EtherWAN EX48000A Series Bedienungsanleitung

Hardened PoE Ethernet Switch

Quick Start Guide

This quick start guide describes how to install and use the

Hardened PoE Ethernet Switch. This is the switch of choice

for harsh environments constrained by space.

Physical Description

The Port Status LEDs and Power inputs

Hardened PoE Ethernet Switch

LED State Indication

Steady Power on.

Power1

Power2

Power3 Off Power off.

Steady Power redundant system failure occurred.

Fault Off Power redundant system failure is not

occurred.

10/100Base-TX, 100Base-FX/BX

Steady A valid network connection established.

Link/ACT Flashing Transmitting or receiving data.

ACT stands for ACTIVITY.

Steady Valid port connection at 100Mbps.

10/100 Off Valid port connection at 10Mbps.

Power Input Assignment

Power3 48VDC DC Jack

＋48VDC

Power2 －Power Ground

＋48VDC

Power1 －Power Ground

Earth Ground

Terminal Block

Relay Output Rating 1A @ 24VDC

Relay Alarm Assignment

FAULT

*Relay warning signal disable for following:

The relay contact closes if Power1 and

Power2 are both failed but Power3 on.

The relay contact closes if Power3 is failed

but Power1 and Power2 are both on.

DC Terminal Block Power Inputs: There are two pairs of

power inputs can be used to power up this switch. Redundant

power supplies function is supported.

The 10/100Base-TX and 100Base-FX/BX Connectors

1. The 10/100Base-TX Connections

The following lists the pinouts of 10/100Base-TX ports.

Hardened PoE Ethernet Switch

Pin PoE Ports (Port 1-4) Non-PoE Port (Port 5)

1 Output Transmit Data + Output Transmit Data +

2 Output Transmit Data - Output Transmit Data -

3 Input Receive Data + Input Receive Data +

4 Positive (VCC+)

5 Positive (VCC+)

6 Input Receive Data - Input Receive Data -

7 Negative (VCC-)

8 Negative (VCC-)

2. The 100Base-FX Connections

The fiber port pinouts: The Tx (transmit) port of device I is

connected to the Rx (receive) port of device II, and the Rx

(receive) port of device I to the Tx (transmit) port of device II.

3. The WDM 100Base-BX Connections

The fiber port pinouts: Only one optical fiber is required to

transmit and receive data.

Hardened PoE Ethernet Switch

Functional Description

•Meets NEMA TS1 & TS2 Environmental requirements:

temperature, shock, and vibration for traffic control

equipment.

•Meets EN61000-6-2 & EN61000-6-4 EMC Generic

Standard Immunity for industrial environment.

•Supports IEEE802.3af Power over Ethernet (PoE)

Power Sourcing Equipment (PSE).

•Supports IEEE802.3/802.3u/802.3x. Auto-negotiation:

10/100Mbps, Full/Half-duplex, Auto-Negotiation, Auto

MDI/MDIX.

•100Base-FX: Multi/Single mode SC or ST type,

100Base-BX: WDM Multi/Single mode SC type.

•Supports 1024 MAC addresses. Provides 512K bits

buffer memory.

•Alarms for power and port link failure by relay output.

•Power Supplies: Redundant 48VDC Terminal Block

power inputs and 48VDC DC JACK with optional

100-240VAC external power supply.

•Operating voltage and Max. current consumption: 1.5A

@ 48VDC. Power consumption: 72W Max.

•-40 to 75 (℃℃-40℉to 167℉) operating temperature

range. Tested for functional operation @ -40 to 85℃℃

(-40℉to 185℉).

•Supports Desktop installation.

Hardened PoE Ethernet Switch

Preface

A member of the growing family of rugged switches, this

Hardened PoE Ethernet Switch addresses a need for a

smaller switch. This switch provides an affordable solution

for rugged and outdoor environment, transportation

road-side cabinet, industrial floor shop, multitenant

dwellings or Fiber To The Home (FTTH) applications.

Capable of operating at temperature extremes of -40°C to

+75°C, this is the switch of choice for harsh environments

constrained by space.

