EAE ORIA Bedienungsanleitung

Product Manual Oria Thermostat

EAE KNX Oria Thermostat Oria Thermostat PM R1.0

©EAE!Technology!!!!!www.eaetechnology.com!!!!Sayfa!1!/!50!

EAE#ORIA#THERMOSTAT#

Product#Manual#Oria#Thermostat#

Product Manual Oria Thermostat

EAE KNX Oria Thermostat Oria Thermostat PM R1.0

©EAE!Technology!!!!!www.eaetechnology.com!!!!Sayfa!2!/!50!

! !

Content!

1.!General!....................................................................................................................................................!4!

2.!Device!Technology!..................................................................................................................................!4!

2.1!Button!Definitions!...........................................................................................................................!4!

2.2!Connection!Diagram!........................................................................................................................!4!

2.3!Technical!Data!.................................................................................................................................!5!

2.4!Dimensions!......................................................................................................................................!5!

3.!Communication!Object!Table!..................................................................................................................!6!

4.!Parameters!and!Communication!Objects!................................................................................................!8!

4.1!General!............................................................................................................................................!8!

4.1.1!Parameters!..............................................................................................................................!8!

4.1.2!Communication!Objects!..........................................................................................................!9!

4.2! Rockers!and!Push!Buttons!..............................................................................................................!10!

4.2.1

Rockers

!.......................................................................................................................................!10!

4.2.2!Push!Buttons!..........................................................................................................................!19!

4.3

!Temperature!Sensor!..........................................................................................................................!27!

4.3.1!Parameters!................................................................................................................................!27!

4.3.2!Communication!Objects!............................................................................................................!28!

4.4

!Thermostat!........................................................................................................................................!28!

4.4.1

!Parameters!................................................................................................................................!29!

4.4.2

!Communication!Objects!............................................................................................................!30!

4.4.3

!Control!Types!.............................................................................................................................!31!

4.4.3.1

!PI!Continuous!.........................................................................................................................!31!

4.4.3.2

!PI!PWM!..................................................................................................................................!31!

4.4.3.3

!On/Off!...................................................................................................................................!32!

4.4.3.4

!Fan!coil!...................................................................................................................................!32!

4.4.3.5

!Split!........................................................................................................................................!32!

4.4.4

!Heating!Control!..........................................................................................................................!32!

4.4.4.1

!PI!Continuous!.........................................................................................................................!32!

4.4.4.2

!PI!PWM!..................................................................................................................................!33!

Product Manual Oria Thermostat

EAE KNX Oria Thermostat Oria Thermostat PM R1.0

©EAE!Technology!!!!!www.eaetechnology.com!!!!Sayfa!3!/!50!

4.4.4.3

!On/Off!...................................................................................................................................!34!

4.4.4.4

!Fan!Coil!..................................................................................................................................!35!

4.4.4.5

!Split!Unit!................................................................................................................................!36!

4.4.5!Cooling!Control!..........................................................................................................................!37!

4.4.5.1!PI!Continuous!.........................................................................................................................!38!

4.4.5.2!PI!PWM!..................................................................................................................................!39!

4.4.5.3!On/Off!...................................................................................................................................!40!

4.4.5.4!Fan!Coil!..................................................................................................................................!41!

4.4.5.5!Split!Unit!................................................................................................................................!42!

4.4.6!Fan!Control!................................................................................................................................!43!

4.4.6.1!Parameter!..............................................................................................................................!44!

4.4.6.2!Communication!Objects!........................................................................................................!44!

4.5!Setpoints!...........................................................................................................................................!45!

4.5.1!Setpoint!Limitations!...................................................................................................................!46!

4.5.2!Operating!Modes!.......................................................................................................................!46!

4.5.3!Reset!on!Site!..............................................................................................................................!47!

4.5.4!Parameters!................................................................................................................................!47!

4.5.5!Communication!Objects!............................................................................................................!48!

4.6!Status!.................................................................................................................................................!49!

4.6.1!Parameters!................................................................................................................................!49!

4.6.2!Communication!Objects!............................................................................................................!49!

4.7!Local!Control!...........................................................................................................................................!50!

