Elsner elektronik KNX K8 Leitfaden

Installation and Adjustment

KNX K8

Actuator for Heating and Cooling

Item number 70321

Elsner Elektronik GmbH Control and AutomationTechnology

Sohlengrund 16

75395 Ostelsheim Phone +49(0)7033/30945-0 info@elsner-elektronik.de

Germany Fax +49(0)7033/30945-20 www.elsner-elektronik.de

Technical support: +49 (0) 70 33 / 30 945-250

1 Contents

Elsner Elektronik GmbH • Sohlengrund 16 • 75395 Ostelsheim • Germany

KNX K8 actuator • from software version 1.00, ETS programme version 1.0

Status: 26.02.2016 • Subject to technical changes. Errors excepted.

1. Description ........................................................................................... 3

1.1. Technical data ........................................................................................................... 3

2. Installation and start-up ....................................................................... 4

2.1. Installation notes ...................................................................................................... 4

2.2. Device connection and design ................................................................................ 5

2.3. Notes on mounting and commissioning ................................................................ 5

2.3.1. Buttons and LEDs for the output channels ................................................. 5

3. Transmission protocol ......................................................................... 7

3.1. List of all communications objects ......................................................................... 7

4. Parameter setting .............................................................................. 10

4.1. Behaviour on power failure/ restoration of power .............................................. 10

4.2. General settings ..................................................................................................... 10

4.3. Channel 1...8 ........................................................................................................... 11

4.4. Temperature controller .......................................................................................... 13

4.4.1. General regulation ...................................................................................... 13

4.4.2. General set point values ............................................................................. 15

4.4.3. Heating control level 1/2 ............................................................................. 18

4.4.4. Cooling control level 1/2 ............................................................................. 20

2 Clarification of signs

This manual is amended periodically and will be brought into line with new software

releases. The change status (software version and date) can be found in the contents footer.

If you have a device with a later software version, please check

www.elsner-elektronik.de in the menu area "Service" to find out whether a more up-to-

date version of the manual is available.

Clarification of signs used in this manual

Installation, inspection, commissioning and troubleshooting of the device

must only be carried out by a competent electrician.

Safety advice.

Safety advice for working on electrical connections, components,

etc.

DANGER! ... indicates an immediately hazardous situation which will lead to

death or severe injuries if it is not avoided.

WARNING! ... indicates a potentially hazardous situation which may lead to

death or severe injuries if it is not avoided.

CAUTION! ... indicates a potentially hazardous situation which may lead to

trivial or minor injuries if it is not avoided.

ATTENTION! ... indicates a situation which may lead to damage to property if it is

not avoided.

ETS In the ETS tables, the parameter default settings are marked by

underlining.

3 Description

KNX K8 actuator • Version: 26.02.2016 • Technical Changes and Errors excepted.

1. Description

The KNX K8 actuator offers eight internal temperature regulators and eight output

channels for controlling heating or cooling systems. The temperature regulators can

control both the outputs on the KNX K8 and other climate control system on the KNX-

Bus.

In automatic mode, the temperature regulators are set at nominal temperatures for

different modes. This way, it is easy to switch between the modes, comfort, standby,

eco and building protection. The switch is made via an object e. g. via a manual switch,

time switch or sensor switch outputs in the KNX-System.

The buttons on the device allow for direct manual switching of the connected systems.

LEDs show whether the output channel was manually operated or is running in an

automatic mode.

Functions:

•8 internal, independent temperature regulators with automatic controls

for the heating and cooling controls (one or two step heating and cooling)

•8 output channels (230 V AC, 8 Watt per output) with pulse width modulation

control (PWM) for actuators

• Keypad field 8 buttons and status LEDs

Configuration is made using the KNX software ETS. The product file can be

downloaded from the Elsner Elektronik homepage on www.elsner-elektronik.de in

the “Service” menu.

