Elation RGB Lamp Bedienungsanleitung

Rev. 6/6/2008 Version 1.53/27

User Manual - RGB

Elation Professional

6122 S Eastern Ave

Los Angeles, Ca 90040

www.elationlighting.com

©Elation Professional® 2 impression™

©Elation Professional® 3 impression™

CONTENTS

1. General Information……………………………………………………………………… 4

a. Introduction………………………………………………………………………. 4

b. Unpacking………………………………………………………..…………..….. 4

c. Customer Support…………………………………………….………………… 4

d. Warranty Registration……………………………………………………..……. 5

e. Discharge Lamp Warning………………………………………………………. 5

2. Safety Guidelines………………………………………………………........……………6

3. Fixture Overview…………………………………………………………………………..7

4. Features……………………………………………………………………………………11

5. General Guidelines………………………………………………………………………. 10

6. Mounting and Installation………………………………………………………….……..12

a. Mounting Points…………………………………………………………………..13

b. Clamp Mounting ………………………………………………………………….14

c. Floor Mounting ……………………………………………………………………14

d. Side Mounting ……………………………………………………………………15

e. Securing………………………………………………………………………….. 16

7. Understanding DMX……………………………………………………………………... 17

a. DMX Cable Requirements……..………………………………………………. 17

b. DMX Terminator…………………………………………………………………. 19

c. 3-Pin to 5-Pin Conversion……………………………………………………….19

d. DMX Addressing………………………………………………………………… 19

8. Fixture Menu……………………………………………………………………………… 21

9. Operation..…………………………………………………………………………………24

10. DMX Channel Traits…...….…………………………………………………………….. 25

a. 14 Channel Mode ………………………………………………………………. 25

b. 10 Channel Mode ………………………………………………………………. 28

c. 13 Channel Mode ………………………………………………………………. 29

11. Cleaning and Maintenance……………………………………………………………… 30

12. Warranty……………………………………………………………………………………31

13. Dimensional Drawings………………………………………………….……………….. 33

14. Technical Specifications…………………………………………...………….………… 34

©Elation Professional® 4 impression™

1. GENERAL INFORMATION

INTRODUCTION: Congratulations, you have just purchased one of the most innovative and

reliable lighting fixtures on the market today! The Impression,™ has been designed to

perform reliably for years when the guidelines in this booklet are followed. Please read and

understand the instructions in this manual carefully and thoroughly before attempting to

operate this unit. These instructions contain important information regarding safety during

use and maintenance.

UNPACKING: Thank you for purchasing the Impression™ by Elation Professional®. Every

Impression™ has been thoroughly tested and has been shipped in perfect operating

condition. Carefully check the shipping carton for damage that may have occurred during

shipping. If the carton appears to be damaged, carefully inspect your unit for damage and be

sure all accessories necessary to operate the unit have arrived intact. In the event damage

has been found or parts are missing, please contact our customer support team for further

instructions. Please do not return this unit to your dealer without first contacting customer

support at the number listed below.

CUSTOMER SUPPORT: Elation Professional®provides a customer support line, to provide

set up help and to answer any question should you encounter problems during your set up

or initial operation. You may also visit us on the web at www.elationlighting.com for any

comments or suggestions. For service related issue please contact Elation Professional®.

Service Hours are Monday through Friday 8:00 a.m. to 5:00 p.m. Pacific Standard Time.

Voice: (323) 582-3322

Fax: (323) 832-9142

E-mail: [email protected]

Forum: www.ElationLighting.com/forum

Warning! To prevent or reduce the risk of electrical shock or fire, do not expose this unit to

rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not attempt any repairs

yourself, doing so will void your manufactures warranty.

©Elation Professional® 5 impression™

Please do not discard the shipping carton in the trash. Please recycle whenever possible.

WARRANTY REGISTRATION: The Impression™ carries a two year (730 days) limited

warranty. Please fill out the enclosed warranty card to validate your purchase. All returned

service items whether under warranty or not, must be freight pre-paid and accompany a

return authorization (R.A.) number. The R.A. number must be clearly written on the outside

of the return package. A brief description of the problem as well as the R.A. number must

also be written down on a piece of paper and included in the shipping container. If the unit is

under warranty, you must provide a copy of your proof of purchase invoice. Items returned

without a R.A. number clearly marked on the outside of the package will be refused and

returned at customer’s expense. You may obtain a R.A. number by contacting customer

support at (323) 582-3322.

Never open this fixture while in use!

This fixture operates with extremely high voltages. Shock may occur if this fixture is opened

during use.

This device falls under protection-class 1. Therefore it is essential that the device be

grounded properly.

All electrical connections must performed by qualified personal.

