1 OVERVIEW

1.1 Brief Introduction

E30-400M30S（4463）is a hardware module (SPI) based on the SI4463

RF chip imported from Silicon Labs. It is a half-duplex, SMD integrated

transceiver with transparent transmission available. With working frequency

band 425 ～525MHz, transmitting power 1w, it is suitable for a variety of

environments. The original imported SI4463 RF chip from Silicon Labs(USA)

features high receiving sensitivity and strong anti-interference, supporting the

development of low power consumption as well. It has been widely used in

various industries and has the characteristics of stable performance, long

transmission distance, and strong ability of penetration and diffraction, etc.

1.2 Features

The measured communication distance is up to 5.6km;

Maximum transmission power: 1W;

425～525MHz ultra-wide frequency band;

Air date rate：1k～25kbps;

With 3.3～5.5V power supply, over 5 V guarantees the best performance;

Industrial grade standard design,support -40 ~ 85 °C for working over a long time;

1.3 Application

Home security alarm and remote keyless entry;

Smart home and industrial sensors, etc.;

Wireless alarm security system;

Building automation solutions;

Wireless industrial-grade remote control;

Intelligent agriculture and oilfield solutions;

Health care products;

Advanced Meter Reading Architecture(AMI);

Automotive industry applications.

Chengdu Ebyte Electronic Technology Co.,Ltd E30-400M30S（4463）User

Manual

2 Specification and Parameter

2.1 Limit Parameter

Main parameter

Performance

Remark

Min

Max

Power supply（V）

3.3

5.5

Voltage over 5.5V will cause permanent damage to

module

Blocking power（dBm）

Chances of burn is slim when modules are used in

short distance

Operating temperature（℃）

-40

+85

Industrial grade

2.2 Operating Parameter

Main parameter

Performance

Remark

Min

Typical

Max

Operating voltage（V）

3.3

5.0

5.5

5 V ensures output power

Communication level（V）

3.3

For 5V TTL, it may be at risk of burning down

Operating temperature（℃）

-40

+85

Industrial grade

Operating frequency（MHz）

425

525

Power

Consump

- tion

TX current（mA）

550

650

700

Instant power consumption

RX current（mA）

Sleep current （μA）

Max TX power（dBm）

30.5

Receiving sensitivity（dBm）

-120

-121

-122

Air data rate is1kbps

Main parameter

Description

Remark

Reference distance

5.6Km

Test condition：clear and open area, antenna gain: 5dBi，

antenna height: 2.5m，air data rate: 1kbps

Modulation

GFSK

Communication Interface

SPI

Max. rate 10Mbps

Package

SMD

Interface method

Stamp Hole

Size

38.5*24mm

Antenna

IPEX/STAMP

50 ohm impedance

Chengdu Ebyte Electronic Technology Co.,Ltd E30-400M30S（4463）User

Manual

3 Size and Pin definition

Pin No.

Item

Direction

Description

GND

Ground wire, connected to the power reference ground

GND

Ground wire, connected to the power reference ground

GND

Ground wire, connected to the power reference ground

GND

Ground wire, connected to the power reference ground

GND

Ground wire, connected to the power reference ground

IO_2

Output

Configurable universal GPIO port (see SI4463manual for details)

IO_3

Output

Configurable universal GPIO port (see SI4463manual for details)

IO_0

Output

Configurable universal GPIO port (see SI4463manual for details)

VCC

Power supply, 3.3~5.5V, 5V is recommended (It is also recommended to add

external ceramic filter capacitor)

VCC

Power supply, 3.3~5.5V, 5V is recommended (It is also recommended to add

external ceramic filter capacitor)

GND

Ground wire, connected to the power reference ground

GND

Ground wire, connected to the power reference ground

IO_1

Output

Configurable universal GPIO port (see SI4463manual for details)

IRQ

Output

SPI interrupt request

SDN

Shutdown Input Pin. It is low level when working

(See SI4463 manual for more details)

Chengdu Ebyte Electronic Technology Co.,Ltd E30-400M30S（4463）User

Manual

MISO

Output

SPI master output slave input

MOSI

Input

SPI master input slave output

SCK

Input

Serial Clock Input

nSEL

Input

SPI Chip select for starting SPI communication

GND

Ground wire, connected to the power reference ground

ANT

Input/Output

Antena

GND

Ground wire, connected to the power reference ground

4 Recommended circuit diagram

5 Hardware design

It is recommended to use a DC stabilized power supply. The power supply ripple factor is as small as possible and the

module needs to be reliably grounded;

Please pay attention to the correct connection of the positive and negative poles of the power supply, reverse connection

may cause permanent damage to the module;

Please check the power supply to ensure that between the recommended supply voltage, if exceeding the maximum, the

module will be permanently damaged;

