EasyN F2 series Bedienungsanleitung

MF2E-E-A4

- 2 -

FORWORD

This series product is integrated webcam focusing on network video

monitoring, including wired box IP camera, wireless box IP camera, wired

IR dome camera, wired waterproof IR IP camera, etc. The media processor

of camera uses high-ability chip to realize audio/video capture,

compression and transmission, the standard Motion-JPEG coding algorithm

can confirm the clear and smooth effect of video transmission. The camera

supports user remote-real-time monitoring through super client software,

system client platform and IE browser, etc.

This series IP camera can be used for remote monitoring locations, such

as enterprises, chain stores, factories and homes, etc. It is simple

pick-up and easy operation.

Please confirm the items to be complete, if there is lost, please contact seller

timely.

ITEMS LIST:

IP camera -------------------------------------------- 1piece

Bracket（referring to model）---------------------- 1piece

Power adapter --------------------------------------- 1piece

Certificate------------------------------------------- 1piece

CD ---------------------------------------------------- 1piece

Warranty card----------------------------------------- 1piece

Instruction:

IP Camera referred is network camera; PC is personal computer; single

click means mouse left click; double click means mouse twice left click.

For IP Camera factory settings:

Administrator user: admin; password: no password

LAN IP address: 192.168.1.126; http port: 81

Statement:

The current device may have different version with the sample in this

manual, if u can not set up device referring to this manual, please contact

provider.

The content will update from time to time, the manufacturer reserves the

right without notice.

MF2E-E-A4

- 3 -

1. PRODUCT OVERVIEW......................................................................................................... - 4 -

2. PRODUCT FEATURE ............................................................................................................ - 5 -

3. DEVICE APPEARANCE AND INTERFACE........................................................................ - 7 -

3.1. DEVICE APPEARANCE.............................................................................................- 7 -

3.2. DEVICE INTERFACE ................................................................................................. - 7 -

4. NETWORK CONNECTION................................................................................................... - 8 -

4.1. CONNECTION INSTRUCTION................................................................................. - 8 -

4.2. ACCESS INSTRUCTION............................................................................................ - 8 -

4.3. CONNECT NETWORK VIAADSL............................................................................ - 9 -

4.4. CONNECT NETWORK VIA ROUTER .................................................................... - 10 -

5. SOFTWARE OPERATION ................................................................................................... - 10 -

5.1. IPcamera TOOL.......................................................................................................... - 10 -

5.2. LOGIN IP CAMERA.................................................................................................. - 11 -

5.3. USER OPERATION ................................................................................................... - 12 -

5.4. MULTIDEVICE CONFIGURATION ........................................................................- 13 -

5.5. NETWORK CONFIGURATION ............................................................................... - 14 -

5.6. DDNS SETTINGS...................................................................................................... - 16 -

5.7. EMAIL SERVICE SETTINGS................................................................................... - 17 -

5.8. MOTION DETECTION ............................................................................................. - 18 -

6. SD CARD GUIDE………………………………………………………………….………_20-

6.1. INSERT SD CARD…………………………………………………………………....-20-

6.2. STORAGE CONFIGURATION……………………………………………………....-21-

6.3. PLAY BACK…………………………………………………………………………..-23-

7. SD CARD PLAYER MANUAL.............................................................................................. -27-

7.1.SYSTEM VEQUIREMENT......

……………………………………………………......-27-

7.2 FUNCTION OPERATION ............................................................................................ -27-

7.3.PIAY VIDEO ................................................................................................................. -29-

8. PORT FORWARDING .......................................................................................................... - 31 -

9. APPENDIX............................................................................................................................ - 32 -

9.1. FAMILIAR PROBLEM.............................................................................................. - 32 -

9.2. WARRANTY.............................................................................................................. - 33 -

9.3. WARRANTY CARD.................................................................................................. - 34 -

MF2E-E-A4

- 4 -

1. PRODUCT OVERVIEW

IP Camera integrates network function and web service function, it can

send video record to anywhere through internet, and we can view real-time

video of site via web browser. And it is suitable for many locations,

such as large stores, schools, factories and homes, etc.

