Elo TouchSystems PayPoint Plus for Android Bedienungsanleitung

Revision A

P/N E132130

www.elotouch.com

Quick Installation Guide

Elo PayP

oint® Plus for Android

The information in this document is subject to change without notice. Elo Touch Solutions, Inc. and its Afﬁliates ( collectively “ Elo”) m akes n o

representations or warranties with respect to the contents herein, and speciﬁcally disclaims any implied warranties of merchantability or ﬁtness for a

particular purpose. Elo reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation

of Elo to notify any person of such revisions or changes.

No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer

language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior

written permission of Elo Touch Solutions, Inc.

Elo (logo), Elo PayPoint and Elo Touch Solutions are trademarks of Elo and its Affiliates.

Asia-Paciﬁc

Tel +86 (21) 3329 1385

Fax +86 (21) 3329 1400

[email protected]

Latin America

Tel 786-923-0251

Fax 305-931-0124

EloSales.LAT[email protected]

Contents:

1x PayPoint Plus for Android

1x Receipt paper roll

1x Power cord

2x Cash drawer keys

1x RJ45 to DB9 serial cable

For software development kit please visit

www.elotouch.com

Elo Touch Solutions Technical Support

Online self-help:

https://www.elotouch.com/support

North America

800-ELO-TOUCH

Tel +1 408 597 8000

Fax +1 408 597 8050

[email protected]

Europe

Tel +32 (0)16 70 45 00

Fax +32 (0)16 70 45 49

[email protected]

Connect power and ethernet cable. Connections are underneath the

Install receipt paper: Install the paper by pressing the lid release button

and lifting up the printer lid. Note the correct paper orientation from

pictures above. Do not use paper that exceeds 80 mm in width.

If an Internet connection is not found in Step 3, hold the power button

for 3 seconds and release. This lets you enter the set-up page to find

your Wi-Fi connection. Under the Network Tab, select the Wi-Fi

network. Once connected, your device should start auto provisioning

itself to your software provider. Once set up is complete, password

1elo can be used to re-enter control panel if needed.

Power on the register: Press the power button (located on the back of

the display head). If an Ethernet connection is available, registration

will start automatically when the device powers on.

" 

12-r)$.

.
