EnGenius ETR9360 Bedienungsanleitung

ETR9360 Wireless-N 3G Router & Client Bridge

• 2.4GHz

• 150Mbps

• 3G/3.5G Network Sharing

Learn more about EnGenius Solutions at www.engeniustech.com.sg

HOME AND HOME OFFICE

ETR9360

ETR9360 Datsheet Version 24052010

*Theoretical wireless signal rate based on IEEE standard of 802.11 b, g, n chipset used. Actual throughput may vary.Network conditions and environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice

91mm

31mm

63mm

PRODUCT DESCRIPTION

ETR9360 is a 1T1R Wireless Single chip 11N Pocket AP/Router that delivers up to 3-times faster speed than 802.11g devices while

serving with superior performance and unparalleled wireless range. With just the size of your breast-pocket, you can share 3G/3.5G or

ADSL network anytime & anywhere without additional bulky adapter. It also comes with easy-to-use WPS function which allows you to

setup wireless connection with one-touch.

PACKAGE CONTENT

1*802.11n Pocket AP (ETR9360)

1*CD (User’s Manual)

1*Lion Battery

1* Power Adapter

1*RJ45 cable

Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

ETR9360

HOME AND HOME OFFICE

ETR9360

ETR9360 Datsheet Version 24052010

*Theoretical wireless signal rate based on IEEE standard of 802.11 b, g, n chipset used. Actual throughput may vary.Network conditions and environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice

TECHNICAL SPECIFICATIONS

> HARDWARE SPECIFICATION

MCU RT3050, embedded RF/MAC/BB

Memory 32MB SDRAM

Flash 4MB

PCB dimension 80mm * 54mm

WAN/LAN: 10/100 Fast Ethernet RJ-45 x 1

USB port for 3G

WPS (WiFi Protected Setup)

Physical Interface

Mini-USB for Adapter

Operation Mode

Power Status

WAN (Internet)

WLAN(Wireless connection)

WPS

LEDs Status

Power Requirements Lion Battery or Adapter (3.7V 1800mAh)

Battery Charger (110~240V)

> Top Panel (LED status)

Operation Mode 1(AP:Orange/Router:Blue/ClientBridge:Green)

Power 1 ( Link-> blue static on)

WAN 1 ( Link-> blue static on, traffic->blink)

WLAN 1 ( Link-> blue on, traffic->blink)

WPS 1 (Link-> Associate Done, Processing->blink)

3G 1 (Link blue static on)

Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

ETR9360

HOME AND HOME OFFICE

ETR9360

ETR9360 Datsheet Version 24052010

*Theoretical wireless signal rate based on IEEE standard of 802.11 b, g, n chipset used. Actual throughput may vary.Network conditions and environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice

RF SPECIFICATION

Frequency Band 2.400～2.484 GHz

Modulation Technology OFDM: BPSK, QPSK, 16-QAM, 64-QAM

DBPSK, DQPSK, CCK

Operating Channels 11 for North America, 14 for Japan, 13 for Europe

Wireless Setting Wireless Mode – 11b/ 11g /11n

Channel Selection (Setting varies by Country)

Channel Bandwidth (Auto, 20Mhz, 40Mhz)

Transmission Rate

-11g: Best. 54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 in Mbps

-11n:

Guard Interval 800ns Guard Interval 400ns

MCS

Index 20MHz

(Mbps)

40MHz

(Mbps)

20MHz

(Mbps)

40MHz

(Mbps)

0 6.5 13.5 7.2 15

1 13 27 14.4 30

2 19.5 40.5 21.7 45

3 26 54 28.9 60

4 39 81 43.3 90

5 52 108 57.8 120

6 58.5 121.5 65 135

7 65 135 72.2 157.5

Receive Sensitivity (Typical)