IPCAM basic function of remote video data transmission is basis on MJPEG

hardware compressive technology, the maximum speed of high-quality

image transmission in LAN/WAN can reach 25fps.

IPCAM video data transmission is based on TCP/IP protocol, and it has

built-in Web server to support Internet Explorer, hence, it is more

convenient to manage and maintain device, to remote configure some

options, to update versions.

Please check the product if the items are complete before set-up, if there is

some lost, please contact seller.

MF2E-E-A4

- 5 -

2. PRODUCT FEATURE

● powerful high-speed processor of video protocol

● high sensitivity and definition CMOS sensor

● 0.3 megapixels

● IR night version

● Optimized Motion-JPEG video compression algorithms to achieve narrow

bandwidth high-definition image transmission

● multilevel users and password management

● support many browsers（IE browser，Firefox browser，Google browser,

etc.）

● support wireless network(Wi-Fi/802.11/b/g)

● support dynamic DNS (DDNS)

● support maximum 32G SD card storage，for alarm snapshot and record

● support motion detection

● support two-way audio monitoring

● support snapshot

● support mobile phone view

● support log

● support multiprotocol :HTTP/TCP/IP/UDP/STMP/DDNS/SNTP/DHCP/FTP

MF2E-E-A4

- 6 -

System

feature

System

security

Three levels account， password，multi-authority

management

Own dynamic IP

domain name

system（free）

Built-in independent R&D DDNS system, lifetime

free proprietary ddns, no need to apply DynDns,

no worry about frequent offline problem, quickly

connection. For example,http://demo.easyn.hk,

the serial number is "demo"

Mobile phone

platform（free）

No need to install software, support IE multi-view,

management, phone message on alarm, alarm picture

storage functions.

Superiority

Support computer monitoring, support many smart

phone in market, such as Iphone, android, Symbian,

etc.

Mobile phone

view

Support Iphone、Windows Mobile、Symbian、Android

direct view.

Local storage Support maximum 32G SD card memory

Kernel

OS Embedded Linux OS

Micro

processor 32Bit RSIC Embedded Processor

Video

Compression Motion-JPEG-N

Signal system CMOS 0.3 megapixels

Frame rate 25fps

Resolution VGA(640*480),QVGA(320*240) QQVGA（160*120）


adjustment Brightness, contrast, can be adjusted

White balance,

BLC Auto white balance and BLC

Network

Interface RJ-45 10/100Mb auto-adjusted internet interface

Protocol Support TCP/IP,HTTP,ICMP,DHCP,FTP,SMTP,PPPoE,etc

Wi-Fi WIFI,802.11 b/g/n

Online user Support 15 users direct connection

Support IP Static IP, dynamic IP, PPPOE

Alarm

Input/output 1/1

Alarm

detection Motion detection, sensitivity configuration

Alarm notice Support to upload pictures via Email, FTP and call

preset position, and control by GPIO signal, etc.

Certificate Certification ISO FCC CE SASO RoHS

MF2E-E-A4

- 7 -

3. DEVICE APPEARANCE AND INTERFACE

3.1. DEVICE APPEARANCE

Picture 1- device appearance

3.2. DEVICE INTERFACE

Picture 2- device interface

Power: connect to external power adapter, standard: DC 5V/2A

RJ 45: network interface standard: 10/100M auto-adjusted internet interface, it can connect

many kinds of devices, such as hub, router, and switch, etc.

Network lens: lens flickers when network connecting

Power lens: lens on when power on

SD card: support 32G SD memory card

I/O interface: 1 channel alarm input, connect 3 and 4 interfaces（ground,

trigger by low electric level）；TTL to control output, connect 1 and 2

interfaces（1，2 short connection）.