1.1. Technical data

Housing Plastic

Colour White

Mounting Series installation on mounting rail

Protection category IP 20

Dimensions approx. 107 x 88 x 60 (W x H x D, mm), 6 modules

Weight approx. 270 g

Ambient temperature Operation -20…+70°C, storage -55…+90°C

Ambient humidity max. 95% RH, avoid condensation

Operating voltage 230V AC, 50 Hz

Power consumption max. 2 W

Power on bus: 10 mA

Outputs 8 x 230 V (OUT/N), not short-circuit-proof.

When connectiong one consumer load per separate channel

(1 to 8):

Max. load for continuous operation: 8 W per channel

Max. switch-on current: 1.1 A per channel

Observe the specifications in the data sheet of the consumer

load.

Data output KNX +/- bus connector terminal

4 Installation and start-up

KNX K8 actuator • Version: 26.02.2016 • Technical Changes and Errors excepted.

The product conforms with the provisions of EU directives.

2. Installation and start-up

2.1. Installation notes

Installation, testing, operational start-up and troubleshooting should

only be performed by an electrician.

DANGER!

Risk to life from live voltage (mains voltage)!

There are unprotected live components within the device.

• VDE regulations and national regulations are to be followed.

• Ensure that all lines to be assembled are free of voltage and take

precautions against accidental switching on.

• Do not use the device if it is damaged.

• Take the device or system out of service and secure it against

unintentional use, if it can be assumed, that risk-free operation is no

longer guaranteed.

The device is only to be used for its intended purpose. Any improper modification or

failure to follow the operating instructions voids any and all warranty and guarantee

claims.

After unpacking the device, check it immediately for possible mechanical damage. If it

has been damaged in transport, inform the supplier immediately.

The device may only be used as a fixed-site installation; that means only when

assembled and after conclusion of all installation and operational start-up tasks and

only in the surroundings designated for it.

Elsner Elektronik is not liable for any changes in norms and standards which may occur

after publication of these operating instructions.

BCU type unit's own microcontroller

PEI type 0

Group addresses max. 254

Assignments max. 254

Communication objects 249

5 Installation and start-up

KNX K8 actuator • Version: 26.02.2016 • Technical Changes and Errors excepted.

2.2. Device connection and design

2.3. Notes on mounting and commissioning

Device must not be exposed to water (rain). This could result in the electronics being

damaged. A relative air humidity of 95% must not be exceeded. Avoid condensation.

After the operating voltage has been applied, the device will enter an initialisation

phase lasting a few seconds. During this phase no information can be received or sent

via the bus.

2.3.1. Buttons and LEDs for the output channels

The buttons on the devices can be deactivated in the ETS (active when delivered).

1) Programming LED and programming buttons (PRG)

2) Bus terminal slot (KNX +/-)

3) Network LED (power)

4) Buttons and LEDs outputs 1-8

5) Sample connection: Per output max. 8 W

• Operating voltage input 230 V AC L/N/PE

L bridged to IN 1/2, IN 3/4, IN 5/6, IN 7/8

• Actuator on output 8 (OUT 8 | N)

All terminals N or PE of the lower connection strip are bridged internally.

Actuator

drive

Internally

Series

installation on

mounting rail

(6 modules)

bridged cables

6 Installation and start-up

KNX K8 actuator • Version: 26.02.2016 • Technical Changes and Errors excepted.

Buttons

LEDs

Behaviour of the LEDs for the output channels

in Automatic mode:

in Manual mode:

brief button press (<0,5 s) LED shows current status (see ETS parameter: Channel

LED)

button press >0,5 s in Automatic mode: Switching to Manual mode

in Manal mode: Switching from manually ON to

manually OFF and reverse

long button press (>3 s) Switching to Automatic mode (when activated in ETS)

Off Actuating variable = 0%

On Actuating variable > 0%

Flashes slowly Manually OFF

Flashes fast Manually ON

7 Transmission protocol

KNX K8 actuator • Status: 18.11.13 • Technical Changes and Errors excepted.

