Electroair Acquisition Corp. IM EA-13000 Page 1 of 10
Revision 03 Prepared by: EAC 02/04/2020
Electroair Acquisition Corp.
5097 Williams Lake Road
Waterford, MI 48329 U.S.A.
Phone: 248-674-3433 Fax: 248-674-4231
Email: sales@electroair.net
EA-13000
Installation Manual
Ignition/Starter Switch Panel
Electroair Acquisition Corp. IM EA-13000 Page 2 of 10
Revision 03 Prepared by: EAC 02/04/2020
Table of Contents
REVISION LOG .............................................................................................................. 2
OVERVIEW OF IGNITION/STARTER SWITCH PANEL INSTALLATION ..................... 3
EA-13000 KIT DESCRIPTION & REQUIREMENTS ....................................................... 4
EA-13000 KIT CONTENTS ............................................................................................. 4
RECEIVING AND ACCEPTANCE CHECKING OF EIS KIT .......................................... 4
PRECAUTIONARY STATEMENTS: ............................................................................... 5
INSTALLATION OF EA-13000: ...................................................................................... 6
GLOSSARY AND ABBREVIATIONS: .......................................................................... 10
Table of Figures
Figure 1: Configuration A Overall Dimensions ............................................................... 6
Figure 2: Configuration B Overall Dimensions………………………………………………6
Figure 3: Configuration A Cutout Dimensions ................................................................ 7
Figure 4: Configuration B Cutout Dimensions ................................................................ 8
Figure 5: Configuration A and B Back Surfaces……………...……………………………..9
Revision Log
Revision
Pages
Affected
Date of
Revision Description of Revision Approved
by
Date of FAA
Approval
00 05/12/2015 Initial Release 08/26/2015
01 05/12/2016 ECO 1019-0007
05/12/2016
02 06/20/2016 ECO 1019-0016
02/03/2017
03 1,2,4,5,7,
8,9 02/04/2020 ECO 1019-0079
Electroair Acquisition Corp. IM EA-13000 Page 3 of 10
Revision 03 Prepared by: EAC 02/04/2020
Overview of Ignition/Starter Switch Panel Installation
Thank you for purchasing an Electroair Ignition/Starter Switch Panel for Electroair
electronic ignition system equipped aircraft. Electroair is confident that you will be
happy with the performance of the Electroair Ignition/Starter Switch Panel for Electroair
electronic ignition system equipped aircraft. The next pages will provide a step-by-step
process of installing the EIS on the aircraft. Electroair hopes you will enjoy the
experience and that this manual will provide clear direction and guidance through this
process. This manual will cover the following general installation steps:
1. General overview and recommendations
2. Removal of old ignition components
3. Set-up & installation of p/n: EA-13000 Ignition/Starter Switch Panel
4. Final installation steps
Electroair strongly recommends reading through this entire installation procedure before
installing the Electroair Ignition/Starter Switch Panel for your Electroair electronic
ignition system equipped aircraft. Make sure that any questions are answered before
the actual installation. Also, make sure any extra components needed, e.g. cable ties,
switch terminations, etc., are available. Removal of old components and installation of
new components shall be completed in compliance with CFR Title 14 Part 43, as
applicable, and any Airframe or Engine Manufacturer Maintenance Procedures, as
applicable. Above all else, use good common sense and professional judgment. An
ignition/starter switch panel is an electrical device. If an ignition/starter switch panel is
improperly installed, severe damage could be caused to the ignition/starter switch
panel, EIS, aircraft, or installer including bodily injury or death.
Please contact Electroair with any questions during this installation process. Good luck
and happy flying!!
Electroair
Electroair Acquisition Corp. IM EA-13000 Page 4 of 10
Revision 03 Prepared by: EAC 02/04/2020
EA-13000 Kit Description & Requirements
EA-13000 System Description & Requirements:
1. This kit replaces the rotary key switch on aircraft with an EIS kit installed.
2. 12V or 24V electrical system capable of 0.75A.