SD card

MF2E-E-A4

- 8 -

4. NETWORK CONNECTION

Picture 3- network connection scheme

4.1. CONNECTION INSTRUCTION

Before access IP Camera, first to confirm the network connection and the

power supply, to check if the status lens normal. For connection as picture

1）camera-1 and camera-2 is connected to two different LANs

2）the two LANs must connect to internet and have routers connecting

through ADSL or optical fiber, etc.

3）computer-3 should be a device connecting to internet

4.2. ACCESS INSTRUCTION

For accessing camera, in addition to communication links remain open, it

also requires a simple settings for camera and network:

1）computer and camera are in the same LAN

For access IP Camera via LAN, it should be confirmed that the computer

and camera in the same subnet, if they are not, then need to configure

the IP Camera, for example: in picture 5 camera-1’s IP is 192.168.1.126

（located in subnet 192.168.1），PC-1’s IP is 192.168.0.100（located in

192.168.0），on this case, PC-1 can not access IP Camera-1, after changing

IP Camera-1’s IP into 192.168.0.126, it can access;

2）computer and camera are in different LANs, but both of them can access

internet.

MF2E-E-A4

- 9 -

For camera-1 and computer-2 in picture 3, to access camera-1 through

computer-2, then need to set step 1）first to confirm computer-1 can access

camera-1, then configure router-1 （ router-1 should support port

forwarding）, then computer-2 can apply to access camera-1 via router-1.

Normally, computer-2 only can send message to router-1, so it can not

access camera-1 without configuration of router-1.

4.3. CONNECT NETWORK VIA ADSL

Connect device to computer via cable.

Configure device basic settings through IP Camera tool (details refer to: 5.1

IPcamera tool).

Login device as administrator, access PPPOE setting page to input account user

and password.

Meanwhile to enable DDNS server function then click <set> to restart

device.(details refer to: 5.6 ddns settings)

Connect device to internet via ADSL, then it can be accessed via ddns through

WAN.

MF2E-E-A4

- 10 -

4.4. CONNECT NETWORK VIA ROUTER

5. SOFTWARE OPERATION

5.1. IPcamera TOOL

In picture 3, camera-1’s IP is not in the same subnet with computer-1, it can not

be accessed, to run Devfind.exe in CD, click search button then

click-on searched IP Camera, then we can configure the settings, inte rface as

picture 4.

Picture 4- LAN configuration interface

1) Connect device to LAN through cable

2) Configure device through IPcam tool.

(Details refer to: 5.1 IPcamera tool)

3) Access device as administrator.

4) Access ddns setting page to enable DDNS

service then click <set> to restart device.

(Details refer to: 5.6 ddns settings)

5) Then it can be accessed through internet.

Andere Handbücher für F2 series

Inhaltsverzeichnis

Andere EasyN Sicherheitskamera Handbücher

EasyN

EasyN H Series Bedienungsanleitung

Beliebte Sicherheitskamera Handbücher anderer Marken

Okina USA

Okina USA SIR36-870VF650LP Bedienungsanleitung

Divio

Divio NDR155PA Bedienungsanleitung

Canon

Canon VB-C500D Bedienungsanleitung

Easy Access

Easy Access EasyGuard Bedienungsanleitung

Vivotek

Vivotek FD9389-EHV-v2 Bedienungsanleitung

TUYA

TUYA COSMO W2 Bedienungsanleitung

Eusso

Eusso UNC7500-IR Einrichtungshandbuch

urmet domus

urmet domus 1096/204 Bedienungsanleitung

VC VC20 series Bedienungsanleitung

Axis

Axis Q1614 Bedienungsanleitung

ieGeek

ieGeek DD201 Bedienungsanleitung

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Bedienungsanleitung

Vicon

Vicon V662-D-1 Betriebsanleitung

Grundig

Grundig GCH-K0274P Bedienungsanleitung

Lorex

Lorex VANTAGE LBC7032 Bedienungsanleitung

4xem

4xem WPT Bedienungsanleitung

Samsung

Samsung SCV-3082 Bedienungsanleitung

Vitek

Vitek VTC-C544 Bedienungsanleitung