3. Transmission protocol

Units:

Temperatures in degrees Celsius

Variables in %

3.1. List of all communications objects

Abbreviation flags:

C Communication

R Reading

WWriting

T Transferring

UUpdating

No. Name Function DPT Flags

0 Software version Output 217,001 C R T

1 Channel 1: Control / Status Input / Output 5,001 C R W T

2 Channel 1: Auto / Manual Input / Output 5.002 C R W T

3 Channel 1: Block Input 1.001 K S

4 Channel 2: Control / Status Input / Output 5,001 C R W T

5 Channel 2: Auto / Manual Input / Output 5.002 C R W T

6 Channel 2: Block Input 1.001 K S

7 Channel 3: Control / Status Input / Output 5,001 C R W T

8 Channel 3: Auto / Manual Input / Output 5.002 C R W T

9 Channel 3: Block Input 1.001 K S

10 Channel 4: Control / Status Input / Output 5,001 C R W T

11 Channel 4: Auto / Manual Input / Output 5.002 C R W T

12 Channel 4: Block Input 1.001 K S

13 Channel 5: Control / Status Input / Output 5,001 C R W T

14 Channel 5: Auto / Manual Input / Output 5.002 C R W T

15 Channel 5: Block Input 1.001 K S

16 Channel 6: Control / Status Input / Output 5,001 C R W T

17 Channel 6: Auto / Manual Input / Output 5.002 C R W T

18 Channel 6: Block Input 1.001 K S

19 Channel 7: Control / Status Input / Output 5,001 C R W T

20 Channel 7: Auto / Manual Input / Output 5.002 C R W T

21 Channel 7: Block Input 1.001 K S

8 Transmission protocol

KNX K8 actuator • Status: 18.11.13 • Technical Changes and Errors excepted.

Temperature control (TC)

22 Channel 8: Control / Status Input / Output 5,001 C R W T

23 Channel 8: Auto / Manual Input / Output 5.002 C R W T

24 Channel 8: Block Input 1.001 K S

Name Func

tion

DPT Flags

25 53 81 109 137 165 193 221 TC_X_ measured

temperature

value

Input 9,001 K S

26 54 82 110 138 166 194 222 TC_X_ Eco-

Standby

HVAC 1

Input 1,003 K S

27 55 83 111 139 167 195 223 TC_X_ comfort

activation HVAC

Input 1,003 K S

28 56 84 112 140 168 196 224 TC_X_ Frost/heat

activation

Input 1,003 C R W

29 57 85 113 141 169 197 225 TC_X_ Blocking

object

Input 1.003 K S

30 58 86 114 142 170 198 226 RC_X_ Current

set point

Outp

9,001 C R T

31 59 87 115 143 171 199 227 TC_X_ Switching

object (0:Heating

| 1:Cooling)

Input 1,002 K S

32 60 88 116 144 172 200 228 TC_X_ Set point,

comfort heating

Input

Outp

9,001 C R W

33 61 89 117 145 173 201 229 TC_X_ Set point,

comfort heating

(1:+ | 0:-)

Input 1.002 K S

34 62 90 118 146 174 202 230 TC_X_ Set point,

comfort cooling

Input

Outp

9,001 C R W

35 63 91 119 147 175 203 231 TC_X_ Set point,

comfort cooling

(1:+ | 0:-)

Input 1.002 K S

36 64 92 120 148 176 204 232 TC_X_ Set point,

standby heating

Input

Outp

9,001 C R W

No. Name Function DPT Flags

9 Transmission protocol

KNX K8 actuator • Status: 18.11.13 • Technical Changes and Errors excepted.

