Eneo MPD-62V2713P0A Bedienungsanleitung

User Manual

1/2.8” HD Dome, Fixed, Indoor,

Day&Night, 1920x1080, Infrared,

2.7-13.5 mm, 12VDC

MPD-62V2713P0A

Safety Precaution

ULTRA CLEAR RESOLUTION CAMERA

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

To prevent fire or shock hazard, do not expose the unit to rain or moisture.

To prevent electric shocks and risk of fire hazards, do NOT use other than

specific power source.

The symbol is intended to alert the user to the presence of important

operating and maintenance(servicing) instructions in the literature

accompanying the unit.

The symbol is intended to alert the user to the presence of uninsulated

"dangerous voltage" within the product's enclosure that may be of

sufficient magnitude to constitute a risk of electric shock to persons.

Warning :

This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference when the equipment

is operated in a commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at

his own expense.

Caution :

Any changes or modifications in construction of this device which are not expressly

approved by the party responsible for compliance could void the user's authority

to operate the equipment.

Mains power quality should be that of a typical commercial environment. If the user

of the model requires continued operation during power mains interruptions, it is

recommended that the model be powered from an uninterruptible power supply

(UPS) or a battery.

ULTRA CLEAR RESOLUTION CAMERA

Safety Precaution

NOTICE

The image used in this instruction manual are processed to help comprehension

and may differ from actual video of the camera.

Avoid installing areas where has shock or vibration which results in the problems.

Pay attention to safety when laying the connection cable and observe that the cable

is not subjected to heavy loads, kinks or damage and no moisture can get in.

Never open the device such as boards or lens.

The warranty becomes void if repairs are undertaken by unauthorized persons.

Maintenance and repair have to be carried out only by authorized service centers.

Use only a mild detergent to clean the housing.

The camera should never be operated beyond the technical specifications.

This can lead to destruction.

The camera should never be operated in water.

ULTRA CLEAR RESOLUTION CAMERA

Contents

Safety Precaution

p.03~04

Contents

p.05

Features

p.06

Composition

p.07

Dimensions

p.08

Part Names

p.09

Installation Instructions

p.10~12

Operating Instructions

p.13~30

Specifications

p.31~32

ULTRA CLEAR RESOLUTION CAMERA

Features

Key Features

• 1/2.8” SONY Exmor CMOS sensor

• 1080P TVI mode, CVI mode, AHD Video or 960H CVBS Video Selectable

• TVI mode/CVI mode/AHD Video Transmission Distance over Coax.; 500M

• Automatically removable IR Cut filter by Dual filter switcher

• Built-in f=2.7~13.5 mm F1.3 Mega pixel DC Auto Iris Vari-focal lens

• Sensitivity of Color 0.3 Lux / BW 0.005 Lux (@IRE 40, Sens-up On, IR Off)

• D-WDR (Wide Dynamic Range)

• Improved noise reduction 2D+3D-NR

(TVI mode/CVI mode/AHD)

, 2DNR(CVBS)

• FOCUS ASSIST for Error free focus adjustment

• 2 Auto(AE/AWB) control

• LSC (Lens Shading Compensation)

• DPC (Defective Pixel Compensation)

• Motion detection, Privacy mask, BLC/HSBLC, Defog, Sens-up(~x30),

Mirror/Flip, Freeze, Negative Image, IR Smart, Cam Title

• Built-in 2pcs High power SMD LED

• OSD MENU & CVBS output for easy installation & maintenance

• Circuit protection against faulty connection in power polarity

• Zoom & Focus Adjustment on 3-Axis gimbal

• Double side Anti-scratch Hard coated bubble dome

• Quick installation with Easy Adaptor (Flat or Tilted Adaptor)

• Power: DC12V

Composition

ULTRA CLEAR RESOLUTION CAMERA

Mounting Template Operating Instruction

Video Sub-out Cable

Mounting Screw:

3.5 x 25mm (3pcs)

Plastic Anchor:

6 x 30mm (3pcs)

Dome Camera

Easy Adaptor

(Flat type) Open & Adjust

Driver (1pc)

Easy Adaptor

(Tilted type)

(unit : mm)

ULTRA CLEAR RESOLUTION CAMERA

Dimensions

• Extreme care should be taken NOT to scratch the bubble dome surface while

the camera installing or adjusting.

• Care should be taken the cable is NOT to be damaged, kinked or exposed in

the hazardous area.

• Do not expose the camera directly to a strong light source such as the sun or

spot light.

CAUTION

Tilted adaptor

Ø116

Ø80

94 (with Flat adaptor)

52.5

116.3 (with Tilted adaptor)

ULTRA CLEAR RESOLUTION CAMERA

Part Names

Dome Cover

Lens

Bubble Shield

Bubble

Dome Base

Easy Adaptor

Flat type

SMD LEDs

Focus & Zoom

adjustment

Light

Sensor

Power Cable

3-Axis Gimbal

Tilted Easy Adaptor

Video format DIP Switch

CVBSHD

ULTRA CLEAR RESOLUTION CAMERA

Installation Instructions

Mounting Screw

(3.5x25mm)

Plastic Anchor

(6x30mm)

OPEN

LOCK

1. Drill three holes for mounting on the ceiling or wall.

2. Place the Easy Adaptors at the pre-drilled installation position and fix it by

using mounting screws.

3. Route the power/video cable to the connecting place.

4. Attach the dome base assembly to the Easy Adaptor.

5. Adjust the camera’s viewing angle (Pan, Tilt, Rotation)

(Then remove the caution sticker. Refer to p.11)

6. Assemble the dome cover to the dome base unit.

Open & Adjust

Driver
