WM1080A

GPRS Mobile Modem

Quick Setup Guide

GPRS Mobile Modem Quick Set-up Guide

Important - Before You Start

Prohibited areas

Do not use modem in areas where the use of mobile phones is prohibited.

Examples of such areas are: hospital, petrol station, or on board an aircraft.

Emergency calls

This is a wireless de ice that uses radio frequency signals. Therefore a connection

cannot be guaranteed under all conditions. Check with your network ser ice

pro ider for further details regarding emergency calls. Users should not solely

depend on this mobile de ice for emergency communication.

Global roaming

Check with your network operator regarding using GPRS data roaming and CSD

roaming o erseas and make necessary prior arrangements before tra el. This

product is “dual band” GSM 900/1800 MHz. It is incompatible with the GSM

1900 MHz networks in North America.

To avoid damage to your SIM card or modem

Ne er insert or remo e SIM card when modem is connected to computer.

Do not plug modem into computer with SIM slot co er open.

Do not unplug modem from computer while the iTegno Mobile Office Suite

software is running. Exit from the software before unplugging.

Minimum system requirements

A alid SIM card suitable for use with the Vodafone New Zealand network.

Windows 98, 98SE, ME, 2000 or XP.

15 MB disk space.

CDROM dri e.

USB 1.1 compliant port.

Introduction

GPRS (General Packet Radio Ser ices) is a new ad ancement of the GSM cellular

network. This technology enables the user to make regular oice calls, send and

recei e data, or maintain Internet access anytime and anywhere. This is ideal for

anyone who needs Internet access and mobility, both within New Zealand and

o erseas. When tra elling o erseas the greatest co erage is expected throughout

Asian & European countries.

The main benefits of GPRS are:

“Always on” mobile Internet connecti ity, anywhere and anytime as long as you

are within the cellular network co erage area with adequate signal strength.

Send & recei e files, e-mail, SMS or faxes. 

Charges are only for the amount of data you send and recei e.

Make regular oice calls.

Roaming o erseas.

Your GPRS modem enables you to enjoy all of the abo e. E en if your SIM card

has not been enabled for GPRS, it is possible to use the modem as a GSM modem

for dial-up Internet access, file transfer or faxing at up to 14,400 bps. In contrast

to using a cell phone connected to your computer, the use of this modem truly

deli ers the “always on” connecti ity benefit with GPRS. The modem can remain

connected to the GPRS network whene er the computer is on.

Installation

This guide is intended to take you quickly through the installation. If you require

a step-by-step guide with illustrations, insert the pro ided iTegno CDROM into the

CD-ROM dri e and double click ReadMeFirst-English.htm to iew the user manual.

The next fi e sections are intended to guide you through modem installation and

configuration:

Section Install SIM card into the modem.

Section 2 Connect it to your computer and install the modem dri er.

Either follow section 3, or section 4 depending on your needs:

Section 3 Install the iTegno Mobile Office Suite software. This software is

optional if you intend to browse websites, use e-mail and fax. Install

the software if you want to use phone book, SMS, and making or

recei ing oice calls ia modem.

Section 4 If section 3 is skipped you must follow this section to set up Dial-up

Networking in Windows correctly. At any time you still ha e the option

of following section 3 to install the software.

Section 5 This section is optional. It refers to setting up to use GSM dial-up

(CSD) if GPRS is una ailable.

SIM Card Installation

STEP 1: Ensure PIN protection on the sim card is disabled.

STEP 2: Insert SIM card. Close SIM slot co er. The co er must be closed for modem

to operate properly.

STEP 3: Connect the pro ided USB cable to modem. Next follow the dri er

installation guide below.

GPRS Mobile Modem Quick Set-up Guide

Connect modem to computer & install modem driver

If you require a step-by-step guide with illustrations, insert the pro ided iTegno

CDROM into the dri e. Double click ReadMeFirst-English.htm to iew the “Install

iTegno WM1080A GPRS Modem Dri er” pages.

WINDOWS XP

1. Insert the pro ided iTegno CDROM into the dri e. Next plug the modem into

the USB port of your computer.

2. System will report found new hardware. Select Install the software

automatically (Recommended) - Next. When system pauses during installation

click Continue Anyway to proceed with copying files. The process may take

se eral minutes.

3. Click Finish to complete dri er installation. Once you ha e successfully installed

the dri er in your computer, you will see a blinking light on your modem.

WINDOWS 2000

1. Insert the pro ided iTegno CDROM into the dri e. Next plug the modem into

the USB port of your computer.

2. System will report found new hardware. Click Next and select the option Search

for a suitable driver for my device (recommended). Click Next to proceed.

3. Tick the CD-ROM drives option. Click Next - Next and then Yes in response

to the “Digital Signature Not Found” message. The system will start copying

files and the process may take se eral minutes.

4. Click Finish to complete dri er installation. Once you ha e successfully installed

the dri er in your computer, you will see a blinking light on your modem.

