EnGenius EOA3630 Bedienungsanleitung

EOA3630 Outdoor 7 Multi-Function AP/CB • 2.4 GHz 802.11b/g

• IP65

• RSSI indicator

• 7-Multi Function

PRODUCT DESCRIPTION

The outdoor wireless device EOA3630 is a powerful, enhanced, enterprise scale

product with 7 multi-functions. External N-type connector provides antenna extend.

It features output power levels setting, Narrow bandwidth selection, Traffic

Shaping and Real-time RSSI indicator.

EOA3630 comes with wall mount kit and supports PoE function for quick outdoor

installation. To ensure wireless security, it provides full coverage of security

encryption mechanisms support including WEP, WPA/WPA2 and IEEE 802.1x.

Beside upgradable N-type interface which make it a scalable solution for all

possible project requirements. Stable and high reliability design let users don’t

worry about the operation in harsh environment.

Package Content

1* EOA3630

1* PoE injector with Power Adapter

1* QIG

1* Wall Mounting kit

1* CD with User’s Manual

Learn more about EnGenius Solutions at www.engeniustech.com.sg

BUSINESS CLASS

EOA3630

3630 Datasheet Version 09032010

** All specifications are subject to change without notice

Features Benefits

High Speed Data Rate Up to 108Mbps Capable of handling heavy data payloads such as MPEG video

streaming

High Output Power up to 28 dBm Extended excellent Range and Coverage (fewer APs)

IEEE 802.11b/g Compliant Fully Interoperable with IEEE 802.11b/IEEE802.11g compliant

devices

Watertight and Weatherproof Avoid water invaded and weather corroded for outdoor

environment

Wall mount and mast mounting kit support Building on Outdoor environment easily.

Detachable antenna support (N-Type) Collocate with any antenna for user’s environment

7 Multi-Function Users can use different mode in various environment

Point-to-point, Point-to-multipoint Wireless Connectivity Let users transfer data between two buildings or multiple

buildings

Channel Bandwidth Selection Using different bandwidth to reach varied distance

Support RSSI Indicator (CB mode) Users can select the best signal to connect with AP easily

Power-over-Ethernet Flexible Access Point locations and cost savings

Universal Repeater The easiest way to expand your wireless network's coverage

Support Multi-SSID function (4 SSID) in AP mode Allow clients to access different networks through a single

access point and assign different policies and functions for each

SSID by manager

WPA2/WPA/ IEEE 802.1x support Powerful data security

MAC address filtering in AP mode(up to 50) Ensures secure network connection

PPPoE/PPtP function support (CR mode) Easy to access internet via ISP service authentication

SNMP Remote Configuration Management Help administrators to remotely configure or manage the Access

Point easily.

QoS (WMM) support Enhance user performance and density

Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

EOA3630

BUSINESS CLASS

EOA3630

EOA3630 Datasheet Version 09032010

** All specifications are subject to change without notice

TECHNICAL SPECIFICATION

> Hardware Specification

zHM081,6132RAsorehtAUCM

MARDSBM23yromeM

BM8hsalF

54-JRtenrehtEtsaF001/01enO:NAL-ecafretnIlacisyhP

- Reset Button

- Antenna Switch

sutatS/rewoPx1sutatSsDEL

1 x LAN (10/100Mbps)

1 x WLAN (Wireless is up)

3 x Link Quality (Client Bridge mode)

• Green: Good Quality

• Yellow: Marginally Acceptable Quality

• Red: Bad Quality

Power Requirements Active Ethernet (Power over Ethernet)

24V/0.6A

Regulation Certifications FCC Part 15/UL, ETSI 300/328/CE

> RF Specification

Frequency Band 2.412～2.484 GHz

Media Access Protocol Carrier sense multiple access with collision avoidance (CSMA/CA)

Modulation Technology - OFDM: BPSK, QPSK, 16-QAM, 64-QAM

- DBPSK, DQPSK, CCK

Operating Channels 11 for North America, 14 for Japan, 13 for Europe

Receive Sensitivity (Typical) IEEE802.11g

6Mbps@ -92dBm

54Mbps@ -74dBm

IEEE802.11b

1Mbps@ -97dBm

11Mbps@ -89dBm

IEEE802.11g

27dBm@6~24Mbps

25dBm@36Mbps

23dBm@48Mbps

22dBm@54Mbps

IEEE802.11b

28dBm@1 ~ 11Mbps

Available transmit power

mBd1±=ecnareloTmBd1±=ecnareloT

annetnA

Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

EOA3630

BUSINESS CLASS

EOA3630

EOA3630 Datasheet Version 09032010

** All specifications are subject to change without notice

1 x External N-Type (Female) Connector

EOA3630_27082009_REVISED.pdf 7/21/2010 4:04:46 PMEOA3630_27082009_REVISED.pdf 7/21/2010 4:04:46 PM

> Software Features

Setting

Topology Infrastructure

Operation Mode Access point/Client Bridge/Repeater/WDS AP/WDS CB/

Client Router/AP Router

LAN DHCP Server

DHCP Client

WAN PPPoE/PPtP (Client Router /AP Router mode)

Router NAT/ NAPT

VPN VPN pass-through (PPTP, L2TP, IPSEC)

Wireless - Wireless Mode – 11b / 11g / Disable

- Channel Selection (Setting varies by Country)

- Transmission Rate

11 b/g: 54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 in Mbps

SuperG: 108Mbps

- Distance Control (Ack timeout)

- Signal Strength

- Channel Bandwidth Selection- 20/10/5MHz

- RSSI Indicator (CB mode)

- Auto Channel Selection

- AP Detection

- MSSID up to 4

- BSSID

Security - WEP Encryption-64/128/152 bit

- WPA Personal (WPA-PSK using TKIP or AES)

- WPA Enterprise (WPA-EAP using TKIP)

- 802.1x Authenticator

- Hide SSID in beacons

- Multiple SSID with 802.1q VLAN tagging (up to 4 SSIDs)(AP mode)

- MAC Filter(AP mode)

- L2 isolation(AP mode)

- Wireless STA (Client) connected list

QoS WMM

Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

EOA3630

BUSINESS CLASS

EOA3630

EOA3630 Datasheet Version 09032010

** All specifications are subject to change without notice

> Management

Configuration Web-based configuration (HTTP)/Telnet

Firmware Upgrade - Upgrade firmware via web-browser

- Keep latest setting when f/w update

Administrator Setting Administrator password change

Reset Setting - Reboot

- Reset to Factory Default

System monitoring Status, Statistics and Event Log

SNMP V1, V2c

MIB MIB I, MIB II (RFC1213)

Bandwidth Measurement Traffic Shaping

Backup & Restore Settings through Web

Diagnostic Ping Function and Trace-route

ENVIRONMENT

Temperature Range Operating: -20°C~70°C

Storage: -30°C to 80°C

Humidity (non-condensing) 5%～95% typical

Dimensions 260mm(L) x 175mm(W) x 65mm(H)

Weight 680g

MECHANICAL



V1.0

Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

EOA3630

BUSINESS CLASS

EOA3630

EOA3630 Datasheet Version 09032010

** All specifications are subject to change without notice