Be sure to always use an approved “Power Con” connector. Never attempt to modify the

power inlet. Be sure the power cord is never crimped or damaged. If the power cord is

damaged, replace it immediately with a new one of similar power rating.

Always disconnect from main power before performing any type of service or any cleaning

procedure.

Only handle the power cord by the plug. Never pull out the plug by tugging the wire portion of

the cord.

Please be aware that damages caused by user modifications to the device are not subject to

warranty.

©Elation Professional® 6 impression™

2. SAFETY GUIDLINES

The Impression™ is an extremely sophisticated piece of electronic

equipment. To guarantee a smooth operation, it is important to follow the

guidelines in this manual. The manufacturer of this device will not accept

responsibility for damages resulting from the misuse of this fixture due to

the disregard of the information printed in this manual.

1. Always be sure that the fan and the air inlets remain clean and are never blocked.

Allow about 6” (15cm) between this fixture and other devices or a wall to allow for

proper cooling.

2. Never touch the fixture during normal operation. This can cause severe personal

injuries and/or damage to the fixture.

3. Be sure to unplug the Impression™ and allow it to cool for at least 15 minutes

before attempting to change the optical lens assembly.

4. Never look directly into the lamp beam. You risk injury to your retina, which may

induce blindness.

5. For safe operation, follow the Installation guide described in chapter three of this

manual. Operating the Impression™ without suited safety aids such as safety

cables or clamps can increase the risk of damage and/or personal injury.

6. Installation should only be performed by qualified and certified personal.

7. When mounting this fixture, use only the original rigging parts included with this

fixture. Any structural modification will void the original manufactures warranty and

may increase the risk of damage and/or personal injury.

8. To reduce the risk of fire or shock, do not expose this fixture to rain or moisture.

9. Do not attempt to operate this fixture if the power cord is damaged in any way.

10. The impression is a completely self-contained fixture, there are no user serviceable

parts or lamps to change. Please do not attempt to service this fixture. All service

related issues should be referred to an authorized Elation service technician.

Important Notice: Damages resulting from the disregard of safety and general user

instructions found in this user manual are not subject to any warranty claims.

©Elation Professional® 7 impression™

3. FIXTURE OVERVIEW

1. Head and Lens Assembly

(actively and passively

cooled)

2. Arm with various cooling

vents

3. LCD-Full Text Display and

Menu with Foil Key Pad (data

entry)

4. Base with various connectors

and Camlock mounting

system

5. Power On/Off Switch

6. DMX- Output (3-pin XLR)

7. DMX- Input (3-pin XLR)

8. Fuse Holder and Fuse (GMA

5x20mm, 220V/4A)

9. Main Power Input (Powercon)

10.Safety Cable Slot

©Elation Professional® 8 impression™

1. Head / LED Lens Assembly – The head assembly consist of the main output

lenses, and LED cluster module. A high-velocity variable speed fan is mounted in

the head to aid in the cooling process. The fan is designed to vary the velocity at

different operating temperatures. When the fixture reaches a predetermined

internal operating temperature the fan functions at high speeds. The higher speeds

provide better cooling associated with higher operating temperatures during long

use. When the fixture is operating at a lower temperature the fans operate at low

speed. Be sure to keep all vents clean, blocked cooling vents can shorten LED life

and reduce the fixtures reliability.

2. Arm / Cooling Fan – A high-velocity variable speed fan is mounted in the head to

aid in the cooling process. The fan is designed to vary the velocity at different

operating temperatures. When the fixture reaches a predetermined internal

operating temperature the fan functions at high speeds. The higher speeds provide

better cooling associated with higher operating temperatures during long use.

When the fixture is operating at a lower temperature the fans operate at low speed.

Be sure to keep all vents clean, blocked cooling vents can shorten LED life and

reduce the fixtures reliability.

3. 4-Segment Menu Display – This display details menu functions.

a) Mode Select Button – This button is used to access the fixture’s main

system menu and on-board programming functions.

b) Enter Select Button – This button is used to select and confirm a menu

function when working in the fixture’s operating system.

c) Down Select Button – This button is used to scroll backwards when

navigating through the system menu.

d) Up Select Button - This button is used to scroll forward when navigating

through the system menu.

4. Base - This fixture uses an integrated Camlock system for various mounting

options built in to the base. The Camlock clamp system allows a quick and efficient

means to secure the unit. For proper installation see “Mounting and Installation” on

page 12.

5. Power Switch – The switch is used to control main power to fixture’s electronics.

©Elation Professional® 9 impression™

6. DMX Output Jack – This 3-Pin XLR jack is used to send an outgoing DMX signal.

For best results this jack should be terminated if it is the last fixture in a DMX

daisy-chain (see termination on page 19).