Please check the stability of the power supply. Voltage can not fluctuate greatly and frequently;

When designing the power supply circuit for the module, it is often recommended to reserve more than 30% of the

margin, so the whole machine is beneficial for long-term stable operation;

The module should be as far away as possible from the power supply, transformers, high-frequency wiring and other

parts with large electromagnetic interference;

Bottom Layer High-frequency digital routing, high-frequency analog routing, and power routing must be avoided under

Chengdu Ebyte Electronic Technology Co.,Ltd E30-400M30S（4463）User

Manual

the module. If it is necessary to pass through the module, assume that the module is soldered to the Top Layer, and

the copper is spread on the Top Layer of the module contact part(well grounded), it must be close to the digital part

of the module and routed in the Bottom Layer;

Assuming the module is soldered or placed over the Top Layer, it is wrong to randomly route over the Bottom Layer or

other layers, which will affect the module's spurs and receiving sensitivity to varying degrees;

It is assumed that there are devices with large electromagnetic interference around the module that will greatly affect

the performance. It is recommended to keep them away from the module according to the strength of the

interference. If necessary, appropriate isolation and shielding can be done;

Assume that there are traces with large electromagnetic interference (high-frequency digital, high-frequency analog,

power traces) around the module that will greatly affect the performance of the module. It is recommended to stay

away from the module according to the strength of the interference.If necessary, appropriate isolation and shielding

can be done;

If the communication line uses a 5V level, a 1k-5.1k resistor must be connected in series (not recommended, there is

still a risk of damage);

Try to stay away from some physical layers such as TTL protocol at 400MHz;

The mounting structure of antenna has a great influence on the performance of the module. It is necessary to ensure that

the antenna is exposed, preferably vertically upward.

When the module is mounted inside the case, use a good antenna extension cable to extend the antenna to the outside;

When the antenna is installed inside a metal case, it will cause the transmission distance to be greatly weakened.

6 FAQ

6.1 Communication range is too short

The communication distance will be affected when obstacle exists;

Data lose rate will be affected by temperature, humidity and co-channel interference;

The ground will absorb and reflect wireless radio wave, so the performance will be poor when testing near ground;

Sea water has great ability in absorbing wireless radio wave, so performance will be poor when testing near the sea;

The signal will be seriously affected when the antenna is near metal object or put in a metal case;

Power register was set incorrectly or air data rate is set as too high (the higher the air data rate, the shorter the distance);

The power supply low voltage under room temperature is lower than our recommendation, the lower the voltage, the

lower the transmitting power;

Due to antenna quality or poor matching between antenna and module.

6.2Module is easy to damage

Please check the power supply, ensure it works in correct voltage;

Please check the stability of power source, the voltage cannot fluctuate too much;

Please make sure anti-static operation when installing and using, high frequency devices have electrostatic

susceptibility;

Please ensure the humidity is within limited range, some parts are sensitive to humidity;

Chengdu Ebyte Electronic Technology Co.,Ltd E30-400M30S（4463）User

Manual

Please avoid using modules under too high or too low temperature.

6.3 BER(Bit Error Rate) is high

There are co-channel signal interference nearby, please be away from interference sources or modify frequency and

channel to avoid interference;

Poor power supply may cause messy code. Make sure that the power supply is reliable;

The extension line and feeder quality are poor or too long, so the bit error rate is high.

7 Production guidance

This product is a SMD module. When soldering the module, the soldering personnel must work in accordance with

the anti-static operation specification;

This product is an electrostatic sensitive product. If the module is not welded according to the specification, the

module may be permanently damaged.

8 E30 series

Model No.

Frequency

power

dBm

Distance

Air data rate

bps

Package

Size

Antenna

E30-170T20D

SI4463

170M

2.0

1k～25k

DIP

21 * 36

SMA-K

E30-170T27D

SI4463

170M

5.0

1k～25k

DIP

24 * 43

SMA-K

E30-433T20S3

SI4438

433M

2.5

1k～25k

SMD

16 * 26

IPEX/STAMP

E30-433T20S

SI4438

433M

2.5

1k～25k

SMD

17 * 30

IPEX/STAMP

E30-433T20D1B

SI4438

433M

2.5

1k～25k

DIP

21 * 36

SMA-K

E30-490T20S

SI4438

490M

2.5

1k～25k

SMD

17 * 30

IPEX/STAMP

E30-490T20D

SI4438

490M

2.5

1k～25k

DIP

21 * 36

SMA-K

E30-780T20S

SI4463

780M

2.5

1k～25k

SMD

17 * 30

IPEX/STAMP

E30-868T20D

SI4463

868M

2.5

1k～25k

DIP

21 * 36

SMA-K

E30-868T20S

SI4463

868M

2.5

1k～25k

SMD

17 * 30

IPEX/STAMP

E30-915T20D

SI4463

915M

2.5

1k～25k

DIP

21 * 36

SMA-K

E30-915T20S

SI4463

915M

2.5

1k～25k

SMD

17 * 30

IPEX/STAMP

9 Antenna recommendation

The antenna plays an important role in the communication process. A good antenna can largely improve the

Chengdu Ebyte Electronic Technology Co.,Ltd E30-400M30S（4463）User

Manual

communication system. Therefore, we recommend some antennas for wireless modules with excellent performance and

reasonable price.

