EKSA H1-BT Bedienungsanleitung
Wireless Headset with Microphone
User Manual
H1-BT
1
Bluetooth® Specification
Microphone Specification
Driver Specification
Model
Dimensions
Impedance
Sensitivity
Frequency Response
Vibrating diaphragm material
Magnet Level
40mm
32Ω±15%
105dB±3dB
20Hz~20kHz
PET
N45
Chipsets
Bluetooth® Version
Support Protocols
Effective wireless range
BES2300Z
Bluetooth V5.0
Bluetooth 2.1+EDR and BLE5.0
30 M/ 99ft
Dimensions
Microphone Direction
Sensitivity
Frequency response
Impedence
MIC Frequency Response Curve
ø6X2.7mm
Omnidirectional
-42±3dB
100Hz~10KHz
2.2kΩ
TBD
Specification
2
1.EKSA H1 Wireless Headset
2.Type-C Charging Cable
3.User Manual
4.Carry Pouch
Package Contents
Over View
3
4
5
6 7
1
2
3
4
1
2
Microphone
Multifunction Button
Volume +
Volume -
5
6
7
MIC Mute Button
Type-C Charging Port
Indicator Light
3
Operation function
Press and hold the multi-
function button for 3
seconds to power on or off.
Power On/Off
3″
short press the multi-func-
tion button to pause/play
the music
Play/Pause
x1
Three-click the MFB
multifunction button to start
SIRI/Voice Assistant
x3
SIRI
When a call comes in, short
press the multi-function
button to answer the call
Answer Calls
x1
short press the
multi-function button to
hang up the call
Hang up
x1
press and hold the
multi-function button for 1
second to reject the call
x1
Reject calls
4
Operation function
2″
x1
x1
2″
Note:
When you use headphones, if you find that the environmental noise is not
reduced. then you need to turn on the environmental noise reduction function.
how to use as below:
At the same time, long press both volume up and volume down buttons to turn
on or turn off the environmental noise reduction function. you can hear the voice
prompts here “microphone on” or “microphone off” (After turn on the environ-
mental noise reduction function, unless it needs to be turned off under special
circumstances, it will remain turned on at other times)
Click the mute button to
mute microphone(voice
prompt) and click mute
button to cancel mute
(voice prompt).
Mute
Microphone
x1
Click volume “+” button
Volume “+”
Long press the volume “+
”button for 2 seconds
Next track
Click Volume “-” button
Volume “-”
Long press the volume “-
”button for 2 seconds
Previous track
5
How to Use
1. Long press the multi-function button of EKSA H1 for 3
seconds to enter the pairing mode, and the red and blue
lights flash alternately.
2. Turn on the Bluetooth® of the mobile phone and select
"EKSA H1" from the list of found devices. When "EKSA H1"
appears, click the pairing connection. After the connection
is successful, the LED turns to blue light flashing slowly,
you will hear the voice prompt "connected".
Bluetooth® Pairing and Connection
3″
EKSA H1
Note：Ensure that the headphones are within 1m range of your smartphone and that
Bluetooth® is activated on the head- phones when performing this procedure.
3. If you want to pair the headset with another device when
already paired, you need to turn off the Bluetooth®
on the current connected device. then connect head-
phones with the second device as above. it can't support to
connect with two Bluetooth® devices simultaneously.
6
How to Use
If the headset fails to pair with your Bluetooth® device,
you need to clear the pairing history. When the headset is
charging, long press and hold multi-function button for
over 10 seconds until the LED indicator flashes red and
blue. Then re-pair your Bluetooth® device as instructed in
Pairing.
Clear Bluetooth® Pairing
Charging
When the EKSA-H1 is in low battery, the red light flashes,
please charge it immediately. Charging for about 3 hours,
when the red light is off and the blue light is always on, it
means that the battery is fully charged.
*Note:
A. When EKSA-H1 is not in use, please charge it at least
one time every 2 months.
Charging voltage can't exceed 5V.
B. It is recommended to charge the headphones using
only the original USB cable. Don't use headphones when
Charging.
C. Please make sure the microphone is not muted before
using.
Limited Warranty
7
Please sign up for EKSAtelecom warranty service at www.ek-
satelecom.net We provide a 2-year warranty from the date of
retail purchased by the original end-user. And it is delivered
from EKSAtelecom authorized reseller, in original package, in
new condition and is free from any defects in manufacturing
and workmanship. We will repair or replace (using new or
refurbished replacement product) any defective product within
a reasonable period and free of charge.
This warranty does not cover defects resulting from improper
or unreasonable use or maintenance; failure to follow
operating instructions; accidents; excess moistures; insects;
lightning; unauthorized alteration or modification of original
condition; damage caused by inadequate packing or shipping
procedures; loss of, damage to or corruption of stored data;
damage caused by use with non-EKSAtelecom products; the
product that requires modification or adaptation to enable it to
operate in any country other than the country for which it was
designed, manufactured, approved and/or authorized, or
repair of products damaged by their modifications; and
products purchase from unauthorized dealers.
How to Make a Claim?
In the event damage has occurred to products, you must
follow these instructions:
number in e-commerce website after you discover a
product defect
In order to get professional solutions from EKSAtelecom,
please give a detailed explanation of how the damage occurred.
Return the products. EKSAtelecom will, at our sole option,
repair or replace (using new or refurbished replacement
parts) any defective parts within a reasonable period
of time and free of charge.
Please attach the video and the description of the product.
We could solve the problem with more details timely. Those
who email with videos and detailed descriptions will be
awarded with 1 gift product.
Other Legal rights
This limited warranty gives you specific legal rights, and you
also may have other rights that vary from state to state or
country to country. Some places do not allow limitations on
implied warranties or the exclusion or limitation of incidental
or consequential damages, so the above limitations or
exclusions may not apply to you. Thank you for choosing
EKSAtelecom. We hope you enjoy our product. Do you like the
purchase experience in our store? We'd appreciate it if you
can share your fair product review and feedback. If you are
not completely satisfied, please reply to [email protected]
or you can contact us via
HongKong Customer Center: +852 6940 4955
(Mon to Fri 9:00 am- 6:30 pm, UTC+8 HKT)
India Customer Center: +91 84319 76061
(Mon to Sat IST 9:30 am-6:00 pm) so that we may a
ddress your concerns before you leave a product review.
8
9
Note
If you can’t connect the headset/headphones to your
devices, please ask us for complete FAQ guidance. You
can find the solution finally.
Depending on your head/ear size/shape, it may be a little
tight (feels like“on ear") for someone to wear which is
designed to avoid sound leakage. In case of that and to
get both audio and wearing comfort, please take off the
headphone every 1~2 hours to get your ears relaxed and
protect them from the muggy environment in use.