WINDOWS ME

. Insert the pro ided iTegno CDROM into the dri e. Next plug the modem into

the USB port of your computer.

2. System will report new hardware found. Select automatic search for a better

driver (Recommended) - Next. The system will start copying files and the

process may take se eral minutes.

3. Click Finish to complete dri er installation. Once you ha e successfully installed

the dri er in your computer, you will see a blinking light on your modem.

WINDOWS 98

. Insert the pro ided iTegno CDROM into the dri e. Next plug the modem into

the USB port of your computer.

2. System will report new hardware found. Click Next to start the installation

process. Select Search for the best driver for your device (Recommended).

Click Next to proceed.

3. Tick the CD-ROM drive option. Click Next to continue. The system will start

copying files and the process may take se eral minutes.

4. Click Finish to complete dri er installation. Once you ha e successfully installed

the dri er in your computer, you will see a blinking light on your modem.

Install the iTegno Mobile ffice Suite Software

The iTengo Mobile Office Suite provides an integrated environment for managing

the phone book, SMS and voice calls via modem. If you do not wish to use

these functions, you may go to section 4 and set up Dial-up Networking for

Internet & e-mail.

SOFTWARE INSTALLATION:

. Exit from all running Windows programs.

2. Insert the iTegno CDROM.

3. Double click My Computer.

4. Double click iTegno WM 080A (your CDROM dri e).

5. Double click the folder iTegno Mobile Office.

6. Double click Setup.

7. Click Next - Next - Next to install the complete program features.

8. Click Install to begin the installation process.

It may take se eral minutes to complete.

9. Click Finish on completion.

After successful installation, the icon iTegno Mobile Office Suite will appear on

your desktop. Double click the icon to launch the application and set up a

connection for modem.

SET UP CONNECTION FOR MODEM:

Double click on the icon iTegno Mobile Office Suite on your desktop to launch

the application.

. Click on the icon Settings on left hand side of menu.

2. Select Modem Setting.

3. Click Wizard and select

New Zealand Vodafone GPRS

from the pull down list.

4. Click Create, then OK to confirm

and then click Close. The default

APN is www. odafone.net.nz.

Only if the network operator

specifies a different APN, edit the

new setting under APN by typing

o er the default.

5. Only if the network operator

specifies a dial string other than

*99*** # or *99#, click on Edit and

enter new dial string under Phone

number. Otherwise go to Step 6.

6. Click the Sa e button and then

OK to confirm sa ing the setting.

A Dial-Up Networking icon for

connecting to your GPRS network

pro ider is created. The next section

should be skipped.

GPRS Mobile Modem Quick Set-up Guide

Configure Windows Dial-up Networking

Skip this section if you ha e already followed through Section 3. Points to note:

1. Select iTegno WM 080 Modem if you ha e more than one modem a ailable.

2. Authentication information is stored on your SIM card. When using Dial-Up

Networking there is no need to enter user name and password. Lea e these

fields blank.

3. Use either *99# or *99*** # as phone number. *99*** # is the standard to

use if you are roaming o erseas.

4. Do not use dialling rule or area code because this is a direct connection to

the cellular network. Double click on the connection icon and then select properties

to ensure no dial modifiers are inserted.

WINDOWS XP

Go to Control Panel - Network Connections. Select Create a new connection -

Next. Select Connect to the Internet - Next - Set up my connection manually -

Next - Connect using a dial-up modem – Next.

Enter a name for the connection and click Next. Enter *99# as Phone number.

In Internet Account Information page, lea e user name and password as blank.

Click Next – Finish.

WINDOWS 2000

Go to Control Panel - Network & Dial-Up Connections. Double click Make New

Connection and then Next. Select Dial-up to private network - Next. Enter *99#

into Phone Number. Do not select Use dialling rules, click Next. On the next

screen select either “For all users” or “Only for myself” then Next. Enter a name

for the connection and click Finish.

WINDOWS ME

Go to Control Panel - Dial-Up Networking. Double click Make New Connection.

Enter a name for the connection. Select iTegno WM 080 Modem from the pull

down list. Click Next to continue. On the next screen lea e area code as blank,

and enter *99# into Telephone Number. Then Next - Finish.

WINDOWS 98

Go to My Computer - Dial-Up Networking. Double click Make New Connection.

Enter a name for the connection. Select iTegno WM 080 Modem from the pull

down list, click Next to continue. On the next screen lea e area code as blank,

and enter *99# as Telephone Number. Then Next - Finish.

Set up modem to use GSM dial-up connection

This is often referred to as CSD (Circuit Switched Data). Compared with GPRS,

the network operator charges CSD for the time used instead of traffic olume.

CSD is usually a more expensi e option to use than GPRS. If your SIM card has

not been enabled for GPRS or GPRS is una ailable, set up modem according to

the procedure in the next paragraph.

