CS60 OWNERS MANUAL

Drawing No. :- TPC302

Issue :- 1

Date :- 12

07/04

EBAC MODEL CS60

INDUSTRIAL DEHUMIDIFIER

OWNER’S MANUAL

CS60 OWNERS MANUAL

Drawing No. :- TPC302

Issue :- 1

Date :- 12

07/04

INTRODUCTION

Designed for a wide range of applications, the CS60 dehumidifier is a rugged, industrial unit

which utilizes an energy-efficient compressor and a compact portable design to provide easy

efficient drying.

The CS60 has a number of special features:

•Compact Size

•High efficiency rotary compressor

•Ebac’s “Hot Gas” defrost system

•Exterior epoxy powder-coated finish

•Provision for permanent drainage

•All galvanized interior

•Extra long power cord

•Humidistat

The fan draws the moist air through the cold evaporator coil, which cools the air below its dew

point. Moisture forms on the evaporator coil and is collected in the condensate tray, which is

equipped with a permanent drain. The cooled air then passes through the hot condenser coil

where it is reheated using the same energy removed during the cooling phase, plus the additional

heat generated by the compressor. The air is, therefore, discharged from the dehumidifier at a

slightly higher temperature with a lower absolute humidity than that which entered. Continuous

circulation of air through the dehumidifier gradually reduces the relative humidity within the

area.

The CS60 dehumidifier is a rugged, reliable drying unit designed to operate effectively over a

broad range of temperature and humidity conditions. An active hot gas defrost system,

controlled by an electronic timer, guarantees positive de-icing, thereby optimizing operation at

low temperatures.

The unit incorporates a welded and galvanized steel chassis and is finished in an epoxy coating

for resilience to damage caused by rough handling.

CS60 OWNERS MANUAL

Drawing No. :- TPC302

Issue :- 1

Date :- 12

07/04

SPECIFICATIONS

MODEL: CS60

HEIGHT: 13.25” (336.55mm)

WIDTH: 13.75” (349.25mm)

DEPTH: 20.25 ” (514.35mm)

WEIGHT: 62.83lbs (28.5 kg)

AIRFLOW:

360 CFM

EXTRACTION: 56 Pints Per Day

At 80ºF/60% RH

POWER SUPPLY: 115V/ 60Hz/ 1 ph

FINISH: Powder-coated Epoxy

OPERATING RANGE: 33°F – 105°F

REFRIGERANT: R-22 (13 oz)

CS60 OWNERS MANUAL

Drawing No. :- TPC302

Issue :- 1

Date :- 12

07/04

OPERATION

The following procedures should be followed to test the CS60 for correct operation:

1. After unpacking, examine all external features to confirm damage-free shipment.

Report all defects and damage at once. Connect the power cable to a grounded 15

Amp electrical outlet.

2. Check dehumidification process as follows:

CAUTION: DO NOT REMOVE COVERS WHEN UNIT IS IN

OPERATION.

A. Place unit on a level surface.

B. Start up unit by turning the humidistat control knob until the unit turns on.

C. Check that the compressor is running.

D. Leave the machine running for 15 minutes.

E. Observe the evaporator coils through the rear upper grill, to confirm frost

operation.

i. If the air temperature is below 80° F, an even coating of frost should cover

the entire evaporator coil

ii. If the air temperature is above 80° F, frost and/or droplets of condensed

water should cover the entire evaporator coil.

F. After continuous running time of approximately 55 minutes, the unit will enter

“Hot Gas” defrost mode for 5 minutes and then automatically return to normal

operation.

If, after carrying out the above procedures, the unit does not appear to function properly, refer to

the Trouble Shooting section, which follows, or contact the Factory Service Center.

CAUTION: Once the unit has been switched off, wait at least five

minutes before restarting.

CS60 OWNERS MANUAL

Drawing No. :- TPC302

Issue :- 1

Date :- 12

07/04

ROUTINE MAINTENANCE

WARNING: ENSURE THAT THE POWER CORD TO THE MACHINE

HAS BEEN DISCONNECTED BEFORE CARRYING OUT

ROUTINE MAINTENANCE.

To ensure continued full efficiency of the dehumidifier, maintenance procedures should be

performed as follows:

1. Clean the surface of the evaporator and condenser coils by blowing the dirt out from

behind the fins with compressed air. Hold the nozzle of the air hose away from the

coil to avoid damaging the fins. Alternatively, vacuum clean the coils.

WARNING: DO NOT STEAM CLEAN REFRIGERATION COILS.

2. Check that the fan is firmly secured to the motor shaft and that the fan rotates freely.

The fan motor is sealed for life and therefore does not need oiling.

3. To check the refrigerant charge, run the unit for 15 minutes and briefly remove the

top cover. The evaporator coil should be evenly frost coated across its surface. At

temperatures above 80°F, the coil may be covered with droplets of water rather than

frost. Partial frosting accompanied by frosting of the thin capillary tubes, indicates

loss of refrigerant gas or low charge.