1 Mbps -90 dBm

11b 11 Mbps -87 dBm

6 Mbps -90 dBm

11g 54 Mbps -70 dBm

MCS 0 -82 dBm

11n / HT 20 MCS 7 -64 dBm

MCS 0 -79 dBm

11n / HT 40 MCS 7 -61 dBm

Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

ETR9360

HOME AND HOME OFFICE

ETR9360

ETR9360 Datsheet Version 24052010

*Theoretical wireless signal rate based on IEEE standard of 802.11 b, g, n chipset used. Actual throughput may vary.Network conditions and environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice

Available Transmit Power Mode Status Specification

11b 1 ~ 11 Mbps ≧16 dBm

6 ~ 9 Mbps ≧16 dBm

12 ~ 18 Mbps ≧15 dBm

24 ~ 36 Mbps ≧14 dBm

11g

48 ~ 54 Mbps ≧13 dBm

MCS 0~1 ≧16 dBm

MCS 2~3 ≧15 dBm

MCS 4~5 ≧14 dBm

11n

MCS 6~7 ≧13 dBm

Antenna * 1 Peak Gain = 2 dBi embedded ANT

SOFTWARE FEATURES

> ROUTER AND GATEWAY

Topology Infrastructure

Operation Mode AP/Router/Client Bridge

LAN

DHCP Server

Static Routing Table

UPNP

WAN

PPTP

PPPoE

Static IP

DHCP Client

Clone MAC

Router

NAT/ NAPT

Static Routing

Dynamic Route

Virtual server mapping

IP address mapping

Port Forwarding

Port Triggering

Special application

ALG(Application Layer Gateway) support (RTP/RTSP, AOL, FTP, ICMP, WMP/MMS, NetMeeting,

SIP)

DNS Relay

Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

ETR9360

HOME AND HOME OFFICE

ETR9360

ETR9360 Datsheet Version 24052010

*Theoretical wireless signal rate based on IEEE standard of 802.11 b, g, n chipset used. Actual throughput may vary.Network conditions and environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice

DDNS

Time Zone(NTP client)

Firewall

Blocking Ping

DoS(Blocking Ping, Port scan, Sync Flood)

MAC / IP Filtering

ICMP Blocking

SPI (Stateful Packet Inspection)

DMZ (Demilitarized Zone) Host

Policy Based Parental Controls

Port Range / Service Filtering

Internet Domain Restriction

Dynamic URL Filtering (OEM subscription service)

VPN VPN pass-through (PPTP, L2TP, IPSEC)

Wireless

Power saving(Green technology)

64/128 bit WEP Encryption

WPA Personal (WPA-PSK using TKIP or AES)

WPA Enterprise (WPA-EAP using TKIP)

802.1x Authenticator

Hide SSID in beacons

Wi-Fi Protection Setup (WPS)

ACL control

Best channel selection

Speed/Bandwidth monitor

QoS

WMM

Application base

Priority Queue

Bandwidth Allocation

Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

ETR9360

HOME AND HOME OFFICE

ETR9360

ETR9360 Datsheet Version 24052010

*Theoretical wireless signal rate based on IEEE standard of 802.11 b, g, n chipset used. Actual throughput may vary.Network conditions and environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice

MANAGEMENT

Configuration Web-based configuration (HTTP)

Firmware Upgrade Via webpage upgrade

Auto recovery once firmware upgrade fail

Administrator Setting Administrator password change

Idle time out

WPS button 2sec WPS Enable

>10sec Reset to Default

System monitoring Speed and Bandwidth monitoring

Scheduling Enable power saving

Easy access User can type model name and access the main page.

Install wizard Guide user to set-up Router smoothly

ENVIRONMENT AND PHYSICAL

Temperature Range 0 to 40° C - Operating, -10 to 70 ° C - Storage

Humidity (non-condensing) 15%～95% typical

Dimensions 90mm (L) x 63mm (W) x 31mm (H)

BATTERY SPECS

Hours

Device Standby 13~14

Extreme Loading 3~4

Normal Loading 4~5

Battery Charge 1~2