You must ha e an Internet access account with an ISP if you want to access Internet

ia CSD. In all aspects this is the same as using a landline except the call is going

through the cellular network. If intended to use CSD o erseas check with your

network operator for CSD roaming before departure. To set up modem follow the

same procedure as in section 4, but substitute parameters as in table below.

Documentation for Itegno Mobile ffice Suite

A complete user manual is pro ided on the CDROM.

Insert the pro ided iTegno CDROM into the dri e and double click ReadMeFirst-

English.htm. Next click on Click here to start and then User Manual to iew.

Phone number *99# OR *99***1# Your ISP’s access number

User name Lea e blank ISP specified user name

Password Lea e blank ISP specified password

GPRS CSD

GPRS Mobile Modem Quick Set-up Guide

Troubleshooting

The iTegno CDROM contains more troubleshooting tips for the iTegno Mobile

Office Suite software.

Modem LED does not come on

Check that the USB cable is connected to both computer and modem. If necessary,

disconnect the USB cable and reconnect. Reboot the computer.

Modem LED does not blink but remains solid

Typically it takes 30 seconds for the modem to synchronise with the network.

Check that the SIM card is inserted correctly and SIM slot co er is

closed properly.

Disable PIN protection of SIM card. You can check the status using your

cellular handset.

No GPRS connection possible

Check that the modem LED blinks. Make sure the SIM card is GPRS enabled. If

necessary, contact network operator to erify. Call 977 on your cellular phone to get

Vodafone New Zealand to enable GPRS on the SIM card you will use in the modem.

Cannot make or receive voice calls via modem

This modem is oice capable. You need to run iTegno Mobile Office Suite software

and use the earpiece pro ided with the modem.

Modem cannot be detected, or errors such as "hardware failure” come up when

trying to use modem from another application

Check that the iTegno Mobile Office Suite software is not running when you use

the modem with other applications. This includes running your browser or e-mail

program. The iTegno software holds the communication port of the modem, thus

making the communication port una ailable to other programs.

Cannot download e-mail from my ISP

If you are an Xtra customer, email can only be downloaded if you connect to Xtra

directly. Your GPRS modem does not connect directly to Xtra, it connects to

Vodafone. There are two workarounds:

Go to Xtramail (web-based e-mail) from your browser and login as usual.

Set up modem to use GSM dial-up to connect directly to Xtra and download

e-mail. See section 5 Set up modem to use GSM dial-up connection.

GPRS Mobile Modem Quick Set-up Guide

Notes

Inhaltsverzeichnis

Andere Dynalink Modem Handbücher

Dynalink

Dynalink RTA1025W Bedienungsanleitung

Dynalink

Dynalink RTA1025WV6 Bedienungsanleitung

Dynalink

Dynalink ALE800 Bedienungsanleitung

Dynalink

Dynalink ALE070 Bedienungsanleitung

Dynalink

Dynalink RTA770 Bedienungsanleitung

Dynalink

Dynalink RTA100+ Bedienungsanleitung

Dynalink

Dynalink RTA1046VW Bedienungsanleitung

Dynalink

Dynalink 56USBPRO Bedienungsanleitung

Dynalink

Dynalink WLG25USB Bedienungsanleitung

Dynalink

Dynalink RTA1320 Bedienungsanleitung

Dynalink

Dynalink 56K e-modem III Bedienungsanleitung

Dynalink

Dynalink u90E-RURALII Bedienungsanleitung

Dynalink

Dynalink DY56EXT3 Bedienungsanleitung

Dynalink

Dynalink 1456VQE-C Bedienungsanleitung

Dynalink

Dynalink RTA1320 Bedienungsanleitung

Beliebte Modem Handbücher anderer Marken

Davicom

Davicom DM562AP Bedienungsanleitung

EpiValley

EpiValley TATA indicom SXC-1080 Bedienungsanleitung

Zte

Zte WiMAX Bedienungsanleitung

Intelimax

Intelimax MA-2060 Bedienungsanleitung

SMC Networks

SMC Networks D3CM1604V Gebrauchs- und Pflegehandbuch

Telstra

Telstra Wi-Fi 4G Advanced Pro X Bedienungsanleitung

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Bedienungsanleitung

Samsung

Samsung AceLink SAM-335A Bedienungsanleitung

Enfora

Enfora Enabler-G Kurzanleitung zur Einrichtung

iRZ

iRZ ATM2-232 Bedienungsanleitung

Zhone

Zhone 6310 Bedienungsanleitung

Paradyne

Paradyne Hotwire 7976 Bedienungsanleitung

US Robotics

US Robotics 3453C Bedienungsanleitung

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Bedienungsanleitung

Zte

Zte MF823 Bedienungsanleitung

Four-Faith

Four-Faith F1403 Bedienungsanleitung

Sierra Wireless

Sierra Wireless AIRLINK MP595W Bedienungsanleitung

Gemtek

Gemtek WiMAX WIXFBR-103 Bedienungsanleitung
