Equalizer Terminator TSK710 Bedienungsanleitung
Windshield Repair System
Part# TSK710
User Guide
WARRANTY INFORMATION
Equalizer® Terminator® is warranted for 30 days to be free of
factory defects from the date of purchase. Warranty does not apply
to abuse, misuse, normal wear and tear, to accessories or damage.
Equalizer® will replace, at our option, any defective part.
TSK710 • Equalizer® Terminator® Windshield Repair Kit
If you feel your product is covered under warranty
send the entire kit to:
Equalizer®
Attention: Customer Service
2611 Oakmont Drive
Round Rock, TX 78665
Equalizer® reserves the right to refuse, at our expense, any product
which has not been properly used or maintained as specied in the
User Guide.
If you have any questions about your tool call us at 512.388.7715,
fax us at 512.388.4188, or email sales@equalizer.com.
Thank you for your purchase of the Equalizer® Terminator®!
Equalizer® is committed to manufacturing quality tools and
products. Equalizer® has tested and demonstrated the
Equalizer® RockStar® Roadie™ on various breaks. This guide is meant to give
basic procedures on the use of this product.
For technical support and tips please contact us
for assistance at 512.388.7715.
To watch Instructional Videos go to equalizer.com/videos or
scan the QR code below:
Always wear safety gloves and safety glasses
when using Equalizer® products.
Inspection and Assessment:
1. Examine the damaged area from the inside and outside of the
vehicle. Look for hidden cracks, moisture, contamination or
previous repair attempts.
2. Determine if the damage is within the scope of your technical
experience to repair.
3. Assess to make sure that the windshield is at the appropriate
temperature. Ideal temperature is between 65°F to 85°F plus or
minus 5°F.
4
Install the mirrow inside the car to serve as a guide during the re-
pair. Using the probe, remove broken glass debris from the chip.
Use a clean dry paper towel to wipe debris away.
Clean around the damaged area with water or glass cleaner. Be sure
to place a nitrile glove-covered nger over the rock chip in order to
keep from contaminating the break. Wipe dry with the paper towel.
Install the bridge onto the glass so that the injector tip o-ring is over
the rock chip. Pump the vacuum cup to secure to the glass. Screw
the injector down until the o-ring makes contact with the surface of
the glass. Adjust the bridge posts until the o-ring has a at look to its
appearance.
Unscrew the nozzle of the injector and apply 3-5 drops of resin in the cham-
ber.
*Always make sure to use the right resin for the job. If the temperature of
the work area is warm or the job is at high altitude; always use a thicker res-
in. If the temperature of the work area is cool or at sea level use a thinner
resin.
Connect the hose onto the chamber, then connect the hose onto the right
side of the terminator machine.
Switch the terminator on by pressing the white button on top of the
machine. [Select your program with the button menu.]
6
Several programs available:
a) Stars-break and combo- Duration: 12 min 30
b) Bull-eyes and half bull-eyes
Duration: 8 min 30
c) Express nish program: for every types - Duration: 2 min 35
Once you selected a program press “START”.
The machine automatically purges at the end of the repair and warns you at
the end of the program with a sound and displays “END”
Remove the injection bridge
Wipe the excess of resin from the pit with a clean cloth.
Apply a drop of pit ller resin. Place a mylar square cure sheet onto the pit ller
resin. Be sure to gently place the cure sheet in a download laying motion and let
gravity do the rest.
Place the UV lamp over the break, power on and let cure for 50 seconds. *UV
lamp will ash when curing and turn off when complete.
Remove the UV lamp and mylar square. Using a new razor blade, scrape the new
resin in a back and forth motion at a 90 degree angle until the resin is even and
level with the glass. *Spray water or glass cleaner over the repair to make remov-
ing resin easier.
Apply a drop of pit polish over the repair and using a clean, dry paper towel buff
vigorously until the pit resin is shiny.
Battery and Charger
You can charge the battery of the TERMINATOR® directly by connecting it
to a power outlet. The charge of the battery can be done with the power
on or power off.
Charge the unit once the last lling charge remain.
Function of the charger:
Green LED light : Charged
Red LED Stable : Under charge
Red LED Flashing : Charging problem
Charging time: 1 hour 30 minutes
Cleaning and Maintenance
Clean the hose on the side where the resin has been injected, then, with a
cleaning solution to remove the excess of resin from the other side.
Clean the suction cups (UV lamp, inspection glass and if necessary the
injection bridge with water and dry towel.
Always storage resins in their original packaging, protected from UV light.
2
2611 Oakmont Drive • Round Rock • Texas • 78665
Toll Free USA & Canada: 800.334.1334
International: 512.388.7715 • Fax: 512.388.4188
Email: sales@equalizer.com
www.equalizer.com
VCB1454VPO1455 AVL209
VAF1471
VAL1472
VPF1452
VPL1453
VMR1450
VML1451
VTR1448
VTL1449 TRR652
TRO653
DL1093 BNG418
BNL820
MS492
VPT1489
RB497
VUV1447
Additional Accessories
