EcLine BT-8500 Bedienungsanleitung

EC BT-8500

Wireless'Handheld'Linear'Imager'Barcode'Scanner'

User’s Manual

www.ecline.com.mx

Table of Contents

1. Introduction ............................................................................. 1!

1.1!Safety & Caution.................................................1!

1.2!FCC Warning ......................................................2!

2. General Description ................................................................... 3!

2.1!Product Description ............................................3!

2.2!Illustration ...........................................................3!

3. Installation ............................................................................... 4!

3.1!Unpacking .........................................................4!

3.2!Mounting............................................................ 4!

4. Setup Bluetooth Communication ............................................. 7!

4.1 Pairing ..............................................................7!

4.2 Setup SPP Master Mode ..................................7!

4.3 Setup SPP Slave Mode ....................................8!

4.4 Setup HID Slave Mode .....................................8!

4.5 Sleep Mode ...................................................... 9!

4.6 Batch Mode ...................................................... 9!

4.7 Out of Range ....................................................9!

4.8 Scanner Mode ................................................ 10!

5. Configuring............................................................................ 11!

5.1 Preface ........................................................... 11!

5.2 Changing Scanner Settings with

Programming Codes.........................................11!

5.3 Programming Flow Chart................................ 12!

6. Programming Menu .............................................................. 13!

6.1!General Process ...............................................13!

6.2!Set Cradle Interface..........................................14!

6.3!RS232 mode parameters..................................18!

6.4!Keyboard Wedge Mode Parameters ................21!

6.5!Output Characters............................................24!

6.6!Code Type ........................................................25!

6.7!UPC/EAN/JAN Parameters ..............................28!

6.8!Code 39 Parameters.........................................30!

6.9!Code 128 Parameters.......................................32!

6.10!Interleaved 2 of 5 Parameters ..........................34!

6.11!Industrial 2 of 5 Parameters..............................37!

6.12!Matrix 2 of 5 Parameters ..................................38!

6.13!CODABAR Parameters ....................................41!

6.14!Code 93 Parameters.........................................43!

6.15!Code 11 Parameters.........................................45!

6.16!MSI/plessey Code Parameters.........................47!

6.17!Telepen Parameters ......................................... 49!

6.18!GS1 Databar Parameters .................................51!

6.19!GS1 Databar Limited Parameters.....................52!

6.20!GS1 Databar Expanded Parameters ................53!

7.!Miscellaneous Parameters.................................................... 54!

7.1 Bar Code ID ........................................................54!

7.2!preambles and postambles Insertion................56!

7.3!Character deletion ............................................60!

7.4!Appendices .......................................................65!

A. Decimal Value Table ............................................65!

B ASCII Table......................................................... 66!

C Function Key Table.............................................71!

D. Decimal Value Table..........................................72!

E. Technical Specifications ....................................73!

F. Indicator LED Status ..........................................74!

G. Electrical Characteristics ...................................75!

H. Scan Map .............................................................76!

A.!How to communicate with Bluetooth

dongle 77!

1. Introduction

Thank you for purchasing this brand-new designed

2D imager hand held barcode scanner.

This is a cutting-edge gun-type area imaging

barcode scanner which is designed specifically for

retailer, entertainment coupons, medical

environment, shipping industry and etc. That adds

on more user friendly functions and has replaceable

cable that makesit more easily to be operated by the

customers.

This high performance gun-type scanner provides

the customer with the most cost effective solution in

the market. It is perfectly suitable and definitely the

best choice for you.

1.1 Safety & Caution

1) Please read the following safety statement

carefully.

2) Please preserve this user manual for reference

sometime.

3) Before cleaning the device, the users must cut off

all AC power. Do not use liquid or spray type of

detersive to clean the device. Please use

dampish cotton cloth to clean the device.

4) The outlet must set nearby the device for

connecting power easily.

5) Keep the device dry to avoid short circuit.

6) During installation you must fix the equipment at

solid table to avoid damage caused by falling.

7) Before inserting power please ensure the voltage

is healthy to the equipment.

8) For safety please tie wire well and don’t put

anything on the wire.