4.7.1!Parameters!.......................................................................................................................................!50!

! !

Product Manual Oria Thermostat

EAE KNX Oria Thermostat Oria Thermostat PM R1.0

©EAE!Technology!!!!!www.eaetechnology.com!!!!Sayfa!4!/!50!

1. General,,

Extendable!up!to!4!folds,!Oria!thermostats!offer!a!wide!range!of!functional!flexibility!with!integrated!

programmable!switches.!

Buttons!on!Oria!thermostats!can!be!programmed!to!control!lighting,!shutter/blind!drivers,!speakers,!make!

scene!calls!and!mimic!panic!buttons.!Each!button!can!be!programmed!independently!for!a!different!function.!!

2. Device,Technology,

2.1 Button,Definitions,

1.!Programmable!Button!Group!1!!!!!!!!!!!!!2.!Fan!

Speed!(1,!2,!3,!A)! ! !!!!!!!!!!!3.!Operation!

Mode!(Comfort,!Night,!Away,!OFF)!4.!Setpoint!

Temperature!UP!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!5.!Setpoint!

Temperature!DOWN!!!!!!!!!!!!!!!!!!!!!!!!!!!6.!Programmable!

Button!Group!2!

2.2 Connection,Diagram,

1.!KNX!Port!Terminal!

2.!Programming!Button!

3.!Programming!LED!

Product Manual Oria Thermostat

EAE KNX Oria Thermostat Oria Thermostat PM R1.0

©EAE!Technology!!!!!www.eaetechnology.com!!!!Sayfa!5!/!50!

2.3 Technical,Data,

2.4 Dimensions,

Protection!Type!

IP20!

EN!60529!

Safety!Class!

II!

EN!61140!

Supply!

Voltage!Range!

Supply!Voltage!

Power!Consumption!

21-30V!DC,!Supply!from!EIB/KNX!line!

20!mA!

20!mA!x!30V!

Operation!LEDs!

Programming!LED!for!each!fold!

1!to!5!RGB!LEDs!for!physical!address!

identification!

Button!Operation!Life!

100.000!

Temperature!

Operating!

Storage!

Transport!

-5°!C!!!!!!!!+!45°!C!

-25°!C!!!!!!+!55°!C!

-25°!C!!!!!!+!70°!C!

CE!

In!accordance!with!EMC!guideline!

and!low!voltage!regulation!

Product Manual Oria Thermostat

EAE KNX Oria Thermostat Oria Thermostat PM R1.0

©EAE!Technology!!!!!www.eaetechnology.com!!!!Sayfa!6!/!50!

! !

3. Communication,Object,Table,

No.

Object Name

Function

Number of Bits

Flags

General, operation

Active

Rocker 1, switch

On/Off

CWT

Rocker 1, shutter

Up/Down

CWT

Rocker 1, value[0,1]

Send

CWT

Rocker 1, value[0…255]

Send

CWT

Rocker 1, value[0…65535]

Send

CWT

Rocker 1, value[-32768…32768]

Send

CWT

Rocker 1, value[0…4294967295]

Send

CWT

Rocker 1, value.temperature

Send

CWT

Button 1, switch

On/Off

CWT

Button 1, shutter

Up/Down

CWT

Button 1, value[0,1]

On/Off

CWT

Button 1, value[0...255]

Send

CWT

Button 1, value[0..65535]

Send

CWT

Button 1, value[-32768…32768]

Send

CWT

Button 1, value[0…4294967295]

Send

CWT

Button 1, value.temperature

Send

CWT

Rocker 1, dimming

Send

CWT

Rocker 1, shutter

Stop/Lamella Adj

CWT

Button 1, dimming

Send

CWT

Button 1, shutter

Stop/Lamella Adj

CWT

Button 1, value[0,1]

On/Off

CWT

Button 1, value[0…255]

Send

CWT

Button 1, value[0…65535]

Send

CWT

Button 1, value[-32768…32768]

Send

CWT

Button 1, value[0…4294967295]

Send

CWT

Button 1, value.temperature

Send

CWT

Rocker 1, shutter

Top Position

CWT

Rocker 1, status

Top Position

CWT

Button 1, shutter

Top Position

CWT

Button 1, status

Top Position

CWT

Rocker 1, shutter

Bottom Position

CWT

Button 1, shutter

Bottom Position

CWT

Product Manual Oria Thermostat

EAE KNX Oria Thermostat Oria Thermostat PM R1.0

©EAE!Technology!!!!!www.eaetechnology.com!!!!Sayfa!7!/!50!

