Epson EPL-5700L Einrichtungshandbuch

Where to Find Information

Unpacking Guide

Provides you with information and instructions on how to

unpack the printer. Before using the printer, you need to remove

all protective materials as described in the instructions contained

in this guide.

Getting Ready (this manual)

Provides you with information on assembling the printer’s parts

and installing printer options.

Reference Guide

Provides you with detailed information on the printer’s functions,

maintenance, troubleshooting, and technical specifications.

Online Help

Provides you with detailed information and instructions on the

printer driver that controls your printer (online help will be

automatically installed when you install the printer driver).

Getting Ready

Laser Printer

system, or transmitted in any form or by any means, mechanical, photocopying, recording,

or otherwise, without the prior written permission of SEIKO EPSON CORPORATION.

No patent liability is assumed with respect to the use of the information contained herein.

Neither is any liability assumed for damages resulting from the use of the information

contained herein.

Neither SEIKO EPSON CORPORATION nor its affiliates shall be liable to the purchaser of

this product or third parties for damages, losses, costs, or expenses incurred by purchaser or

third parties as a result of: accident, misuse, or abuse of this product or unauthorized

modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly

comply with SEIKO EPSON CORPORATION’s operating and maintenance instructions.

SEIKO EPSON CORPORATION shall not be liable against any damages or problems arising

from the use of any options or any consumable products other than those designated as

Original Epson Products or Epson Approved Products by SEIKO EPSON CORPORATION.

General Notice: Other product names used herein are for identification purposes only and may be

trademarks of their respective owners. EPSON disclaims any and all rights in those marks.

Declaration of Conformity

According to ISO/IEC Guide 22 and EN 45014

Manufacturer: SEIKO EPSON CORPORATION

Address: 3-5, Owa 3-chome, Suwa-shi,

Nagano-ken 392-8502 Japan

Representative: EPSON EUROPE B.V.

Address: Prof. J. H. Bavincklaan 5 1183

AT Amstelveen

The Netherlands

Declares that the Product:

Product Name: Laser Printer

Model: L270-D

Conforms to the following Directive(s) and Norm(s):

Directive 89/336/EEC:

EN 55022 Class B

EN 50082-1

IEC 801-2

IEC 801-3

IEC 801-4

Directive 73/23/EEC:

EN 60950

October 1999

H. Horiuchi

President of EPSON EUROPE B.V.

iii

Contents

1 Safety Instructions

Laser Printer Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Warnings, Cautions, and Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2 Finding a Place for the Printer

3 Installing the Options

500-Sheet Lower Cassette Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Face-up Tray. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Memory Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Removing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

4 Connecting the Printer

Loading Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Attaching the Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Connecting to the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Parallel interface for PCs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Using a USB connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

5 Installing the Printer Software

For Windows Users. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

For parallel interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

For USB interfaces (Windows 98 pre-installed PCs only) . 25

For Macintosh Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

For USB interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Making Basic Driver Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

For Windows users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Testing the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Printing a Status Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

6 Safety Information

Laser Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

For United Kingdom users. . . . . . . . . . . . . . . . . . . . . . . . . . . 38

CDRH regulations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Laser safety labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Internal laser radiation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Ozone safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

ENERGY STAR Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

For United Kingdom Users. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Use of options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Safety information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Index

Safety Instructions 1

1Safety Instructions

Laser Printer Precautions

This printer uses laser technology. The following list of

precautions applies whenever you open the printer cover. Even

if you are familiar with other types of printers, be sure to follow

these precautions carefully to ensure safe, trouble-free operation.

wWarning:

Be careful not to touch the fuser, which is marked CAUTION

Hot Surface Avoid Contact. If the printer has been in use, the

fuser can be very hot.

❏Avoid touching the components inside the printer unless

instructed to do so in this guide.

CAUTION Hot Surface Avoid Contact

2 Safety Instructions

❏Never force the printer’s components into place. Although the

printer is designed to be sturdy, rough handling can damage

it.

❏When removing the developer cartridge, never touch the

developing roller under the flap; otherwise, the print quality

will decline.

❏Do not turn the cartridge upside down or stand it on its sides.

❏When handling the cartridge, always set it on a clean, smooth

surface.

❏Do not attempt to modify or take apart the cartridge. It cannot

be refilled.

❏Try not to touch the toner and avoid all contact with your eyes.

❏Do not use a cartridge for at least one hour after moving it

from a cool to a warm environment.

Safety Instructions 3

❏When removing or installing a new photoconductor unit,

avoid exposing it to light. The green cylinder, visible through

the openings in the unit, is a light-sensitive drum. If the

photoconductor unit is out of the printer for a long period,

covering it with an opaque cloth prevents extended exposure

to light and possible damage. Exposure to light will damage

the drum, resulting in dark or light areas on the printed page

and may shorten the service life of the unit.

❏Be sure not to scratch the surface of the drum. When you

remove the photoconductor unit from the printer, always set

the unit on a clean, smooth surface. Also, avoid touching the

drum, as oils from your skin can permanently damage its

surface and may affect print quality.

❏To get the best print quality, do not store the photoconductor

unit in an area subject to direct sunlight, dust, salty air, or

corrosive gasses (such as ammonia). Avoid locations subject

to extremes or rapid changes of temperature or humidity.

Also, be sure to keep the consumable components out of the

reach of children.

Hinweis:

Die Geräteanschlußleitung muß den einshlägigen Normen genügen. Es

muß eine dreiadrige Leitung verwendet werden. Die Anshlußleitung

darf nicht leichter als H05VV-F order H05VVH2-F sein.
