket

closed frame

P.-set of clamps div. prg.1 0911 417694 Finished P.-set of clamps, div., with

closed frame prg.1

P.-set of clamps div. prg.2 0911 417704 Finished P.-set of clamps, div., with

closed frame prg.2

P.-set of clamps div. prg.3 0911 417714 Finished P.-set of clamps, div., with

closed frame prg.3

Reception f. change-over clamp 0911 457564 Kit for the reception of the change-over clamp

C.-set of clamps HF 0911 417524 Change-over set of clamps HF

C.-set of clamps prg.1 0911 417554 Finished change-over set of clamps prg.1

C.-set of clamps prg.2 0911 417564 Finished change-over set of clamps prg.2

C.-set of clamps prg.3 0911 417574 Finished change-over set of clamps prg.3

Kit reduced pressure 0911 597544

Kit barcode reader 0911 597554

Set throat plate 0911 597504 Throat plate for processing thin materials

Set presser foot 0911 597514 Presser foot

Jumping foot 0467 220283 For thin material

Sewing lamp complete 9822 510026

Table clamp 9822 510027

Pneumatic connection package 0797 003031

Height adjustment 0911 407524 Table top height adjustable from 800mm to 1050mm

Andere Handbücher für 911

Inhaltsverzeichnis

Andere DURKOPP ADLER Nähmaschine Handbücher

DURKOPP ADLER

DURKOPP ADLER 745-34 - Bedienungsanleitung

DURKOPP ADLER

DURKOPP ADLER 745-34-2 Bedienungsanleitung

DURKOPP ADLER

DURKOPP ADLER 745-34 - Bedienungsanleitung

DURKOPP ADLER

DURKOPP ADLER 8967 Bedienungsanleitung

DURKOPP ADLER

DURKOPP ADLER 911-211 Betriebsanleitung

DURKOPP ADLER

DURKOPP ADLER 867 Betriebsanleitung

DURKOPP ADLER

DURKOPP ADLER DAC BASIC - CLASS 271 PART II V 12-2010 Bedienungsanleitung

DURKOPP ADLER

DURKOPP ADLER 911-211 Betriebsanleitung

DURKOPP ADLER

DURKOPP ADLER 367 Bedienungsanleitung

DURKOPP ADLER

DURKOPP ADLER 827-M Bedienungsanleitung

DURKOPP ADLER

DURKOPP ADLER 275 Series Bedienungsanleitung

DURKOPP ADLER

DURKOPP ADLER 381 Bedienungsanleitung

DURKOPP ADLER

DURKOPP ADLER M-Type Premium Series Betriebsanleitung

DURKOPP ADLER

DURKOPP ADLER 610-01 Bedienungsanleitung

DURKOPP ADLER

DURKOPP ADLER 669 ECO Bedienungsanleitung

DURKOPP ADLER

DURKOPP ADLER 969 Classic Betriebsanleitung

DURKOPP ADLER

DURKOPP ADLER DAC BASIC - CLASS 271 PART II V 12-2010 Bedienungsanleitung

DURKOPP ADLER

DURKOPP ADLER 581 Bedienungsanleitung

DURKOPP ADLER

DURKOPP ADLER 7700 Leitfaden

DURKOPP ADLER

DURKOPP ADLER 370 Bedienungsanleitung

DURKOPP ADLER

DURKOPP ADLER DAC classic 281 Bedienungsanleitung

DURKOPP ADLER

DURKOPP ADLER 1265-5 Bedienungsanleitung

DURKOPP ADLER

DURKOPP ADLER beisler 2112-5 Betriebsanleitung

DURKOPP ADLER

DURKOPP ADLER 559 - Benutzerhandbuch

Beliebte Nähmaschine Handbücher anderer Marken

Riccar

Riccar RL634DE Bedienungsanleitung

Singer

Singer 2517 Bedienungsanleitung

Pfaff

Pfaff 3307-1 SERIES Bedienungsanleitung

Janome

Janome Quilt Maker Pro 18 VERSA Bedienungsanleitung

Siruba

Siruba C007JP Bedienungsanleitung

Husqvarna Viking

Husqvarna Viking Designer SE Bedienungsanleitung

Singer

Singer 148-5 Bedienungsanleitung

IKEA

IKEA SY Bedienungsanleitung

Pfaff

Pfaff 571 Bedienungsanleitung

Singer

Singer 15-91 Bedienungsanleitung

Brother

Brother BB370 Bedienungsanleitung

Pegasus

Pegasus WT100 Series Bedienungsanleitung

Reliable

Reliable 7100DB Bedienungsanleitung

Pfaff

Pfaff 937 Bedienungsanleitung

Singer

Singer 6038 Bedienungsanleitung

Singer

Singer 413K Bedienungsanleitung

Pfaff

Pfaff 1471 E1 Bedienungsanleitung

Kenmore

Kenmore 16677 - Serger Sewing Machine Bedienungsanleitung
