Elo TouchSystems 1515L Bedienungsanleitung

Touchmonitor User Guide

1515L 15¨ LCD Desktop Touchmonitor,1000 Series

(Optional Magnetic Stripe Reader Available)

(shown with optional Magnetic Stripe Reader)

User Guide

15"LCD Desktop

1515L Series

Revision D

P/N 008612E

No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system,

or translated into any language or computer language, in any form or by any means, including, but not

limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written per-

mission of Elo TouchSystems. Disclaimer

The information in this document is subject to change without notice. Elo TouchSystems makes no

representations or warranties with respect to the contents hereof, and specifically disclaims any

implied warranties of merchantability or fitness for a particular purpose. Elo TouchSystems re-

serves the right to revise this publication and to make changes from time to time in the content

hereof without obligation of Elo TouchSystems to notify any person of such revisions or changes.

Trademark Acknowledgments

AccuTouch, AT4, CarrollTouch, IntelliTouch, iTouch, MonitorMouse and SecureTouch are trade-

marks of Elo TouchSystems, Inc.

Other product names mentioned herein may be trademarks or registered trademarks of their respec-

tive companies.

iii

Table of Contents

Chapter1

Introduction 7

Product Description ...................................................7

Precautions ................................................................7

About the product .......................................................8

Chapter2

Installation and Setup .................................... 9

Unpacking Your Touchmonitor...................................9

Touch Interface Connection .......................................10

MSR Interface connection(Optional) ..........................10

Product Overview ......................................................11

Main Unit ..............................................................11

Rear View ............................................................11

Installing the Driver Software .....................................12

Installing the Serial Touch Driver .........................13

Installing the Serial Touch Driver for Windows

Vista, Windows XP, Windows 2000, Me,

95/98 and NT 4.0 ............................................13

Installing the Serial Touch Driver for MS-DOS

and Windows 3.1..................................................14

Installing the USB Touch Driver...........................15

Installing the USB Touch Driver for Windows

Vista, Windows XP, Windows 2000, Me,

95/98 and NT 4.0 ............................................15

Installing APR USB Touch Driver for

Windows XP ........................................................16

Chapter3

Operation 17

About Touchmonitor Adjustments ..............................17

Side Panel Controls .............................................18

Controls and Adjustment ............................................19

OSD Menu Functions ..........................................19

OSD Lock/Unlock ................................................19

OSD Control Options ...........................................20

Preset Modes.......................................................21

Power Management System ................................22

Display Angle .............................................................22

Chapter4

Troubleshooting 23

Solutions to Common Problems .................................23

AppendixA.................................................... 25

Native Resolution .......................................................26

AppendixB

Touchmonitor Safety ..................................................27

Care and Handling of Your Touchmonitor ..................28

AppendixC

Touchmonitor Specifications ......................................30

IntelliTouch Touchmonitor Specifications .............31

AccuTouch Touchmonitor Specifications.............32

Acoustic Pulse Recognition Specifications ..........33

15" LCD Touchmonitor (ET1515L-XXXC-1-G)

Dimensions ................................................................34

Regulatory Information ............................... 37

Warranty ...................................................... 40

Index ......................................................................41

CHAPTER

INTRODUCTION

Product Description

Your new touchmonitor combines the reliable performance of touch technology with the latest

advances in LCDdisplay design.This combination of features creates a natural flow of information

between a user and your touchmonitor.

This LCD monitor incorporates 15” color active matrix thin-film-transistor (TFT) liquid crystal

display to provide superior display performance.Amaximum resolution of XGA1024 x 768 is ideal

for displaying graphics and images. Other outstanding designs that enhance this LCDmonitor’s

performance are Plug & Play compatibility, and OSD(On ScreenDisplay) controls.

Precautions

Follow all warnings, precautions and maintenance as recommended in this user’s manual to

maximize the life of your unit. SeeAppendix B for more information on touchmonitor safety.

1-7

About the Product

The 1515LLCDDesktopTouchmonitor is a 15” XGATFT color display with the following features:

• The internal microprocessor digitally controls auto-scanning. For horizontal scan frequencies

between 31.5 KHz and 60.2 KHz, and vertical scan frequencies between 56.3 Hz and 75.0 Hz. In

each frequency mode, the microprocessor-based circuitry allows the monitor to function at the

precision-of a fixed frequency.

• High contrast colorTFT LCDdisplay support resolution up to XGA1024 x 768. Compatible with

VGA, SVGA, XGA(non-interlaced) and most Macintosh compatible color video cards.

• Power management system conforms to VESADPMS standard.

• SupportsDDC1/2B for Plug & Play compatibility.

• Advanced OSDcontrol for picture quality adjustment.

• Detachable stand for wall-mounting application.

• Optional touch screen function.

For full Product Specifications refer toAppendix C.

1-8 UserGuide

CHAPTER

INSTALLATION AND SETUP

This chapter discusses how to install the 1515L LCDtouchmonitor and the driver software.

Unpacking Your Touchmonitor

Check that the following 8 items are present and in good condition:

LCD monitor VGAcable USB cable

Serial Cable European power cable Power cable US/Canada

CDand Quick InstallGuide

2-9

Elo QuickStart

Software

Power Cord Video CableUSB Cable Serial Cable

Power Cord Video CableUSB Cable

For APR model only

Touch Interface Connection

Note: Before connecting the cables to your touchmonitor and PC, be sure that the computer and

touchmonitor are turned off.

DC JACK

1. Connect one end of the power cord to the monitor and the other end to the AC outlet.

2. Connect one end of either the touchscreen serial(RS232) cable or the touch screen USB cable

(but not both) to the rear side of the computer and the other end to the LCD monitor. Tighten by

turning the two thumb screws clockwise to ensure proper grounding(optional module USB cable

does not have thumb screws)

3. Connect one end of the video cable to the rear side of computer and the other to the LCDmonitor.

Tighten by turning the two thumb screws clockwise to ensure proper grounding.

4. Press the power button on the front panel to turn the monitor power on.

Magnetic Stripe Reader(MSR) Interface Connection(optional)

If the MSR is installed on the monitor, plug the USB cable from the MSR directly to the PC.

No drivers are required to be loaded.

TochangetheMSRfunctionmodefromkeyboardemulationtoHID,loadthe“MSRCHANGE

MODE.EXE” utility from the enclosed TouchTools CD or go online to www.elotouch.com to

download this utility.

Note: MSRfunction modecan bechanged toHID modefrom keyboardemulation modeandback

using the “MSR CHANGE MODE.EXE” utility.

2-10 UserGuide

Product Overview

Main Unit

Rear View

KensingtonTM Lock

The KensingtonTM lock is a security device that prevents theft. To find out more about this security

device, go to http://www.kensington.com.

2-11

Installing the Driver Software

Elo TouchSystems provides driver software that allows your touchmonitor to work with your

computer. Drivers are located on the enclosed CD-ROM for the following operating systems:

• WindowsVista

• WindowsXP

• Windows 2000

• Windows Me

• Windows 98

• Windows 95

• WindowsNT 4.0

• Windows 3.1

• MS-DOS

Additional drivers and driver information for other operating systems are available on the Elo

TouchSystems web site at www.elotouch.com.

The Elo touchmonitor is plug-and-play compliant. Information on the video capabilities of your

touchmonitor is sent to your video display adapter when Windows starts. If Windows detects your

touchmonitor, follow the instructions on the screen to install a generic plug-and-play monitor.

Refer to the appropriate following section for driver installation instructions.

Depending upon whether you connected the serial communication cable or the USB

communication cable, only the serial driver or the USB driver should be installed.

2-12 UserGuide
