Electrolux WA1459F Bedienungsanleitung
CONTENTS
1. SAFETY INFORMATION...................................................................................... 3
2. SAFETY INSTRUCTIONS.....................................................................................4
3. PRODUCT DESCRIPTION................................................................................... 6
4. CONTROL PANEL...............................................................................................7
5. PROGRAMMES ..................................................................................................8
6. CONSUMPTION VALUES..................................................................................13
7. SETTINGS......................................................................................................... 14
8. OPTIONS...........................................................................................................15
9. BEFORE FIRST USE..........................................................................................16
10. DAILY USE...................................................................................................... 16
11. HINTS AND TIPS............................................................................................. 19
12. CARE AND CLEANING....................................................................................20
13. TROUBLESHOOTING......................................................................................24
14. EMERGENCY DOOR OPENING...................................................................... 26
15. TECHNICAL DATA...........................................................................................27
16. GUARANTEE ..................................................................................................28
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can be
safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com/webselfservice
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.electrolux.com2
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damages that are the result
of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning the use of the appliance in a safe
way and understand the hazards involved.
•Do not let children play with the appliance.
•Children aged 3 years and under must be kept away
from this appliance when it is in operation at all times.
•Keep all packaging away from children and dispose of it
appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance when
the door is open.
•If the appliance has a child safety device, this should be
activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•Do not change the specification of this appliance.
•Do not exceed the maximum load of 9 kg (refer to the
"Programme chart" chapter).
•The operating water pressure at the water entry point
from the outlet connection must be between 0.5 bar
(0.05 MPa) and 8 bar (0.8 MPa).
•The ventilation opening in the base (if applicable) must
not be covered by a carpet, mat, or any floor covering.
ENGLISH 3
•The appliance must be connected to the water mains
using the new supplied hose sets, or other new hose
sets supplied by the Authorised Service Centre.
•Old hose sets must not be reused.
•If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service
Centre or similarly qualified persons to avoid an
electrical hazard.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
•Do not use high pressure water sprays and/or steam to
clean the appliance.
•Clean the appliance with a moist cloth. Use only neutral
detergents. Do not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
2. SAFETY INSTRUCTIONS
2.1 Installation
• Remove all the packaging and the
transit bolts.
• Keep the transit bolts in a safe place. If
the appliance is to be moved in future
they must be reattached to lock the
drum to prevent internal damage.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use a damaged
appliance.
• Follow the installation instruction
supplied with the appliance.
• Do not install or use the appliance
where the temperature can be less
than 0°C or where it is exposed to the
weather.
• The floor area where the appliance is to
be installed must be flat, stable, heat
resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• Do not install the appliance directly
over the floor drain.
• Adjust the feet to have the necessary
space between the appliance and the
flooring.
• Do not install the appliance where the
appliance door cannot be fully opened.
• Do not put a container to collect
possible water leakage under the
appliance. Contact the Authorised
Service Centre to ensure which
accessories can be used.
2.2 Electrical connection
• The appliance must be earthed.
• Always use a correctly installed
shockproof socket.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Should the mains cable need to be
replaced, this must be carried out by
our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
www.electrolux.com4
• Do not touch the mains cable or the
mains plug with wet hands.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• This appliance complies with the E.E.C.
Directives.
2.3 Water connection
• Do not cause damage to the water
hoses.
• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let
the water flow until it is clean and clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
• Do not use an extension hose if the
inlet hose is too short. Contact the
service centre for the replacement of
the inlet hose.
• You can extend the drain hose to
maximum 400 cm. Contact the service
centre for the other drain hose and the
extension.
2.4 Use
WARNING!
Risk of injury, electrical
shock, fire, burns or damage
to the appliance.
• This appliance is for household use
only.
• Follow the safety instructions on the
detergent packaging.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Make sure that all metal objects are
removed from the laundry.
• Do not wash fabrics which are heavily
soiled with oil, grease or other greasy
substances. It can damage rubber
parts of the washing machine. Prewash
such fabrics by hand before loading
them into the washing machine.
• Do not touch the glass door while a
programme is in operation. The glass
can get hot.
2.5 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable close
to the appliance and dispose of it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements for
the disposal of Waste Electrical and
Electronic Equipment (WEEE).
ENGLISH 5
3. PRODUCT DESCRIPTION
3.1 Appliance overview
1
2
3
5
6
7
4
1Worktop
2Detergent dispenser
3Control panel
4Door handle
5Rating plate
6Drain pump filter
7Feet for levelling the appliance
3.2 How to activate the child
safety device
This device prevents children or pets from
being closed in the drum.
Turn the device clockwise, until the groove
is horizontal.
You cannot close the door.
To close the door, turn the device
anticlockwise until the groove is vertical.
3.3 Available from your
authorized dealer
Only appropriate accessories
approved by ELECTROLUX
ensure the safety standards
of the appliance. If
unapproved parts are used,
any claims will be invalidated.
Fixing plate kit (4055171146)
Available from your authorised dealer.
If you install the appliance on a plinth,
secure the appliance in the fixing plates.
Read carefully the instructions supplied
with the accessory.
www.electrolux.com6
4. CONTROL PANEL
4.1 Control panel description
1On/Off button Ein/Aus - Marche/Arrêt
2Programme knob
3Display
4Start Pause button (Start/Pause -
Départ/Pause)
5Delay start button (Zeitvorwahl -
Départ Différé)
6Time save button (Zeit Sparen - Court)
7Extra rinse button (Spülen + - Rinçage
+)
8Stain button (Flecken - Taches)
9Spin reduction button (Schleudern -
Essorage)
10 Temperature button (Temp.)
4.2 Display
A B C D
A
Temperature area:
Temperature indicator
Cold water indicator.