Other items needed:
1. Basic tools and standard aircraft hardware required for mounting EA-13000
Ignition/Starter Switch Panel.
2. Electrical tools for cutting, stripping, and terminating various wiring. Also
recommended is a good selection of cable ties for harness routing and tie-off,
and a selection of shrink tubing for covering exposed electrical connections.
EA-13000 Kit Contents
EA-13000 Kit Contents:
1. ___EA-13000 Panel with Switches
2. ___Baggie with connectors and connecting hardware
3. ___USB Drive Containing System Documents (Installation Manual, STC, ICA)
4. ___Warranty registration--
**USE THIS TO OBTAIN THE STC AUTHORIZATION LETTER**
Receiving and Acceptance Checking of EIS Kit
1. Inspect the packaging for damage before acceptance from the freight carrier. If
damaged, refuse the package.
2. Open the package.
3. Inventory the contents of the package to the content listing of the package.
4. Are all of the materials there? If yes, proceed to step 5. If no, proceed to step 9.
5. Inspect the switches for broken plastic.
6. Inspect the panel for bends
7. Are all materials acceptable?
8. If yes, proceed with installation.
9. If no, contact the factory. Have the serial number of the kit available when
contacting. (factory 248-674-3433 or sales@electroair.net)
If possible, store parts in original packaging when not in use. If not possible, wrap parts
in cushioning material and place in one location. Review above prior to reinstallation.
For latest copies of documentation, refer to www.electroair.net.
Approved Model Listing (AML)
Approved Flight Manual
Supplement (AFMS)
Instructions for Continued
Airworthiness (ICA)
Installation Manual (IM)
Supplemental Type Certificate
(STC)
Trouble Shooting Instructions
(TSI)
Electroair Acquisition Corp. IM EA-13000 Page 5 of 10
Revision 03 Prepared by: EAC 02/04/2020
Precautionary Statements:
ALWAYS STAY OUT OF THE PROPELLER ARC!
CAUTION: Disconnect the battery before starting this procedure.
CAUTION: Prior to any drilling or cutting, verify that there is proper clearance.
CAUTION: Do not cut or alter any structural tubing, aluminum panels, or skin.
CAUTION: Follow these instructions very carefully to insure a correct hook-up of
the Ignition/Starter Switch Panel. Skipping ahead or taking short cuts increases
the risk of an incorrect installation and either a poor performing EIS or the
possibility of damaging equipment. Prior to turning on bus power, verify the
wiring. Please call Electroair with any questions (sales@electroair.net or 248-
674-3433).
CAUTION: Do not secure any radio communication, navigation, transponders or
intercom wiring to any ignition related wires, boxes, or sensors. Doing so will
cause poor to noisy transmission or reception of com and intercom and/or poor
or no navigation function. Keep at least 3 inches between these wires.
CAUTION: If using a non-impulse coupled magneto aka direct
drive magneto aka non-starting magneto, update pilot checklist/
POH to have MAG switch in OFF position during starting.
Consult with appropriate licensed mechanic.
Consult applicable service manuals for the aircraft.
Electroair Acquisition Corp. IM EA-13000 Page 6 of 10
Revision 03 Prepared by: EAC 02/04/2020
Installation of EA-13000:
1. General Overview and Recommendations:
Determine the proper location for the panel.
Determine the most appropriate mounting method.
Overall dimensions are provided in Figure 1 and Figure 2. Cutout dimensions are
provided in Figure 3 and Figure 4. All dimensions are in inches.
Figure 1: Configuration A Overall Dimensions
Figure 2: Configuration B Overall Dimensions
Electroair Acquisition Corp. IM EA-13000 Page 7 of 10
Revision 03 Prepared by: EAC 02/04/2020
2. Removal of Old Ignition Components:
Remove the existing rotary key switch.
Label all leads affixed to the rotary key switch in the process.
Save all of the parts for future reference.
If EIS was previously installed, either coil and stow P-lead wire or carefully clip P-
lead wire from harness.
