PROFESSIONAL LAUNDRY

W5180S

20/45

180

650

742

200

13.0

51 47 51 47

128+31 65+17 159+0 82+0

0.3/0.9/2.0 0.25/0.75/1.05 0.3/- 0.25/-

- - 4.4 2.7

58 66 58 66

Washer extractor

W5180S

Images shown are a representation of the product only and

variations may occur.

Main options

• Automatic liquid detergent supply (optional I/O board)

• Connection to booking- /payment- system or coin meter

Features and beneﬁts

• Compass Pro® microprocessor oﬀers:

– Large display and one control knob for easy program selection

– Language selection

– Quick selection and option buttons for the most frequently used

wash programs and options

– Wash program packages optimized on Economy, Perfomance

and Time. (Available on general programs)

•AS – Automatic Savings:

– The machine weighs the linen and adjusts the amount of water

and energy according to the load. This leads to considerable savings in

case the machine is not fully loaded. (Available on general programs)

• Extremely low water and energy consumption – see table below

• Four compartment detergent box for manual dosing of powder or liquid

detergent

• High extraction force for eﬃcient dewatering

• Door with gasket and strong hinges built for heavy duty operation

• Stainless and galvanized steel in all vital parts for high degree of rust

protection

• Power Balance:

– Maximises the extraction force, leading to highest dewatering

and savings in drying

– Minimizes the stress on the machine, leading to trouble-free

operation and increased machine lifetime

– Reduces vibrations, making it possible to install the machine in

all locations

Certiﬁed in accordance with ISO 9001 and ISO 14001 and approved IP 24D.

Main speciﬁcations

Max. capacity ﬁlling factor 1:9 kg/lb

Drum, volume litre

diameter ø mm

Extraction rpm

G-factor

Standard heating alternatives electricity kW

steam

non-heated

Consumption data ”Normal 60°C”

Economy*

Total time min

Water consumption (cold+hot) litre

Energy consumption (motor/heating/hot water) kWh

Steam consumption kg

Residual moisture %

* Water temperature 15°C cold water and 65°C hot water.

** Programs with AS.

*** Depending on steam pressure.

Full load, 20 kg Half load**, 10 kg Full load, 20 kg Half load**, 10 kg

El Steam***

W5180S

200-600

170

300-600

12.4

3.0 ± 4.8

221

1.26

750

914

1345

500

1440

1048

1247

297

217

1227

1127

278

104

223

132

Share more of our thinking at www.electrolux.com

220-240V 1 ~ 50/60 13.0 13.5 63

220-240V 3 ~ 50/60 13.0 13.5 35

380-415V 3N ~ 50/60 13.0 13.5 25

440V 3 ~ 60 13.0 13.5 20

480V 3 ~ 60 13.0 13.5 20

220-480V 1 ~ 50/60 - 1.0 10

Water and steam connection

Water valves DN

Water pressure kPa

Capacity at 300 kPa l/min

Drain valve ø mm

Draining capacity l/min

Steam valve DN

Steam pressure kPa

Liquid detergent supplies

Floor requirements

Frequency of the dynamic force Hz

Floor load at max extraction kN

Sound levels

Sound power level (IEC 60704-2-4)

wash dB(A)

extraction dB(A)

Heat emission

% of installed power, max

Shipping data**

Weight net, kg

Shipping volume m3

Accessories

Steel base

Hose kits for water or steam

Fluﬀ collector

Dimensions in mm

A Width

B Depth

C Height

1 Operating panel

2 Door opening ø 395 mm

3 Detergent box

4Cold water

5 Hot water

6 Re-used water

7 Drain

8 Liquid detergent supply

9Electrical connection

10 Steam connection

Side view

Rear

Front

Art. No. 438919505EN/2015.07.09

We reserve the right to alter speciﬁcations without notice.

www.electrolux.com/professional

Electrical connections*

Heating Main voltage Heating Total Recommended

alternative power power fuse

Hz kW kW A

Electric heated

Steam or

Non heated

Front and side panels in light grey and blue (RAL 260 70 05, 250 60 30)

* Other voltages available, see installation manual

** Average data. Crated weight/shipping volume depends on conﬁguration.

Please contact logistics for exact measures.
