Epson AL-M200 Series Bedienungsanleitung

Wireless Network Setup

Guide

NPD4754-01 EN

Wireless Network Setup Guide

Checking Your Network

Confirm your computer’s network settings, and then choose what to do next. Follow the instructions

for the environment in which your network devices such as a wireless router or a wireless adapter work

properly.

Windows 7

1. Select Start — Control Panel — Network and Internet.

2. Click Network and Sharing Center.

3. Click Change adapter settings.

4. On the window that appears, answer the following questions in “Checking items” on page 3.

Windows XP

1. Select start — Control Panel.

2. Click Network Connections.

3. On the window that appears, answer the following questions in “Checking items” on page 3.

Mac OS X

1. Select System Preferences from the Apple Menu.

2. Click Network icon.

3. Proceed to “Configuring Wireless Settings (For Mac OS X)” on page 26.

AL-M200 Series Wireless Network Setup Guide

Wireless Network Setup Guide 2

Checking items

1. Is there the Wireless Network Connection icon?

Yes: Wireless LAN connection is available. Proceed to step 2.

No: Proceed to step 3.

2. Does the Wireless Network Connection icon have a red ?

Yes: Wireless LAN (Ad Hoc) connection is available.

Windows 7 Windows XP

Go to “Ad Hoc Settings for Windows” on page 15.

No: Wireless LAN (Wi-Fi) connection is available.

AL-M200 Series Wireless Network Setup Guide

Wireless Network Setup Guide 3

Windows 7 Windows XP

Go to “Configuring Wireless Settings (for Windows)” on page 5.

3. Is there the Local Area Connection icon?

Yes: Proceed to step 4.

No: Network connection is not available. You need to set up network environment for your

computer.

4. Does the Local Area Connection icon have a red ?

Yes: Network connection is not available. You need to set up network environment for your

computer.

Windows 7 Windows XP

No: Wired LAN connection is available. Go to step 5.

AL-M200 Series Wireless Network Setup Guide

Wireless Network Setup Guide 4

Windows 7 Windows XP

5. Refer to User's Guide for more information.

Configuring Wireless Settings (for Windows)

Note:

Be sure to get the SSID and security information from a system administrator in advance when you use

other than WPS.

The following procedure uses Windows 7 as an example.

AL-M200 Series Wireless Network Setup Guide

Wireless Network Setup Guide 5

1. Insert the Software Disc provided with the printer in your computer.

When the AutoPlay window appears, click Run setup.exe to start the Install Navi.

Note:

If the CD does not automatically launch or the AutoPlay window does not appear, click Start —

Computer — D:\setup.exe (where D is the drive letter of your CD), and then click OK.

2. Click Easy Install.

The SOFTWARE LICENSE AGREEMENT appears.

3. If you agree to the terms of the SOFTWARE LICENSE AGREEMENT, select Agree and then click

Next.

Easy Install Navi launches.

4. Click Start Setup.

AL-M200 Series Wireless Network Setup Guide

Wireless Network Setup Guide 6

5. Ensure that Connect Your Printer is selected and the Select your type of connection screen is

displayed.

6. Select Wireless Connection, and then click Next.

The setting method selection window appears.

AL-M200 Series Wireless Network Setup Guide

Wireless Network Setup Guide 7

7. Ensure that Wizard is selected, and then click Next.

Note:

If you select Advanced, refer to User's Guide for more information.

8. Follow the instructions until the Printer Setup Utility screen appears.

AL-M200 Series Wireless Network Setup Guide

Wireless Network Setup Guide 8

If the following window appears, make sure the USB cable is connected to the USB port on the

printer.

9. Select the SSID that you want to connect to as an access point, and then click Next.

Note:

To enter the SSID directly, click Input the SSID directly radio button and enter the SSID in the SSID

box.

AL-M200 Series Wireless Network Setup Guide

Wireless Network Setup Guide 9

10. Enter the WEP Key for the selected access point, and then click Next.

Note:

To display the entered character, select the Show input check box.

11. Select IP Mode depending on your network scheme.

When IPv4 is selected, configure the following:

aSelect Type.

bIf you have selected Use Manual Address from Type, enter the following items:

❏IP Address of your printer

❏Subnet Mask

❏Gateway Address

When Dual Stack is selected, configure the following:

aConfigure IPv4 Settings.

AL-M200 Series Wireless Network Setup Guide

Wireless Network Setup Guide 10