ENGLISH 7
B
Spin area:
Spin speed indicator
No Spin indicator1)
Rinse Hold indicator
1) Only available for Spin/Drain programme.
C
Display indicators:
Washing phase
Rinses phase
Spin phase
Child safety lock
Door locked
You cannot open the appliance door when the symbol is on.
You can open the door only when the symbol goes off.
Delay start
D
Time area:
Programme duration
Delay start
Alarm codes
Message of error
Programme is completed
5. PROGRAMMES
5.1 Programme Chart
Programme
Temperature
range
Maximum
load
Maximum
spin speed
Programme description
(Type of load and soil level)
Washing programmes
www.electrolux.com8
Programme
Temperature
range
Maximum
load
Maximum
spin speed
Programme description
(Type of load and soil level)
Koch/Bunt -
Blanc/Couleurs
95°C - Cold
9 kg
1400 rpm White cotton and coloured cotton. Normal soil
and light soil.
Koch/Bunt +
Vorwäsche -
Blanc/Couleurs +
Prélavage
95°C - Cold
9 kg
1400 rpm White cotton and coloured cotton. Heavy soil
and normal soil.
Extra Leise - Ex-
tra Silence
95°C - Cold
9 kg White and coloured cotton. Normal soil and light
soil. The programme eliminates all spinning phase
to perform a silent cycle. The cycle stops with wa-
ter in the tub.
Pflegeleicht -
Synthétiques
60°C - Cold
4 kg
1200 rpm Synthetic items or mixed fabric items. Normal
soil.
Leichtbügeln -
Repassage Fac-
ile
60°C - Cold
4 kg
800 rpm Synthetic items requiring a gentle wash. Nor-
mal and light soil.1)
Feinwäsche -
Délicats
40°C - Cold
4 kg
1200 rpm
Delicate fabrics such as acrylics, viscose and
mixed fabrics requiring a mild washing. Nor-
mal soil.
Wolle/Seide -
Laine/Soie
40°C - Cold
2 kg
1200 rpm
Machine washable wool, hand washable wool
and other fabrics with «hand washing» care sym-
bol2).
Daunen - Cou-
ette
60°C - 30°C
3 kg
800 rpm
Special programme for one synthetic blanket,
duvet, bedspread and so on.
Schleudern/
Pumpen - Essor-
age/Vidange3)
9 kg
1400 rpm
To spin the laundry and to drain the water in the
drum. All fabrics, except woollens and delicate
fabrics.
ENGLISH 9
Programme
Temperature
range
Maximum
load
Maximum
spin speed
Programme description
(Type of load and soil level)
Spülen - Rinçage
9 kg
1400 rpm
To rinse and spin the laundry. All fabrics, except
woollens and very delicate fabrics. Reduce the
spin speed accordingly to the type of laundry.
Jeans
60°C - Cold
9 kg
1200 rpm Items in denim and jersey. Also for dark col-
oured items.
20 min.-3 kg
40°C - 30°C
3 kg
1200 rpm
Cotton and synthetic items with light soil level
or worn only once.
Super Eco 30°
30°C - Cold
3 kg
1200 rpm Cottons, synthetic and mixed fabrics. Normal
soil4).
Baumwolle Eco -
Coton Eco5)
60°C - 40°C
9 kg
1400 rpm White cotton and fast-coloured cotton. Normal
soil. The energy consumption decreases and the
time of the washing programme is extended.
Steam programmes6)
Steam can be used for dried, washed or worn once laundry. These programmes can
reduce creases and odours and make your laundry softer.
Do not use any detergent. If necessary, remove stains by washing or using localized
stain removal.
Steam programmes do not perform any hygienic cycle.
Do not set a Steam programme with these types of items:
• Items to be washed at a temperature lower than 40°C.
• Items where it is not specified on the care label as being suitable for tumble drying.
• All items with plastic, metal, wooden parts or alike.
Auffrischen - Ra-
fraîchir
1.5 kg Steam programme for cotton and synthetic
items. This cycle removes odours from the laun-
dry7).
www.electrolux.com10
Andere Handbücher für WA1459F
1
Inhaltsverzeichnis
Sprachen:
Andere Electrolux Waschmaschine Handbücher
Electrolux
Electrolux EFLS210TIS01 Bedienungsanleitung
Electrolux
Electrolux Frigidaire CTF140FS0 Handbuch
Electrolux
Electrolux EWF 12780 W Bedienungsanleitung
Electrolux
Electrolux EW 770 F Bedienungsanleitung
Electrolux
Electrolux EWM1000 Bedienungsanleitung
Electrolux
Electrolux EWF 126110W Bedienungsanleitung
Electrolux
Electrolux LP 5260 Bedienungsanleitung
Electrolux
Electrolux EIFLS20QS Series Bedienungsanleitung
Electrolux
Electrolux WA GL2 T 201 Bedienungsanleitung
Electrolux
Electrolux EWF 672 Bedienungsanleitung
Electrolux
Electrolux EWM1000 Bedienungsanleitung
Electrolux
Electrolux EWF 888 Bedienungsanleitung
Electrolux
Electrolux EFLW417SIW Bedienungsanleitung
Electrolux
Electrolux EW6S5426E6 Bedienungsanleitung
Electrolux
Electrolux EW6F5348B5 Bedienungsanleitung
Electrolux
Electrolux Clarus Vibe WH6-14LAG Bedienungsanleitung
Electrolux
Electrolux EWF 1229 Bedienungsanleitung
Electrolux
Electrolux EWFLS70J RR Bedienungsanleitung
Electrolux
Electrolux EWF 1487 HDW2 Bedienungsanleitung
Electrolux
Electrolux EIFLW55HIW - 27" Front-Load Washer Bedienungsanleitung