9) If you don’t use this equipment for long time,

please cut off the power to avoid damage from

surge power.

10) Don’t spray any liquid on this scanner because it

may cause a fire or short circuit.

11) Please do not disassemble the equipment. For

safety only the qualified serviceman can

disassemble the equipment.

12) If there are the following situations please contact

with the qualified serviceman to check this

equipment.

(a) The damage of wire or pin of power supply.

(b) Some Liquid infiltrate into the equipment.

environment.

(d) The equipment can’t work well.

(e) The equipment has any obvious damage,

making the device working abnormally.

13) Don’t storage the device at the temperature lower

than -20°C (-4°F) or higher than +70°C (158°F) to

avoid any damage.

1.2 FCC Warning

This equipment complies with the requirements in

Part 15 of FCC.

Any operation must comply with the conditions

below:

1) The equipment will not cause any severe

interference.

2) The equipment can avoid any interference

from environment.

Statement:

This product is classified as Bclass product.

In environment this product may cause some

interference. In this situation the user may do

something to avoid interference.

2. General Description

2.1 Product Description

BT-8500 is a high performance wireless linear

imager barcode scanner supporting linearand area

imager barcode scanning.

This device is very easy to configure by this manual,

you can set up by scanning all necessary

programming codes one time that meet applications,

the settings are directly saved permanently, and all

settings can be disabled after scan reset factory

default.

2.2 Illustration

BT-8500 Series

3. Installation

3.1 Unpacking

1) Take the device and accessories out of the box.

2) Remove the packing material.

3) Check the standard shipment packing list to

make sure you have received all of the items

ordered.

Wireless Linear Imager Scanner

Bluetooth Cradle or Charger (optional)

Power Adaptor (if applied)

Communication Cable

Skip resistant pad

Iron panel of cradle and screw

Product Compact Disc

4) Visually inspect the device and accessories for

any evidence of physical damage.

5) If anything is missing or appears to be damaged,

immediately contact your dealer.

ATTENTION:

Store the packing material and boxes: It should

be used whenever the device is transported for

servicing.

3.2 Mounting

Once you have unpacked all components, you can

start installing the device as below steps:

BT-8500 Scanner

1) The Scanner must be charged for a minimum of

8 hours before the scanner can be placed in full

operation for the first time.

2) The cradle will indicate in red light when the

scanner is being charged.

3) Once the battery is fully charged, the green LED

of scanner will be on. The green light will be off

when the scanner leaving from cradle. When the

battery is over charged, the red and green LED

will be flashing.

4) If the battery power capacity is too low, the

scanner will indicate with red LED and beeper

warning.

BT-8500 Cradle

1) Connect the supplied communication cable at

the bottom side of the scanner and you will

hear a “click” when the connection is made.

2) Turn off the host system.

3) Connect the other side of the communication

cable to the right connector of your host

system.

4) Plug the external power supply into the power

jack on the bottom of the cradle.

5) Plug the power supply into the AC outlet.

6) Turn on your host system.

7) To setup Bluetooth communication between

the scanner and cradle. (see chapter 4)

Cable Installation

Connect cable and adaptor to Cradle. The other

end of cable will be connected with host device.

Lock the iron panel of Cradle by screwdriver.

Skip resistant pad position

4. Setup Bluetooth

Communication

Before the operation, Bluetooth communication must

be setup between the scanner and cradle.

4.1 Pairing

Each scanner has to be linked or paired to a cradle

by scanning the unique Bluetooth MAC address

code located on the bottom of cradle. The pairing

between scanner and cradle is one to one that is one

scanner can be paired to a cradle only.

4.2 Setup SPP Master Mode

Please follow the steps to setup the communication

between the scanner and cradle.

1) The scanner must scan “SPP Master Mode”

barcode to set the scanner in master mode.

2) Scan the Bluetooth MAC address code located

on the bottom of the cradle.

3) When the Bluetooth MAC address code was

successfully scanned, scanner will sound 3

beepswith Green led.

4) Wait approximately five seconds for completing

the connection process with up-tone.

5) If successful, blue LED of scanner will slow flash

and the cradle will be continued on.