7. DMX Input Jack – This 3-Pin XLR jack is used to receive an incoming DMX signal.

8. Electronics Fuse Holder – This housing holds a 250v/4A GMA fuse (120v

operation). Never defeat this fuse, this fuse is designed to protect the electronics in

the event of severer power fluctuations. In the event of fuse failure, always be sure

to replace this fuse with an exact match unless otherwise instructed by an

authorized Elation technician.

9. Powercon Connector – This power jack is designed to be used only with the

Neutrik Powercon adapter included with your fixture. This jack provides main power

to your fixture.

10.Safety Cable Mounting Point Connection – The fixture includes two safety cable

slots intergraded into the base. Be sure to use these slots as a secondary rigging

point to secure the fixture in the event a clamp fails.

©Elation Professional® 10 impression™

4. FEATURES

•Pan 660° / Tilt 300°

•LED White/Amber Additive Color Mixing

•Strobe effect: 0~10 flashes per second or random strobe

•90 Bright Luxeon K2 High-Powered LEDs

o30 Red

o30 Green

o30 Blue

•Dimmer intensity from 0%~100%

•User Selectable Color Change Modes

•Electronic Power Supply (100~240v / 50Hz~60Hz)

•Control board with full LCD character display and foil-keyboard

•Reversible Display Option (180˚ Flip)

•Auto test for all functions

•Automatic Pan/Tilt Correction

•10˚ Beam Angle

•Optional Lens Replacement Kit (25˚)

•Fully Functional in any Position

•USITT DMX-512 Complaint (3-pin DMX Connections)

•Value of each DMX-channel can be displayed

•Extremely Light Weight 16.5lbs / 7.5kg

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Elation Beleuchtungsausrüstung Handbücher

Elation

Elation ELAR EXTQW FLOOD HP Bedienungsanleitung

Elation

Elation Design LED 12 Brick II Bedienungsanleitung

Elation

Elation CMY Zoom 250 Bedienungsanleitung

Elation

Elation FS-150SCI Bedienungsanleitung

Elation

Elation Design LED 60 TriStrip Bedienungsanleitung

Elation

Elation CUEPIX BLINDER WW2 Bedienungsanleitung

Elation

Elation CMY Zoom 575 Bedienungsanleitung

Elation

Elation PowerWash 250 Bedienungsanleitung

Elation

Elation PLATINUM WASH ZFX PRO Bedienungsanleitung

Elation

Elation Design Spot 300E Bedienungsanleitung

Elation

Elation UV WASH Bedienungsanleitung

Elation

Elation impression rgb 120rz Bedienungsanleitung

Elation

Elation Level Q7 IP Bedienungsanleitung

Elation

Elation DMX Partner Bedienungsanleitung

Elation

Elation Power Spot 700 Bedienungsanleitung

Elation

Elation Design LED 36MH Bedienungsanleitung

Elation

Elation COLOUR CHORUS 72 Bedienungsanleitung

Elation

Elation EVENT PANEL SYSTEM Bedienungsanleitung

Elation

Elation Arena Par Bedienungsanleitung

Elation

Elation PLATINUM SPOT 35 PRO Bedienungsanleitung

Elation

Elation Vision Color 250 Bedienungsanleitung

Elation

Elation COLOUR 5 PROFILE Bedienungsanleitung

Elation

Elation RBG Tri Color LED Par Opti Tri Par Bedienungsanleitung

Elation

Elation E-LOADER III Bedienungsanleitung

Beliebte Beleuchtungsausrüstung Handbücher anderer Marken

Brizo

Brizo 8SP-MU-4 Bedienungsanleitung

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Bedienungsanleitung

IKEA

IKEA BJÖRKSPIREA Bedienungsanleitung

Laserworld

Laserworld Evolution Series ES-400RGB Bedienungsanleitung

Alien

Alien RG STAR Bedienungsanleitung

EuroLite

EuroLite LED B-40 Bedienungsanleitung

Qazqa

Qazqa Suplux SL 3 Black 103062 Bedienungsanleitung

Commercial Electric

Commercial Electric 54568141 Bedienungsanleitung

CREE LIGHTING

CREE LIGHTING 304 Series Bedienungsanleitung

Goobay

Goobay 49867 Bedienungsanleitung

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Bedienungsanleitung

Alkalite

Alkalite Krypton KT-81 Bedienungsanleitung

Clas Ohlson

Clas Ohlson GU10 Bedienungsanleitung

DTS

DTS DELTA 10 F Bedienungsanleitung

ring

ring Solar Steplight Bedienungsanleitung

One Stop Gardens

One Stop Gardens 57696 Montageanleitung

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Bedienungsanleitung

SIREM

SIREM Swimeo A2 Bedienungsanleitung
