EverFocus EQ150 Bedienungsanleitung

3”

”

Q15

User’s Manual

and

Operation Instructions

Notice

This manual is presented to the users of EQ150 by EverFocus Electronics

Corp. With years of engineering researches, EverFocus has spared no effort

to provide the high quality products to the worldwide users. For the policy

of continual product improvement, EverFocus reserves the right to make

changes to the product specifications and documentation without notice.

All the components of the products, including accessories, components, and

outlook, are based on the agreements of each deals to satisfy all kinds of

users. Meanwhile, please be advised that every step of operation must

follow the instruction of this manual to keep EQ150 working under the best

condition. Please notice that EverFocus will not be charged any claims or

renewing cases resulted from inappropriate operation.

Table of Contents

Safety Warning …………………………………………1

Introduction……………………………………………..2

Specification…………………………………………….3

Major Parts and Their Functions………………….…..4

Installation Instructions………………………….….…8

1. Handle the camera with care.

Be careful when handling the camera, do not drop it or subject

it to strong shock or vibration to prevent any damages to it. Do

not disassemble it or place it on an unstable base.

2. Do not install the camera near electric or magnetic fields.

Installed the camera away from TV, radio transmitter, magnet,

electric motor, transformer, audio speakers because the

magnetic fields generate from above devices will distort the

video image.

3. Do not install the camera in the high temperature environment.

Installed the camera away from stoves, or other heat

generating devices as the high temperature could cause

deformation, discoloration or other damages of the camera.

Install the camera at where the temperature range will stay

between 0℃to 50℃ (32℉ to 122℉).

4. Never face the camera toward the sun.

Never aim the camera at the sun or other extremely bright objects

whether it is in use or not.

5. Cleaning

Do not touch the surface of CCD sensor by hand directly. Use

a soft cloth to remove the dirt from the camera body. Use lens

tissue or a cotton tipped applicator and ethanol to clean the

CCD sensor and the camera lens. When the camera is not in

use, put the cover cap on the lens mount.

Safet

Warnin

The new EQ150 series is a solid-state color video camera specially

designed for high quality surveillance applications. It incorporates

break through DSP technology that provides most reliable and

accurate color picture in security industry. The camera is

convenient to use with C-mount or CS-mount lenses and easy

back-focus adjustment help to achieve installation efficiency.

Main Features :

¾1/3” B/W CCD pick up device for more than 560 TV lines of horizontal

resolution

¾Sophisticated DSP (Digital Signal Processing) circuitry design that delivers

excellent picture quality and performance.

¾Wide range automatic electronic shutter: 1/50(1/60)~1/100,000

¾Auto line lock with external phase adjustment

¾Used with either C-mount or CS-mount lenses and easy back-focus a

Adjustment.

¾System available in EIA or CCIR.

Introduction

Pickup Device 1/3" SONY B/W CCD

Picture Elements 768 x 494 (EIA)

752 x 582 (CCIR)

Horizontal Resolution 560 TV lines

Sensitivity 0.01 lux/F=1.2

S/N Ratio Over 48 dB

Electronic Shutter 1/50(1/60)~1/100,000 sec

Auto Iris Video / Direct Drive switch

Flickerless On/Off

Back Light Comp. On/Off

Electronic Shutter On/Off

Auto Gain Control On/Off

Line Lock On/Off

Audio Optional

Gamma Correction 0.45

Power Source 2 types: 12VDC/24VAC;90~260VAC

Power consumption 5W max.

Dimensions 50mm(H) x 57mm (W) x 140.2mm(D);

1.97" (H) x 2.24"(W) x 5.52" (D)

Operature Temparature 0°C~50°C ; 32°F~122°F (20%~80% Humidity)

Certifications FCC/CE

ecification

Front

Side

Top

Rear

(EQ150) Rear(EQ150A)

Major Parts Names and Their Functions

1. Focal Length Adjustment Ring

Use this ring to adjust the appropriate focal length according to the type

of lens. Rotate the ring clockwise for the CS-mount lens, rotate it

counterclockwise for the C-mount lens. The factory setting is C-mount.

2. Lens Mount

To mount an appropriate C-mount or CS-mount lens.

3. Locking Screw

Use the locking screw to fix the focal length.

4. Lens Connector (4 pin socket)

To connect to the lens plug of the auto iris lens.

5. Control Switches

There are 6 control switches located on the sideboard, which are for the

setting of the special features. The switches in orders are for Flickerless,

Back Light Compensation, Electronic Shutter, Automatic Gain Control,

Line-Lock and Auto Iris Lens type.

FL (Flickerless Function) On/Normal

When picture flicker fiercely, turn FL on, then the camera will stabilize

the speed of electronic shutter at 1/100(EIA) or 1/120(CCIR)

automatically, and reduce the flicker immediately. The default setting is

Normal.

BLC (Back Light Compensation) On/Normal

When BLC is turned on, the AGC, ES and IRIS operating point is

determined by averaging over the center area instead of entire

field-of-view, so that a dimly-lit foreground object at center area can be

clearly distinguished from brightly-lit backgrounds.

BLC should not be used unless it is needed to compensate for back-lit.

The default setting is Normal.

ES (Electronic Shutter) Off/On

ES ON: The camera continuously adjusts the shutter speed from 1/60

(EIA), 1/50(CCIR) second to 1/100,000 second according to the

luminance conditions of the scene.

ES OFF: The shutter speed is fixed at 1/60 (EIA), 1/50 (CCIR) second.

Set ES OFF, when auto iris lens is used or flicker is observed under a

very bright fluorescent lamp. Otherwise, turn ES on for optimum

performance. The default setting is ON.

AGC (Automatic Gain Control) Off/On

AGC ON: The sensitivity increases automatically when light is low.

AGC OFF: A-low-noise picture is obtained under a low light

condition.

The default setting is ON.

LL (Line-Lock) Off/On

To select the sync mode between Internal Sync.(LL off) and

Line-Lock (LL on).

Set the line-lock off, the camera will synchronize to the internal time

base. Set the line-lock on, the camera’s vertical synchronization can

be driven by the AC signal in the power lines.

Note: Line-Lock sync mode operation is possible only when used

with an AC power source; it’s not possible with a DC power source.