Window Status

Open/Close

Regulation

On/Off

CWT

Split Heat

On/Off

Split Cool

On/Off

Split Heat Error

True/False

Split Coo Error

True/False

Current Temperature

Temperature

CRT

Current Setpoint

Temperature

CRT

Operating Mode

Send

Comfort Mode

Enable

Night Mode

Enable

Away Mode

Enable

Protect Mode

Enable

Heat Control Value

On/Off

Heat Control Value

Send

Cool Control Value

On/Off

Cool Control Value

Send

Switchover

Control Mode

CRWT

Switchover

Control Mode Status

CRT

Switchover

Control Mode

CRWT

Switchover

Control Mode Status

CRT

Status Heat

On/Off

CRT

Status Cool

On/Off

CRT

Automatic Fan Speed

On/Off

CWT

Fan Speed

Send

CWT

Fan Speed 1

Enable

CWT

Fan Speed 2

Enable

CWT

Fan Speed 3

Enable

CWT

Setpoint Comfort (°C)

Temperature

Setpoint Comfort (°F)

Temperature

Setpoint Night (°C)

Temperature

Setpoint Night (°F)

Temperature

Setpoint Away (°C)

Temperature

Setpoint Away (°F)

Temperature

Reset OnSite

0/1

Status Operating Mode

Send

CRT

Status Comfort

True/False

CRT

Status Night

True/False

CRT

Product Manual Oria Thermostat

EAE KNX Oria Thermostat Oria Thermostat PM R1.0

©EAE!Technology!!!!!www.eaetechnology.com!!!!Sayfa!8!/!50!

Status Away

True/False

CRT

Status Protect

True/False

CRT

4. Parameters,and,Communication,Objects,

4.1,General,

General parameters includes configuration of “in operation bit”, total rocker count, telegram limitations,

window status, LED and LCD controls.

Figure 1

4.1.1 Parameters,

Parameter

Settings

Description

Enable In Operation

Enable/Disable

In operation can be used to ensure

that device is alive and connected

to KNX line.

In Operation Bit

Off/On

Visible when “Enable In

Operation” enabled. Bit value to

send as device alive operation

In Operation Send Interval[sec]

0…

300

…65535

Visible when “Enable In

Operation” enabled. Cyclic time

period for sending in operation bit

Enable Telegram Limit

Enable/Disable

Limits the number of telegrams to

send in certain time period

Product Manual Oria Thermostat

EAE KNX Oria Thermostat Oria Thermostat PM R1.0

©EAE!Technology!!!!!www.eaetechnology.com!!!!Sayfa!9!/!50!

Telegram Limit Period Duration

50ms, 100ms, …, 30sn, 1min

Visible when “Enable Telegram

Limit” enabled. Time period to

check telegram numbers

Maximum Telegram Count in

Period

1..

100

…255

Visible when “Enable Telegram

Limit” enabled. Maximum number

of telegrams to send in telegram

limit period duration

Light Duration of LED

0,75s

, 2.25s, 3.25s

LEDs on duration when status LEDs

used as status indication with

rocker or push buttons.

Rocker Count

2, 3 ,4

Number of rockers should be

selected compatible with device to

be able to use rockers and push

buttons correctly.

Window Status

Enable/Disable

Enables communication object

which will be used to detect

window status. When window

detected as open thermostat

automatically enters “Protect

Mode” with error and detected as

close will return to the previous

mode.

LCD Backlight Control *[1]

Always On

LCD backlight always %100

brightness.

Dimmed After Timeout

Normally %30 brightness, after a

button pressed %100 brightness

for 5 seconds, then returns to %30

brightness

LCD Setpoint Segment

Enable/Disable

When disabled current setpoint

value will replace temperature

segment on LCD and blink for a

few seconds, otherwise additional

setpoint segment will be used.

