Electro-Voice EVID C8.2 Ceiling Bedienungsanleitung

Key Features:

• 8" coaxial two-way with extended LF

• Waveguide coupled Ti Tweeter

• Full bandwidth overload protection

• Front baffle wattage tap adjustment

• Integrated low loss matching transformer

allows for either 70v/100v or 8-ohm

operation

• Includes tile bridge and mounting ring for

easy installation

• Integrated ported enclosure for extended

bass response

EVID C8.2 Ceiling

8” Two-Way

Coaxial Ceiling

Loudspeaker System

General Description:

The Electro-Voice ® EVID C8.2 loudspeaker system is a

complete two-way ceiling loudspeaker package. The package

consists of a bezel assembly, grille, rear enclosure, 8-inch coax

two-way loudspeaker and internal line-matching transformer. The

loudspeaker features a waveguide coupled titanium coated dome

tweeter. The EVID C8.2 loudspeaker utilizes a 2nd order crossover

network at 2.5 kHz, with a comprehensive protection circuit to

protect the network, woofer, and tweeter drivers from excessive

power levels. The C8.2 utilizes a transformer that offers a

selection of 1.88 (70-V only), 3.75, 7.5, 15 or 30 watts delivered

to the loudspeaker system using either 70-V or 100-V lines, or 8

ohm bypass. Selection is via a convenient switch on the front

baffle. The perforated grille is finished in semi-gloss white

powder-coated enamel. The baffle and bezel are constructed

from UL 94V-0 rated ABS. The rear enclosure is constructed

from zinc-plated, heavy gauge steel. The rear enclosure, with

fiberglass damping material, provides an optimum internal

volume for extended low-frequency performance. A rear cover,

with provisions for a junction box fitting, provides access to a 4-

pin terminal block that allows direct connection to the speaker

with 12 gauge wire and provides pass through to additional

speakers. A tile bridge is included for safe suspension of the

C8.2 ceiling systems in a drop ceiling that uses mineral wool, or

other fiber-based ceiling tiles. The EVID line of ceiling speakers

has been designed to work together as a complete system in a

wide range of different ceiling constructions. They provide wide

dispersion, high-efficiency, high-maximum output, ease of

installation, and wide-range reproduction of music or voice.

Technical Specifications:

:)Bd01-(esnopseR.qerFzHk02-zH05

:)lacinoC(egarevoC°011

:gnildnaHrewoPkaePW004/.tnoCW001

:)m1/W1LPS(ytivitisneSBd19

:LPSdetaluclaCxaMBd711

:ecnadepmI)ssapybremrofsnart(lanimonsmhO8

:krowteN,detcetorpsrecudsnartdnakrowteN

zHk6.2tco/Bd21

:recudsnarTFLenocenelyporpyloP)mm002(.ni8

:recudsnarTFHetanimalralyMiT)mm52(ni1

:spaTremrofsnarTW03ro51,5.7,57.3,88.1:V07

W03ro51,5.7,57.3:V001

smhO8:ssapyB

:srotcennoCwercshtiw,elbavomerepytxineohP

21stpecca,"urht-pool"dnaslanimret

eriwag

:lairetaMerusolcnESBAdetarO-V49LU-elffaB

leetsdetalpcniZ-nackcaB

:ellirGhtiwleetsdetaocredwopdetarofreP

rehtetytefas

:erawdraHtroppuS,troppusetalpgnikcab,egdirbeliT

dleihstniap,etalpmettuotuc

:).aiDxH(miD"6.01x"0.01

)mm072xmm552(

:eziStuotuC)mm472("8.01

:)hcae(thgieWteN)gk0.5(sbl0.11

:)riap(thgieWgnippihS)gk0.11(sbl0.42

All Specifications based on Half Space Environment in ceiling.

Architects’ & Engineers’ Specifications: Frequency Response:

Block Diagram: Beamwidth:

Directivity:

Performance Match:

• EVID C10.1 Subwoofer

• CPS-1 Power Amplifier

• CPS-2 Power Amplifier

• CPS-2T Power Amplifier

• MA-1206 Mixer Amplifier

• MA-1212 Mixer Amplifier

EVID C8.2 Part Number

• 301261-000

12000 Portland Avenue South, Burnsville, MN 55337

Phone:952/884-4051, Fax:952/884-0043

www.electrovoice.com

Part Number 38110-126 Rev B

U.S.A. and Canada only. For customer orders, contact Customer Service at:

800/392-3497 Fax: 800/955-6831

Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:

+ 49 9421-706 0 Fax: + 49 9421-706 265

Other International locations. For customer orders, contact Customer Service at:

+ 1 952 884-4051 Fax: + 1 952 887-9212

For warranty repair or service information, contact the Service Repair department at:

800/685-2606

For technical assistance, contact Technical Support at: 866/78AUDIO

Specifications subject to change without notice.

Dimension Drawings:

The EVID C8.2 loudspeaker system shall be comprised of a UL 94V-0

fire rated ABS baffle/bezel assembly, zinc plated steel rear enclosure,

powder coated grille with safety tether, transformer with 8 ohm

bypass, and 8-inch polypropylene low frequency transducer with

coaxially-mounted waveguide coupled 1 inch titanium coated dome

tweeter. The loudspeaker shall meet the following criteria: power

rating shall be 100 watts of EIA RS-426A pink noise (6 dB crest

factor). Frequency response, uniform from 50 Hz to 20 kHz. Pressure

sensitivity, 91dB SPL at 1 meter (3.3 feet) on axis with one watt of

pink noise (ref. 20µPa). Minimum impedance, 6.0 ohms. The

loudspeaker shall be 255 mm (10.0 in.) deep and 270 mm (10.6 in.) in

diameter. Weight shall be 5.0 kg. (11.0 lb) The coaxial ceiling

loudspeaker shall be the Electro-Voice ® model EVID C8.2.
