ECOLINE TV7010 Bedienungsanleitung

Video surveillance camera

Installation Guide

TV7010 TV7011

TV7012 TV7013

1. Preface

Dear Customer,

Thank you for purchasing this ECOLINE digital surveillance camera.

You made the right decision in choosing this state-of-the-art technology.

This product complies with the current standards of domestic and European

regulations. The CE has been proven and all related certifications are available

from the manufacturer upon request. To maintain this status and to guarantee

safe operation, it is your obligation to observe these operating instructions!

The ECOLINE mini-dome series of digital cameras is equipped with a 1/3”

SONY Super HAD interline transfer CCD image sensor. The all state circuitry

provides extremely long life and a high level of reliability. These cameras use first

class microelements that are resistant to external electromagnetic fields. They

offer cutting-edge technology for advanced video surveillance.

2. Scope of delivery

ECOLINE dome camera (model as described)

Installation instructions

Fastening screws

3. Features

All dome cameras of the ECOLINE series have the following functions:

a) Auto electronic shutter (AES)

b) Auto gain control (AGC)

Additional for colour cameras of this series:

c) Auto white balance (AWB)

d) Digital signal processing (DSP)

4. Precautions

To reduce the risk of electric shock, do not remove cover (or back) – there are

no user serviceable parts inside. Refer servicing to qualified service personnel.

Do not expose the camera to rain or moisture or try to operate in

wet areas. The camera is designed to be operated indoors only. If the camera

becomes wet, turn the power off immediately and ask a qualified service

technician to check it before turning the power on again. Moisture can damage

the camera and also create the danger of electric shock.

Never point the camera towards the sun. Whether the camera is in use

or not, never aim the CCD at the sun or other very bright objects (laser light).

This can damage the CCD element and create white dots on the monitor, a sign

that CCD pixels are destroyed.

Operate the camera only within the specified temperature,

humidity and power ranges. Operating the camera outside the prescribed

ranges can lead to reduced product life and early malfunction. Greatly

exceeding the specified operating ranges can also result in immediate failure of

the camera. All specifications can be found in the technical data. Observe the

correct camera model.

Handle the camera with care. Do not abuse the camera. Avoid striking,

shaking, etc. Mount the camera in a shake-free area. The camera could be

damaged by improper handling, storage or transport.

5. Installation instructions

This camera is designed for indoor use only. If the camera is used outdoors,

damage may occur as a result of dampness and temperatures outside the

prescribed range. The ECOLINE colour cameras are equipped with an IR cut

and cannot be used in combination with IR illumination.

Perfect (colour) video pictures depend a great deal on the illumination. Please

take this into account when installing artificial light sources. Light sources with a

colour temperature different from daylight may effect colour drifts for colour

cameras.

The cause of bad picture quality goes hand in hand with improper cabling.

Ensure professional installation and avoid passive video distributors. Always

select the shortest distance between the camera and the video unit.

Before installing a video surveillance system with camouflaged cameras, please

be aware of any possible legal regulations that may apply.

6. Description of the camera

1) Video output (VIDEO OUT)

BNC output. This connector is for connecting the camera video signal to the

VIDEO IN connector of, for example, the monitor (composite signal: 1Vp-p).

2) Power input

12V DC voltage. Approved for DC voltage are class 2 power supply units only.

Ensure the polarity is correct.

7. Installation

Proceed as follows when installing the camera.

1. Select a suitable place on the ceiling of the room where you would like to

mount the camera.

2. Connect the video cable (recommended cable type: RG58) to the BNC

video out (1) of the camera and to the following connected video unit. The

maximum cable length should not exceed 200 m.

3. Connect a 12V DC power supply to the power input of the camera (2).

4. Hold the camera at the location where you want to mount it. Check the

orientation and angle of the camera.

5. Remove the plastic dome from the housing by carefully unscrewing it

counter-clockwise.

6. Change the orientation of the camera module if necessary by loosening the

fixing screws (4), modifying the inclination and direction of the camera

module, and then tightening the fixing screws again.

7. Fasten the Ecoline mini-dome camera to the desired mounting location

using the supplied screws (3) and screw on the plastic housing again.

8. Technical data

Model number TV7010 TV7011 TV7012 TV7013

Image sensor 1/3” SONY Super HAD CCD

TV lines / pixels 420 /

291,000

600 /

438,000

380 /

291,000

470 /

438,000

Minimum

illumination (IRE 30)

0.1 lux

(F2.0)

0.2 lux

(F2.0)

0.2 lux

(F2.0)

0.4 lux

(F2.0)

Signal-to-noise ratio > 48 dB

AES 1/50s – 1 / 110,000s

Lens 1/3” / 3.0 mm / F2.0 / miniature lens

Horizontal angle 96°

Video out 1Vp-p / 75 Ohm / BNC connector

Power source 12V DC

Power consumption 1.32W 2.64W

Video norm CCIR PAL

Dimensions / Weight Ø88 x 57 mm / max. 140 g

Ambient operating

temperature

-10°C – +50°C

Ambient operating

humidity

max. 90% non-condensed

Protection type IP54