Table 2

*[1]

LCD Backlight Control: Additional to the LCD backlight control through “LCD Backlight Control” parameter,

LCD has another method to control backlight. Pressing “Setpoint Decrease Button” for longer than 6 seconds

will dim the backlight to %10 brightness. If the LCD backlight control is selected as “Dimmed After Timeout”,

pressing buttons will no longer have any effect on the backlight brightness. Pressing “Setpoint Increase Button”

for longer than 6 seconds causes the brightness levels to return to normal mode.

4.1.2,Communication,Objects,

Object Name

Function

Data Type

Flags

General – In operation

Active

1 Bit

DPT 1.002

In operation value (0,1) selected through “In operation bit” parameter will be send via the group address

which is linked to this communication object

Window Status

Open/Close

1 bit

DPT 1.009

CWT

Product Manual Oria Thermostat

EAE KNX Oria Thermostat Oria Thermostat PM R1.0

If window status enabled, this communication object will be used to detect window status. If window

detected as open thermostat will enter protect mode and will not response mode change commands (over

communication object or operating mode button) until window detected as closed through this

communication object.

Table 3

4.2,Rockers,and,Push,Buttons,

Total number of rockers can be selected through “Rocker Count” parameter in “General” tab. Buttons on the

thermostat can be used as rockers or push buttons. Select the desired operation from the “Rocker N” (N:

Rocker number) tab (Figure 2). If configured as push buttons, 2 push button tabs will be visible under “Rocker

N” tab (Figure 3). Both rockers and push button have 5 functions, no function, switch, switch and dim, shutter

and value operation.

Figure2

Figure3

4.2.1,Rockers

Number of rockers should be selected in “General” tabs in parameters and should be chosen as compatible

with the device that will be configured. Rockers are numbered from top to bottom, topmost rocker as Rocker 1,

below it Rocker 2, and so on. Rockers can be configured as 4 different operations and 1 function to disable

rocker (No Function). Operation selection can be configured with “Rocker Function” parameter. Every function

enables different parameters and communication objects that will be explained in the following chapters.

Parameter

Setting

Description

Rocker Operation

Rocker/2 Push Button

Selects the function of rocker

Rocker Function

No Function

Disables the rocker

Switch

Rocker can be used to send on/off

telegrams. (For more information

Chapter 4.2.1.1)

Switch and Dim

Rocker can send on/off and

dimming telegrams. (For more

information Chapter 4.2.1.2)

Inhaltsverzeichnis

Andere EAE Thermostat Handbücher

EAE

EAE ROSA Bedienungsanleitung

Beliebte Thermostat Handbücher anderer Marken

EWELLY

EWELLY EW-181 Bedienungsanleitung

Prolon

Prolon T1100 Montageanleitung

Computherm

Computherm Q20 Bedienungsanleitung

Heatmiser

Heatmiser neoStat Bedienungsanleitung

Aube Technologies

Aube Technologies TH111GFCI-NP 240 VCA Bedienungsanleitung

Mars

Mars HEAT CONTROLLER IR Wireless Thermostat Bedienungsanleitung

Saswell

Saswell SAS920XWHB-7-S-RF Leitfaden

Aircalo

Aircalo TFP1-ET85P2 Bedienungsanleitung

Honeywell

Honeywell CM721 Bedienungsanleitung

Carrier

Carrier DEBONAIR 33CS Bedienungsanleitung

Lennox

Lennox iHarmony Zone Thermostat Montageanleitung

Gemtech

Gemtech GT7000 Bedienungsanleitung

Rollei

Rollei Smartes 45000 Bedienungsanleitung

Sinope

Sinope TH1300RF Bedienungsanleitung

Honeywell

Honeywell RLV4305 Bedienungsanleitung

Honeywell

Honeywell Prestige 2.0 THX9421 Bedienungsanleitung

NuTone

NuTone NTBZ48 Original Betriebsanleitung

Stelpro

Stelpro MAESTRO ASMT402AD Bedienungsanleitung