4. Check all wiring connections.

5 To check the operation of the defrost system, switch the machine on and leave it

running for approximately 55 minutes. The machine will then enter “Hot Gas”

defrost mode for approximately 5 minutes before returning to normal operation. If

the unit will not defrost, the printed circuit timer board may be defective or the by-

pass valve may be inoperable.

IF ANY OF THE PRECEDING PROBLEMS OCCUR,CONTACT THE EBAC SERVICE CENTER PRIOR TO

CONTINUED OPERATION OF THE UNIT TO PREVENT PERMANENT DAMAGE.

CS60 OWNERS MANUAL

Drawing No. :- TPC302

Issue :- 1

Date :- 12

07/04

REPAIRS

1. Should an electrical component fail, consult the Factory Service Center to obtain the

proper replacement part.

2. If refrigerant gas is lost from the machine, it will be necessary to use a refrigeration

technician to correct the fault. Contact the Factory Service Center prior to initiating

this action.

Any competent refrigeration technician will be able to service the equipment. The

following procedure must be used:

a. The source of the leak must be determined and corrected.

b. The machine should be thoroughly evacuated before recharging.

c. The unit must be recharged with refrigerant measured accurately by weight.

d. For evacuation and recharging of the machine, use the crimped and brazed

charging stub attached to the side of the refrigerant compressor.

The charging stub should be crimped and rebrazed after servicing. NEVER allow

permanent service valves to be fitted to any part of the circuit. Service valves

may leak causing further loss of refrigerant gas.

3. The refrigerant compressor fitted to the dehumidifier is a durable unit that should

give many years of service. Compressor failure can result from the machine losing its

refrigerant gas. The compressor can be replaced by a competent refrigeration

technician.

Failure of the compressor can be confirmed by the following procedure:

a. Establish that power is present at the compressor terminals using a voltmeter.

b. With the power disconnected, check the continuity of the internal winding by

using meter across the compressor terminals. An open circuit indicates that the

compressor should be replaced.

c. Check that the compressor is not grounded by establishing that a circuit does not

exist between the compressor terminals and the shell of the compressor.

CS60 OWNERS MANUAL

Drawing No. :- TPC302

Issue :- 1

Date :- 12

07/04

TROUBLESHOOTING

SYMPTOM CAUSE REMEDY

Unit inoperative 1. No power to unit

1. Check the power from power supply

panel

Little or no airflow

1. Loose fan on shaft

2. Fan motor burnt out

3. Dirty refrigeration coils

4. Loose electrical wiring

5. Fuse blown or circuit breaker

tripped

1. Tighten fan

2. Replace the fan motor

3. See Routine Maintenance Section

4. Check the wiring diagram to find

fault and repair

5. Replace the fuse or reset the

circuit breaker

Little or no water extraction

1. Insufficient air flow

2. Compressor fault

3. Loss of refrigerant gas

1. Check all of the above

2. Contact the Factory Service Center

3. Contact the Factory Service Center

Little or no defrost when

required

1. Faulty timer

2. Faulty by-pass valve

1. Contact the Factory Service Center

2. Contact the Factory Service Center

Unit vibrates excessively

1. Loose compressor

2. Damaged fan

1. Tighten the nuts on the compressor

mounts

2. Replace fan

Water flooding inside the

machine

1. Drain pipe blocked/frozen

2. Drain pipe too high

3. Crimped or blocked tubing

1. Clear the obstruction

2. Ensure that no section of the

drain hose is above the level of the

water outlet

3. Straighten, clear, or replace tubing

Ebac Industrial Products

704 Middle Ground Boulevard

Newport News

VA 23606

Telephone (757) 873-6800 FAX (757) 873-3632

Sales Inquiries: 800-934-9194

CS60 OWNERS MANUAL

Drawing No. :- TPC302

Issue :- 1

Date :- 12

07/04

CS 60

SPARE PARTS LIST

NUMBER DESCRIPTION PART NUMBER QUANTITY

1 Defrost Timer 1600550 1

2 Control Knob 2019708 1

3 Capillary Tube 3014251 48”

4 Solenoid Valve 3020814 1

5 Filter Dryer 3020901 1

6 Compressor 3022163 1

7 Solenoid Coil 3030421 1

8 Capacitor 3030908 1

9 Humidistat 3035145 1

10 Mains Lead 3035148 1

11 Fan Motor 3035788 1

12 Relay 3036157 1

13 Axial Fan 3040129 1

14 Fan Inlet Ring 3040326 1

15 Rubber Foot 3101436 1

16 Drain Tubing 3014338 9 Feet

17 Drain Tube Jubilee Clip 3086101 1

18 Condenser Coil 2026014 1

19 Evaporator Coil 2026013 1

CS60 OWNERS MANUAL

Drawing No. :- TPC302

Issue :- 1

Date :- 12

07/04

Ebac LIMITED WARRANTY

Our products carry a one-year unconditional warranty against any defects in workmanship or

material. This warranty will cover all parts and labor required to repair your Ebac product. This

warranty is invalid if the unit has been abused, damaged, whether intentional or accidental, or if

any modifications have been made to the unit.