10 Package method for bulk order

Revision history

Version

Date

Description

Issued by

Model No.

Type

Frequeny

Interface

Gain

dBi

Hight

Cable

Function feature

TX433-JZLW-15

Rubber

433M

IPEX 1

3.0

165

150

Rubber antenna for cabinet,

omnidirectional

TX433-FPC-5711

FPC

433M

IPEX 1

2.5

Cost-effective

TX433-PCB-3207

PCB

433M

IPEX 1

2.0

PCB antenna,

TX433-FPC-4516

FPC

433M

IPEX 1

2.0

120

Cost-effective

TX433-FPC-3208

FPC

433M

IPEX 1

2.0

Cost-effective

TX470-JZLW-15

Rubber

470MHz

IPEX 1

3.0

155

150

Rubber antenna for cabinet,

omnidirectional

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Ebyte Drahtlosmodul Handbücher

Ebyte

Ebyte E30-780T20S Bedienungsanleitung

Ebyte

Ebyte E22-230T30D Bedienungsanleitung

Ebyte

Ebyte E73-2G4M08S1CX Bedienungsanleitung

Ebyte

Ebyte E31-433T27D Bedienungsanleitung

Ebyte

Ebyte E103-W06-TB Bedienungsanleitung

Ebyte

Ebyte E01C-ML01SP4 Bedienungsanleitung

Ebyte

Ebyte E220-900T30S Bedienungsanleitung

Ebyte

Ebyte E70 Series Bedienungsanleitung

Ebyte

Ebyte E19-433M20S2 Bedienungsanleitung

Ebyte

Ebyte E18-MS1PA1-IPX Bedienungsanleitung

Ebyte

Ebyte E49-400M30S Bedienungsanleitung

Ebyte

Ebyte E220-900T22S Bedienungsanleitung

Ebyte

Ebyte E31-433T17D Bedienungsanleitung

Ebyte

Ebyte E72-2G4M02S2B Bedienungsanleitung

Ebyte

Ebyte E610-433T S Series Bedienungsanleitung

Ebyte

Ebyte E70-900T14S Bedienungsanleitung

Ebyte

Ebyte E22-900T30DC Bedienungsanleitung

Ebyte

Ebyte E32-433T20S1 Bedienungsanleitung

Ebyte

Ebyte E28-2G4M12S Bedienungsanleitung

Ebyte

Ebyte E200-900A17S Bedienungsanleitung

Ebyte

Ebyte E22-900T22S Bedienungsanleitung

Ebyte

Ebyte E70-433NW30S Bedienungsanleitung

Ebyte

Ebyte E70-900T S Series Bedienungsanleitung

Ebyte

Ebyte E70-433T14S2 Bedienungsanleitung

Beliebte Drahtlosmodul Handbücher anderer Marken

Laird

Laird RM024 Bedienungsanleitung

Laird

Laird BT830-SA Kurzanleitung zur Einrichtung

Fibocom

Fibocom FM101-NA-20 Montageanleitung

Waldmann

Waldmann EnOcean TALK MODUL G2 Bedienungsanleitung

Smartech

Smartech LBT-1.DO4 Bedienungsanleitung

Cooper Wiring Devices

Cooper Wiring Devices ESPIRE RF RFAPM Bedienungsanleitung

Yuga

Yuga CLM920 Bedienungsanleitung

Waldmann

Waldmann TALK Bluetooth Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions UC864-G Installationshandbuch

Quectel

Quectel SC690A Series Beilage

Panasonic

Panasonic INDUSTRY PAN9028 Kurzanleitung zur Einrichtung

LongSung Technology

LongSung Technology U9507E Bedienungsanleitung

Wistron NeWeb

Wistron NeWeb DNUR-S2 Bedienungsanleitung

RF-Star

RF-Star SimpleLink RF-BM-2652P1 CC2652P Bedienungsanleitung

CHIEF

CHIEF AVMW Bedienungsanleitung

Huawei

Huawei EM701 Bedienungsanleitung

SIYI

SIYI FTM30 Bedienungsanleitung

RF-Star

RF-Star RF-BM-4055B1L Bedienungsanleitung
