Edimax SP-2101W V3 Bedienungsanleitung
SP-2101W V3
User Manual
07-2020 / v1.0
Contents
I. Product Information & Safety Information...... 1
I-1. Package Contents....................................................................... 2
I-2. System Requirement .................................................................. 2
I-3. LED Status.................................................................................. 2
I-4. Hardware Interface .................................................................... 3
II. EdiSmart App Installation ............................... 4
III. Register the Account....................................... 5
IV. Adding Devices (Android & iOS Interface) ....... 7
V. Homepage .....................................................11
V-1. Delete a device..........................................................................11
V-2. Info Page ..................................................................................13
V-3. Language ..................................................................................14
V-4. News.........................................................................................15
V-5. FAQ...........................................................................................15
V-6. Privacy Policy ............................................................................16
V-7. Share Account ...........................................................................16
V-8. APP Version ..............................................................................17
VI. Device Setting................................................18
VI-1. Change the name of the device..................................................18
VI-2. Upgrade Firmware ....................................................................19
VII. Factory Default ..............................................20
1
I. Product Information & Safety Information
The Edimax Smart Plug SP-2101W V3 connects people to their homes and the
things they use every day. With the Edimax Smart Plug you can control most
home appliances and check the Power Meter, from anywhere anytime with
the EdiSmart App.
Please install the unit with the safety restrictions outlined below:
-Maximum Power Rating must not be exceeded in order to guarantee the
lifespan and reliability of.
-Children should not use this product without adult supervision.
-This product does not have lightning protection. It is recommended to turn
off the power when lightning strikes.
-When the smart plug is powered on, do not insert conductive materials
into the socket.
Unable to follow the above mentioned guideline may reduce smart
plug lifetime.
You can find all supporting documents from the link below or via QR Code:
https://www.edimax.com/download
(Once you’ve visited the Edimax official website, please enter model no.
“SP-2101W V3”into the search box to search for your product.)
2
I-1. Package Contents
Before using this product, please check if anything is missing from the
packaging, and contact your dealer to claim the missing item(s):
I-2. System Requirement
-Wi-Fi: 2.4 GHz 802.11 b/g/n
-Android 6 or later
-iOS 11 or later
I-3. LED Status
LED Name
Color
Status
Description
Power LED
Blue
Blinking
Power on and before provision
Off
After provision
On
Power switch on
Quick Installation
Guide
AU
EU
UK
US
3
I-4. Hardware Interface
US Smart Plug: AU Smart Plug:
EU Smart Plug: UK Smart Plug
No.
Description
1
Power Button
2
LED
USB Port
1,2
1,2
1
2
1
2
4
II.EdiSmart App Installation
Search and download "EdiSmart" in App Store (iOS) / Google Play Store
(Android) or scan the QR code below. Launch the "EdiSmart" in your smart
mobile device.
Before using EdiSmart app, please make sure,
-Your mobile device can access the internet.
NOTE: Only 2.4 GHz Wi-Fi networks are supported. Please select a 2.4 GHz
Wi-Fi network.
-Go to your phone’s system language, and select the language you want to
use for app. For example, if you change the language of your phone to
English, then your app should automatically display the language you
selected.
5
III.Register the Account
Please follow the steps below to register the account,
1. Launch the EdiSmart App in your device and click the “Sign up”button to
register an account with your email.
2. Read the preamble and click “Yes”to proceed the next step.
6
3. Enter your Email and Password. Chick the “Sign up”button to proceed the
next step.
4. Please check your email and click the “Confirm Your Email”button.
Note: You will receive a message, “Congratulation! You have been
successfully registered.”If the account is successfully created
**********@gmail.com
7
IV.Adding Devices (Android & iOS Interface)
Please follow the steps below to add a new device.
1. Click the “Login”button. Enter your Email/Password and click the “Login”
button.
2. Click the “+”icon in the top right corner.
8
3. Click “Add New Devices”.
4. Follow the instruction on screen and enter the last two digits of MAC. Click
the “Make sure the Status LED indicator blinks”button to confirm.
NOTE: Please make sure Wi-Fi is on all the time.