THE FOREGOING WARRANTY IS EXCLUSIVE AND IS ISSUED IN LIEU OF ALL

OTHER WARRANTIES (WHETHER WRITTEN, ORAL, OR IMPLIED) INCLUDING THE

WARRANTY OF MERCHANTABILITY AND THE WARRANTY OF FITNESS FOR A

PARTICULAR PURPOSE. EBAC SYSTEMS, INC. DISCLAIMS ANY LIABILITY FOR

CONSEQUENTIAL DAMAGES, LOST PROFITS, OR INCIDENTAL DAMAGES FOR

BREACH OF ANY WRITTEN OR IMPLIED WARRANTY WITH RESPECT TO THE

FOREGOING DESCRIBED MERCHANDISE.

For Your Records: Model: ____________________

S/N: ______________________

Date Received: ______________

SAVE THIS SECTION FOR YOUR RECORDS

CLIP AND RETURN THIS CARD

PLEASE NOTE WARRANTY REGISTRATION

To ensure that your Ebac

Dehumidifier is accorded

the full coverage

provided by this

warranty, please

complete and mail this

card at your earliest

convenience.

Thank You

DATE

MODEL ___________ S/N ________________ RECEIVED ________________

OWNER __________________________________________________________

ADDRESS ________________________________________________________

CITY __________________________ STATE ________ ZIP _______________

COMMENTS ______________________________________________________

_________________________________________________________________

Ebac Industrial Products.

704 Middle Ground Boulevard, Newport News, Virginia 23606

Inhaltsverzeichnis

Andere Ebac Luftentfeuchter Handbücher

Ebac

Ebac 6000 Series Bedienungsanleitung

Ebac

Ebac Powerpac Bedienungsanleitung

Ebac

Ebac WRD-5000 Installationsanleitung

Ebac

Ebac Powerpac Bedienungsanleitung

Ebac

Ebac RM40-SH Bedienungsanleitung

Ebac

Ebac BD-150 Bedienungsanleitung

Ebac

Ebac ORION Bedienungsanleitung

Ebac

Ebac ECO60 Bedienungsanleitung

Ebac

Ebac Powerdri DEL080-V3 Bedienungsanleitung

Ebac

Ebac AD850E Bedienungsanleitung

Ebac

Ebac CD60 Bedienungsanleitung

Ebac

Ebac Pro 100 Series Bedienungsanleitung

Ebac

Ebac 2000 Series Bedienungsanleitung

Ebac

Ebac RM85 10560RG-GB Bedienungsanleitung

Ebac

Ebac CD425 Bedienungsanleitung

Ebac

Ebac CD425 Bedienungsanleitung

Ebac

Ebac 4000 Series Bedienungsanleitung

Ebac

Ebac 6000 Series Bedienungsanleitung

Ebac

Ebac BD-150 Bedienungsanleitung

Ebac

Ebac 2000 Series Bedienungsanleitung

Ebac

Ebac CD100 Bedienungsanleitung

Ebac

Ebac 4650e Bedienungsanleitung

Ebac

Ebac CD85 Bedienungsanleitung

Ebac

Ebac TPC321 Bedienungsanleitung

Beliebte Luftentfeuchter Handbücher anderer Marken

Daitsu

Daitsu CD031IU-DFA Bedienungsanleitung

Fehom

Fehom PDGT701BE Bedienungsanleitung

Hitachi

Hitachi RD-190GX Bedienungsanleitung

Westpoint

Westpoint MDF1-30AE Bedienungsanleitung

SOLIS

SOLIS easy dry compact Bedienungsanleitung

ENVIROBOSS

ENVIROBOSS EB240 Bedienungsanleitung

Sinclair

Sinclair R-9112 Bedienungsanleitung

Kenmore

Kenmore 580.54701 Bedienungsanleitung

Demargo

Demargo DM828NF Bedienungsanleitung

Altrad Lescha

Altrad Lescha LDH 600 Bedienungsanleitung

BOMANN

BOMANN LE 1150 CB Bedienungsanleitung

SPT

SPT SD-46 Bedienungsanleitung

REMKO

REMKO SLN 40 Bedienungsanleitung

Haier

Haier HD458 Bedienungsanleitung

Logik

Logik L20DHW12 Bedienungsanleitung

Frigidaire

Frigidaire FDR30S1 - 30 Pint Capacity Dehumidifier Kurzanleitung

Blitz

Blitz HHD Series Bedienungsanleitung

Prem-I-Air

Prem-I-Air PD14DEN Bedienungsanleitung
