Eaton BladeUPS Series Bedienungsanleitung

Eaton®BladeUPS®

DoS Installation Instructions

Eaton®BladeUPS®

DoS Installation Instructions

Help Desk Numbers

United States 1-800-356-5737 or 1-800-843-9433

Canada 1-800-461-9166 ext 260

All Other Countries Call your local service representative

Web sites:

www.eaton.com/powerquality

NOTE: On the Web site opening page, click Support and select the

Customer Service link for more information.

Eaton, BladeUPS, and X-slot are registered trademarks of Eaton Corporation or

its subsidiaries and affiliates. Phillips is a registered trademark of Phillips Screw

Company. All other trademarks are property of their respective companies.

part of this document may be reproduced in any way without the express written

approval of Eaton Corporation.

Eaton BladeUPS DoS Installation Instructions P-164000613—Rev 3 i

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

System Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Moving the System and Battery Pallets . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Unloading the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Equipment Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Install the Equipment Modules and Batteries . . . . . . . . . . . . . . . . . . . . . . 11

Wiring and Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

System Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Table of Contents

ii Eaton BladeUPS DoS Installation Instructions P-164000613—Rev 3

Eaton BladeUPS DoS Installation Instructions P-164000613—Rev 3 1

Section 1 Introduction

If any equipment has been damaged during shipment, keep the shipping cartons and packing materials for the

carrier or place of purchase, and file a claim for shipping damage. If you discover damage after acceptance, file

a claim for concealed damage.

To file a claim for shipping damage or concealed damage: 1) File with the carrier within 15 days of receipt of

the equipment; 2) Send a copy of the damage claim within 15 days to your service representative.

System Components

The equipment components of the BladeUPS system are shipped as follows:

l1 palletized BladeUPS Cabinet (see Figure 1)

l1 palletized Transformer (not needed if you are using an existing transformer or not using a transformer; see

Figure 1)

Figure 1. BladeUPS Cabinet and Transformer (if ordered)

l2 BladeUPS shipping cartons (see Figure 1 and Figure 2 for more information)

2 Eaton BladeUPS DoS Installation Instructions P-164000613—Rev 3

Table 1. Shipped in Each Shipping Carton

Quantity Description

1BladeUPS Module Chassis (delivered with

Electronics Module installed)

1Electronics Module

4Battery Packs

1 package UPS Documentation and Software Tools:

IPSS Software Suite CD and Firmware CD

Installation instructions and a standard

BladeUPS User’s Guide

2 Door Keys

Eaton BladeUPS DoS Installation Instructions P-164000613—Rev 3 3

2 Hot Sync CAN Bridge Cards

1CAN Bridge Card Cable

1Redundant Signal Cable

1Input-Output Wire

2Blue Terminating Plugs

1Bypass Switch Contact Cable

Table 1. Shipped in Each Shipping Carton (Continued)

Quantity Description

4 Eaton BladeUPS DoS Installation Instructions P-164000613—Rev 3

Figure 2. BladeUPS Shipping Carton

Section 2 Tools

To assemble the components, you may need the following tools:

lForklift or pallet jack

lFlathead (short and long)

lShort- and long-handled medium flat-bladed screwdriver

lShort- and long-handled #2 Phillips® screwdriver

lRatcheting socket wrench and socket for 9/16" screws

l7 mm wrench or socket

lUtility knife

lAdjustable pliers

2Two-screw Brackets

2Ferrite Cores

1 package Assorted jumpers for REPO (see the standard

BladeUPS manual)

May include 2-pin or 3-pin jumpers

Table 1. Shipped in Each Shipping Carton (Continued)

Quantity Description