Port 1 to port 4 on this Switch supports IEEE802.3af Power

over Ethernet (PoE) Power Sourcing Equipment (PSE) and

can detect an IEEE802.3af compliant Powered Device

(PD). Using external 48VDC power inputs through

Terminal Block or Power Jack, data and power can be

transmitted to a Powered Device (PD) over the same

twisted-pair Ethernet cable through port 1 to port 4 on the

Switch.

This manual describes how to install and use the hardened

Ethernet Switch. This switch integrates full wire speed

switching technology. This switch brings the answer to

complicated hardened networking environments.

To get the most out of this manual, you should have an

understanding of Ethernet networking concepts.

In this manual, you will find:

•Features on the switch

•Illustrative LED functions

•Installation instructions

•Specifications

Hardened PoE Ethernet Switch

Table of Contents

QUICK START GUIDE 1

PHYSICAL DESCRIPTION 1

The Port Status LEDs and Power inputs 1

The 10/100Base-TX and 100Base-FX/BX Connectors 2

FUNCTIONAL DESCRIPTION 4

PREFACE 5

TABLE OF CONTENTS 6

PRODUCT OVERVIEW 7

HARDENED POEETHERNET SWITCH 7

PACKAGE CONTENTS 7

PRODUCT HIGHLIGHTS 8

Basic Features 8

FRONT PANEL DISPLAY 9

PHYSICAL PORTS 10

INSTALLATION 11

SELECTING A SITE FOR THE SWITCH 11

CONNECTING TO POWER 12

Redundant DC Terminal Block Power Inputs 12

48VDC DC Jack 12

Alarms for Power and Port Link Failure 13

CONNECTING TO YOUR NETWORK 14

Cable Type & Length 14

Cabling 15

SPECIFICATIONS 16

Hardened PoE Ethernet Switch

Product Overview

Hardened PoE Ethernet Switch

Package Contents

When you unpack the product package, you shall find the

items listed below. Please inspect the contents, and report

any apparent damage or missing items immediately to your

authorized reseller.

3This Switch

3User’s Manual

3External power adapter & Power Cord (Optional)

Hardened PoE Ethernet Switch

Product Highlights

Basic Features

•Meets NEMA TS1 & TS2 Environmental requirements:

temperature, shock, and vibration for traffic control

equipment.

•Meets EN61000-6-2 & EN61000-6-4 EMC Generic

Standard Immunity for industrial environment.

•Supports IEEE802.3af Power over Ethernet (PoE)

Power Sourcing Equipment (PSE).

•Supports IEEE802.3/802.3u/802.3x. Auto-negotiation:

10/100Mbps, Full/Half-duplex, Auto-Negotiation, Auto

MDI/MDIX.

•100Base-FX: Multi/Single mode SC or ST type,

100Base-BX: WDM Multi/Single mode SC type.

•Supports 1024 MAC addresses. Provides 512K bits

buffer memory.

•Alarms for power and port link failure by relay output.

•Power Supplies: Redundant 48VDC Terminal Block

power inputs and 48VDC DC JACK with optional

100-240VAC external power supply.

•Operating voltage and Max. current consumption: 1.5A

@ 48VDC. Power consumption: 72W Max.

•-40 to 75 (℃℃-40℉to 167℉) operating temperature

range. Tested for functional operation @ -40 to 85℃℃

(-40℉to 185℉).

•Supports Desktop installation.

Hardened PoE Ethernet Switch

Front Panel Display

Status LEDs

LED State Indication

Steady Power on.

Power1

Power2

Power3 Off Power off.

Steady Power redundant system failure occurred.

Fault Off Power redundant system failure is not

occurred.

10/100Base-TX, 100Base-FX/BX

Steady A valid network connection established.

Link/ACT Flashing Transmitting or receiving data.

ACT stands for ACTIVITY.

Steady Valid port connection at 100Mbps.

10/100 Off Valid port connection at 10Mbps.

Hardened PoE Ethernet Switch

Physical Ports

This switch series provides two different combinations of

RJ-45 copper and fiber ports as below:

•Five 10/100Base-TX ports

•Four 10/100Base-TX ports + one 100Base-FX/BX port

CONNECTIVITY

•RJ-45 connectors

•SC or ST connector on 100Base-FX fiber port.

•SC connector on 100Base-BX fiber port.

<Note> Different product model supports different type of

fiber connector.