37 65 93 121 149 177 205 233 TC_X_ Set point,

standby heating

(1:+ | 0:-)

Input 1.002 K S

38 66 94 122 150 178 206 234 TC_X_ Set point,

standby cooling

Input

Outp

9,001 C R W

39 67 95 123 151 179 207 235 TC_X_ Set point,

standby cooling

(1:+ | 0:-)

Input 1.002 K S

40 68 96 124 152 180 208 236 TC_X_ Set point,

eco heating

Input

Outp

9,001 C R W

41 69 97 125 153 181 209 237 TC_X_ Set point,

eco heating (1:+ |

0:-)

Input 1.002 K S

42 70 98 126 154 182 210 238 TC_X_ Set point,

eco cooling

Input

Outp

9,001 C R W

43 71 99 127 155 183 211 239 TC_X_ Set point,

eco cooling (1:+ |

0:-)

Input 1.002 K S

44 72 100 128 156 184 212 240 TC_X_ Control

variable, heating

(level 1)

Outp

5,001 C R T

45 73 101 129 157 185 213 241 TC_X_ Control

variable, heating

(level 2)

Outp

5,001 C R T

46 74 102 130 158 186 214 242 TC_X_ Control

variable, cooling

(level 1)

Outp

5,001 C R T

47 75 103 131 158 187 215 243 TC_X_ Control

variable, cooling

(level 2)

Outp

5,001 C R T

48 76 104 132 160 188 216 244 TC_X_ Status

Heating 1 (1=ON

| 0=OFF)

Outp

1.002 C R T

49 77 105 133 161 189 217 245 TC_X_ Status

Heating 2 (1=ON

| 0=OFF)

Outp

1.002 C R T

Name Func

tion

DPT Flags

Inhaltsverzeichnis

Andere elsner elektronik Controller Handbücher

elsner elektronik

elsner elektronik RF-MSG2-DST Bedienungsanleitung

elsner elektronik

elsner elektronik KNX RF-MSG-DST Leitfaden

elsner elektronik

elsner elektronik KNX S4-B10 230 V Bedienungsanleitung

elsner elektronik

elsner elektronik KNX S-B2-UP 230 V Gebrauchsanweisung

elsner elektronik

elsner elektronik KNX DALI L4 bc 16 A Leitfaden

elsner elektronik

elsner elektronik KNX S2 Bedienungsanleitung

elsner elektronik

elsner elektronik KNX S-B4T-UP 230 V Gebrauchsanweisung

elsner elektronik

elsner elektronik KNX eTR 205 Light Leitfaden

elsner elektronik

elsner elektronik KNX K4 Bedienungsanleitung

elsner elektronik

elsner elektronik KNX RF-MSG2-DST Bedienungsanleitung

elsner elektronik

elsner elektronik KNX S1R-BA4-UP Leitfaden

elsner elektronik

elsner elektronik Cala Touch KNX Bedienungsanleitung

elsner elektronik

elsner elektronik KNX S4-B12 DES Bedienungsanleitung

elsner elektronik

elsner elektronik KNX R4 16 A Leitfaden

elsner elektronik

elsner elektronik KNX S1R-B4 compact Leitfaden

elsner elektronik

elsner elektronik KNX S1R-B4-UP DES Bedienungsanleitung

elsner elektronik

elsner elektronik 70711 Bedienungsanleitung

elsner elektronik

elsner elektronik KNX R1-B4 compact 16 A Leitfaden

elsner elektronik

elsner elektronik KNX Touch One Style Bedienungsanleitung

elsner elektronik

elsner elektronik KNX S1R-B4-UP DES Leitfaden

elsner elektronik

elsner elektronik KNX RF S1R-B2 compact Leitfaden

elsner elektronik

elsner elektronik Nunio KNX M-T Leitfaden

elsner elektronik

elsner elektronik KNX RF-MSG-ST Bedienungsanleitung

elsner elektronik

elsner elektronik KNX eTR MultiTouch Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung

elsner elektronik KNX K8 Leitfaden

Beliebte Controller Handbücher anderer Marken
