Electro-Voice ZX4 Bedienungsanleitung

Technical Specifications:

The rugged enclosure of the Electro-Voice®Zx4 is perfect

for portable main mix and monitor applications, while the

stylish design gives it appeal in even the trendiest of

environments. At only 20.2 kg (44.5 lbs), the lightweight

Zx4 allows ease of transport and set up.

Every detail of your music is reproduced from extended

highs to powerful lows. The DH3 compression driver with

its pure titanium diaphragm, coupled with the Zx4’s large

90° x 50° horn allows for tremendous intelligibility and

pattern control.The EVS15-SF 15" LF delivers tight, low

bass and outstanding power handling capacity.

Zx4 is capable as an entire system. With an integral pole

mount the Zx4 is ready for main mix applications in DJ,

band and general entertainment use. To accomodate

different stage depths, Zx4 incorporates retractable

monitor feet.This allows Zx4 to be used as a stage

monitor with a 45° or 55° angle.

The high tech enclosure uses injection-molded high

impact polypropylene structural foam to make the Zx4

incredibly durable. The enclosure geometry elements

have been carefully designed to provide maximum

rigidity and bass response.

General Description:

Zx4

15-InchTwo-Way Passive

90°x50°,400W

Loudspeaker System

Key Features:

• EVS15-SF 15”LFTransducer

• DH3 1.25”Voice Coil, 1”Exit

Compression Driver

• 90° x 50° Coverage Pattern

• 400W Continuous (1600W) PowerHandling

• Selectable Monitor Angle (45° or 55°)

• High Sensitivity,132 dB Maximum SPL

• Lightweight 20.2 kg (44.5 lbs)

• Integral Pole Mount

esnopseR.qerF

:)Bd3-(zHk02-zH06

egnaR.qerF

:)Bd01-(zHk02-zH24

:ycneuqerFssapiH.ceRzH24

:ytivitisneSlaixA)m1/W1(Bd001

:LPSdetaluclaCxaMBd231

:egarevoClatnoziroH°09

:egarevoClacitreV°05

:rewoPmetsySdetaRkaePW0061,suounitnoCW004

:recudsnarTFLrevirD)mm183(ni51,FS-51SVE

:recudsnarTFHnoisserpmoCtixE)mm4.52(.ni1,3HD revirD

:ycneuqerFrevossorCzHk5.1

:ecnadepmIlanimoNsmhO8

:ecnadepmImuminiMsmhO5.6

:srotcennoC4LNnokaepSkirtueN

:lairetaMerusolcnEmaoFlarutcurtSenelyporpyloP

:noisnepsuS-elgniS3rofsnoitacolsaherusolcnE degroF8dnasetalPtnemhctattAdutS ,ediSno2,poTno2-stlobeyEleetS erusolcnEforaeRno4dna

:ellirGAG61,detaoCredwoPretseyloP leetSdezinavlaG

:)DxWxH(miDmm114xmm644xmm296 )"61.61x"75.71x"62.72(

:thgieWteN)sbl5.44(gk2.02

:thgieWgnippihS)sbl9.25(gk0.42

1 Half Space measurement.

U.S.A. and Canada only. For customer orders, contact Customer Service at:

800/392-3497 Fax: 800/955-6831

Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:

+ 49 9421-706 0 Fax: + 49 9421-706 265

Other International locations. For customer orders, contact Customer Service at:

+ 1 952 884-4051 Fax: + 1 952 736-4212

For warranty repair or service information, contact the Service Repair department at:

800/685-2606

For technical assistance, contact Technical Support at: 866/78AUDIO

Specifications subject to change without notice.

12000 Portland Avenue South, Burnsville, MN 55337

Phone:952/884-4051,Fax: 952/884-0043

www.electrovoice.com

Part Number 38110-416 Rev. A

Frequency Response & Impedance:

Beamwidth:

Directivity:

Block Diagram:

This Zx4 Loudspeaker should be suspended overhead only in accordance with the procedures and limitations specified.

This system should be suspended with certified rigging hardware by an authorized rigging professional and in compliance with local,

state, and federal overhead suspension ordinances.

CAUTION

Dimension Drawings:

Front View

Top View

Right View

Zx4PartNumber

• 301774-001 Zx4, 90° x 50° Horn, Black Finish

PerformanceMatch

• 301576-001 SbA760, 120V 15” Powered Subwoofer,760W

• D170258 CP2200, 120V Power Amplifier, 2 x 800W

Accessories

• 301626-001 MB5-B, Wall/Ceiling Mounting Bracket (Black)

• 301626-002 MB5-W, Wall/Ceiling Mounting Bracket (White)

• 301634-000 EBK-3, Forged M8 Eyebolt Kit (Set of Three)

• 301633-000 SSK-1, Single-Stud Rigging Kit (Set of Three)

• 301812-000 RK-Z, Anchor Plate Kit (Set of Three)

• 593717 100BK, Tripod Speaker Stand