If EIS not previously installed, remove P-lead from the magneto that is being
converted to the EIS system.
If the ignition/starter switch panel is not being installed in the rotary key switch
location, plug the hole left by removing the rotary key switch as necessary.
3. Set-up & Installation of p/n: EA-13000 Ignition/Starter Switch Panel:
Review the leads corresponding to the location of the ignition/starter switch
panel.
o Are they of the appropriate length?
o If not, adjust in accordance with 43.13-1B Change 1 section 11-167.
Remove the material of the instrument panel in accordance with the cutout
provided. Be advised that the drawing scale is not 1:1. All dimensions are in
inches.
Figure 3: Configuration A Cutout Dimensions
Electroair Acquisition Corp. IM EA-13000 Page 8 of 10
Revision 03 Prepared by: EAC 02/04/2020
Figure 4: Configuration B Cutout Dimensions
CAUTION: Before cutting or drilling verify space is clear behind the
instrument panel.
CAUTION: Use extreme care as to not damage any wiring,
instruments, structural, and fuel lines.
CAUTION: The connectors and connecting hardware for the starter switch are
small. Take extreme care not to lose them.
CAUTION: Ensure electrical connectors are tight on switch connections. Ensure
wires will not pull out of any electrical connections.
EIS Switch
o Use this switch as the EIS Ignition Switch shown in the EIS schematic.
o Connect C1 Pin 1 to connector labeled EIS.
o Connect connector labeled B+ to the 2A breaker or fuse.
Mag Switch
o Use this switch as the Magneto Switch.
o Connect ground to GND.
o Connect the P-Lead to P-LEAD.
Starter Switch
o Use this switch as the Start Switch.
o Connect lead from starter terminal of ignition switch to terminal 1.
o Connect B+ to terminal 2.
Insulate any exposed electrical connections in accordance with 43.13-1B Change
1 section 11-159.
Insert ignition/starter switch panel into instrument panel and screw down using
standard hardware.
Electroair Acquisition Corp. IM EA-13000 Page 9 of 10
Revision 03 Prepared by: EAC 02/04/2020
Figure 5: Configuration A and B Back Surfaces
4. Final Installation Steps:
CAUTION: If using a non-impulse coupled magneto aka direct
drive magneto aka non-starting magneto, update pilot checklist/
POH to have MAG switch in OFF position during starting.
Start the aircraft per the AFMS and perform a ground run-up.
o Check for proper starter function.
o Check for proper RPM drop on EIS.
o Check for proper RPM drop on magneto.
If the aircraft passes, then return to service.
If the aircraft fails, then verify that all of the connections are correct and
competent and that no other wires were damaged during the install. Repeat the
start-up process.
If the aircraft fails a second time, contact the factory for support. (248-674-3433
or sale[email protected])
Electroair Acquisition Corp. IM EA-13000 Page 10 of 10
Revision 03 Prepared by: EAC 02/04/2020
Glossary and Abbreviations:
AD(s) – Airworthiness Directive(s)
AFM – Aircraft Flight Manual
AFMS – Aircraft Flight Manual Supplement
ALS – Aircraft Limitations Section
AML – Approved Model List
APU – Auxiliary Power Unit
BTDC – Before Top Dead Center
CFR – Code of Federal Regulations
CSTW – Crank Shaft Trigger Wheel
EIS – Electronic Ignition System
FAA – Federal Aviation Administration
Ignition Timing – is the process of setting the angle relative to piston position and
crankshaft angular velocity that a spark will occur in the combustion chamber near the
end of the compression stroke.
IAW – In Accordance With
ISSP – Ignition/Starter Switch Panel
MAG – magneto
MAP – Manifold Absolute Pressure
May/Should – an optional requirement
MTH – Mag Timing Housing
Must/Shall – a mandatory requirement
RPM – Revolutions per Minute
POH – Pilot’s Operating Handbook
STC – Supplemental Type Certificate
TDC – Top Dead Center
